Getting started

This section explains you the steps required to create a simple Pivot Grid and demonstrate the basic usage of the Pivot Grid component in React environment.

Setup for Local Development

You can use create-react-app to setup the applications. To install create-react-app run the following command.

npm install -g create-react-app
  • To setup basic React sample use following commands.
create-react-app quickstart --scripts-version=react-scripts-ts

cd quickstart

npm install

Dependencies

Following is the list of minimum dependencies required to use the Pivot Grid.

|-- @syncfusion/ej2-react-pivotview
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-data
    |-- @syncfusion/ej2-pivotview
        |-- @syncfusion/ej2-buttons
        |-- @syncfusion/ej2-dropdowns
        |-- @syncfusion/ej2-excel-export
          |-- @syncfusion/ej2-file-utils
          |-- @syncfusion/ej2-compression
        |-- @syncfusion/ej2-pdf-export
          |-- @syncfusion/ej2-file-utils
          |-- @syncfusion/ej2-compression
        |-- @syncfusion/ej2-grids
        |-- @syncfusion/ej2-inputs
        |-- @syncfusion/ej2-lists
        |-- @syncfusion/ej2-navigations
        |-- @syncfusion/ej2-popups
|-- @syncfusion/ej2-react-base

Adding Syncfusion packages

All the available Essential JS 2 packages are published in npmjs.com public registry. To install Pivot Grid component, use the following command

npm install @syncfusion/ej2-react-pivotview --save

Adding CSS reference

Add components style as given below in src/App.css.

@import '../node_modules/@syncfusion/ej2-base/styles/material.css';
@import '../node_modules/@syncfusion/ej2-buttons/styles/material.css';
@import '../node_modules/@syncfusion/ej2-dropdowns/styles/material.css';
@import '../node_modules/@syncfusion/ej2-grids/styles/material.css';
@import '../node_modules/@syncfusion/ej2-inputs/styles/material.css';
@import '../node_modules/@syncfusion/ej2-lists/styles/material.css';
@import '../node_modules/@syncfusion/ej2-navigations/styles/material.css';
@import '../node_modules/@syncfusion/ej2-popups/styles/material.css';
@import '../node_modules/@syncfusion/ej2-react-pivotview/styles/material.css';

To refer App.css in the application then import it in the src/App.tsx file.

Adding Pivot Grid component

Now, you can start adding Pivot Grid component in the application. For getting started, add the Pivot Grid component in src/App.tsx file using following code.

Place the following pivot grid code in the src/App.tsx.

import { IDataOptions, IDataSet, PivotViewComponent } from '@syncfusion/ej2-react-pivotview';
import * as React from 'react';

let pivotData = [
  { 'Sold': 31, 'Amount': 52824, 'Country': 'France', 'Products': 'Mountain Bikes', 'Year': 'FY 2015', 'Quarter': 'Q1' },
  { 'Sold': 51, 'Amount': 86904, 'Country': 'France', 'Products': 'Mountain Bikes', 'Year': 'FY 2015', 'Quarter': 'Q2' },
  { 'Sold': 90, 'Amount': 153360, 'Country': 'France', 'Products': 'Mountain Bikes', 'Year': 'FY 2015', 'Quarter': 'Q3' },
  { 'Sold': 25, 'Amount': 42600, 'Country': 'France', 'Products': 'Mountain Bikes', 'Year': 'FY 2015', 'Quarter': 'Q4' },
  { 'Sold': 27, 'Amount': 46008, 'Country': 'France', 'Products': 'Mountain Bikes', 'Year': 'FY 2016', 'Quarter': 'Q1' }];

class App extends React.Component<{}, {}>{

  public dataSource: IDataOptions = {
    columns: [{ name: 'Year', caption: 'Production Year' }, { name: 'Quarter' }],
    data: pivotData as IDataSet[],
    expandAll: false,
    filters: [],
    formatSettings: [{ name: 'Amount', format: 'C0' }],
    rows: [{ name: 'Country' }, { name: 'Products' }],
    values: [{ name: 'Sold', caption: 'Units Sold' }, { name: 'Amount', caption: 'Sold Amount' }]
  }
  public pivotGridObj: PivotViewComponent;
  render() {
    return <PivotViewComponent  ref={d => this.pivotGridObj = d!} id='PivotView' height={280} dataSource={this.dataSource}></PivotViewComponent>
  }
};

export default App;

Module Injection

To create Pivot Grid with additional features, inject the required modules. The modules that are available with basic functionality are as follows.

  • GroupingBar - Inject this module to access grouping bar.
  • FieldList - Inject this module to access pivot field list.
  • CalculatedField - Inject this module to access calculated field.

These modules should be injected into the PivotView using the Inject method within the app.tsx file as shown below. On doing so, only the injected views will be loaded and displayed along with Pivot grid.

<Inject services={[GroupingBar]} />

Enable Grouping Bar

The Grouping Bar feature automatically populates fields from the bound data source and allows end users to drag fields between different axes such as columns, rows, values, and filters, and create pivot views at runtime. It can be enabled by setting the showGroupingBar property to true and by injecting the GroupingBar module as follows.

If the GroupingBar module is not injected, the grouping bar will not be rendered with the Pivot Grid component.

Source
Preview
index.tsx
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { IDataOptions, IDataSet, Inject, PivotViewComponent, GroupingBar } from '@syncfusion/ej2-react-pivotview';
import { pivotData } from './datasource';
class App extends React.Component<{}, {}>{
  public dataSource: IDataOptions = {
    columns: [{ name: 'Year', caption: 'Production Year' }, { name: 'Quarter' }],
    data: pivotData as IDataSet[],
    expandAll: false,
    filters: [],
    formatSettings: [{ name: 'Amount', format: 'C0' }],
    rows: [{ name: 'Country' }, { name: 'Products' }],
    values: [{ name: 'Sold', caption: 'Units Sold' }, { name: 'Amount', caption: 'Sold Amount' }]
  };
  public pivotGridObj: PivotViewComponent;
  render() {
    return <PivotViewComponent  ref={d => this.pivotGridObj = d!} id='PivotView' height={280} dataSource={this.dataSource} showGroupingBar={true}><Inject services={[GroupingBar]} />
    </PivotViewComponent>
  }
};
ReactDOM.render(<App />, document.getElementById('pivotview'));

Enable Pivot Field List

The component provides a built-in Field List similar to Microsoft Excel. The top section of the field list allows the user to add and remove fields. The bottom section of the field list allows the user to rearrange the fields between different axes, including column, row, value, and filter along with filter and sort options. It can be enabled by setting the showFieldList property to true and by injecting the FieldList module as follows.

If the FieldList module is not injected, the Field List will not be rendered with the Pivot Grid component.

Source
Preview
index.tsx
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { FieldList, IDataOptions, IDataSet, Inject, PivotViewComponent } from '@syncfusion/ej2-react-pivotview';
import { pivotData } from './datasource';
class App extends React.Component<{}, {}>{
  public dataSource: IDataOptions = {
    columns: [{ name: 'Year', caption: 'Production Year' }, { name: 'Quarter' }],
    data: pivotData as IDataSet[],
    expandAll: false,
    filters: [],
    formatSettings: [{ name: 'Amount', format: 'C0' }],
    rows: [{ name: 'Country' }, { name: 'Products' }],
    values: [{ name: 'Sold', caption: 'Units Sold' }, { name: 'Amount', caption: 'Sold Amount' }]
  };
  public pivotGridObj: PivotViewComponent;
  render() {
    return <PivotViewComponent  ref={d => this.pivotGridObj = d!} id='PivotView' height={280} dataSource={this.dataSource} showFieldList={true}><Inject services={[FieldList]} />
    </PivotViewComponent>
  }
};
ReactDOM.render(<App />, document.getElementById('pivotview'));

Calculated field

The calculated field feature allows user to insert or add a new calculated field based on the available fields from the bound datasource. It can be customized using the calculatedFieldsSettings property through code behind. The setting required for calculate field feature at code behind are:

  • name: it allows to indicate the given calculated field with unique name.
  • formula: it allows to set the formula based on the given datasource.

Also calculated fields can be added to the bound datasource at run time through the built-in popup. The popup can be enabled by setting the allowCalculatedField property to true and by injecting the CalculatedField module as follows.

If the CalculatedField module is not injected, the calculated field popup will not be rendered with the Pivot Grid component. Moreover calculated field is applicable only for value fields.

Source
Preview
index.tsx
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { CalculatedField, FieldList, IDataOptions, IDataSet, Inject, PivotViewComponent } from '@syncfusion/ej2-react-pivotview';
import { pivotData } from './datasource';
class App extends React.Component<{}, {}>{
  public dataSource: IDataOptions = {
    columns: [{ name: 'Year', caption: 'Production Year' }, { name: 'Quarter' }],
    data: pivotData as IDataSet[],
    expandAll: false,
    filters: [],
    formatSettings: [{ name: 'Amount', format: 'C0' }],
    rows: [{ name: 'Country' }, { name: 'Products' }],
    values: [{ name: 'Sold', caption: 'Units Sold' }, { name: 'Amount', caption: 'Sold Amount' }]
  };
  public pivotGridObj: PivotViewComponent;
  render() {
    return <PivotViewComponent  ref={d => this.pivotGridObj = d!} id='PivotView' height={280} dataSource={this.dataSource} allowCalculatedField={true} showFieldList={true}><Inject services={[CalculatedField, FieldList]}/>
    </PivotViewComponent>
  }
};
ReactDOM.render(<App />, document.getElementById('pivotview'));

Run the application

The quickstart project is configured to compile and run the application in the browser. Use the following command to run the application.

npm start
Source
Preview
index.tsx
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { CalculatedField, FieldList, IDataOptions, IDataSet, Inject, PivotViewComponent } from '@syncfusion/ej2-react-pivotview';
import { pivotData } from './datasource';
class App extends React.Component<{}, {}>{
  public dataSource: IDataOptions = {
    columns: [{ name: 'Year', caption: 'Production Year' }, { name: 'Quarter' }],
    data: pivotData as IDataSet[],
    expandAll: false,
    filters: [],
    formatSettings: [{ name: 'Amount', format: 'C0' }],
    rows: [{ name: 'Country' }, { name: 'Products' }],
    values: [{ name: 'Sold', caption: 'Units Sold' }, { name: 'Amount', caption: 'Sold Amount' }]
  };
  public pivotGridObj: PivotViewComponent;
  render() {
    return <PivotViewComponent  ref={d => this.pivotGridObj = d!} id='PivotView' height={280} dataSource={this.dataSource} allowCalculatedField={true} showFieldList={true}><Inject services={[CalculatedField, FieldList]}/>
    </PivotViewComponent>
  }
};
ReactDOM.render(<App />, document.getElementById('pivotview'));
