Validation in EJ2 JavaScript Grid control

13 Apr 202324 minutes to read

Column validation

Column validation allows you to validate the edited or added row data and it display errors for invalid fields before saving data.
Grid uses Form Validator component for column validation. You can set validation rules by defining the columns.validationRules.

ej.grids.Grid.Inject(ej.grids.Edit, ej.grids.Toolbar);
var grid = new ej.grids.Grid({
    dataSource: data,
    toolbar: ['Add', 'Edit', 'Delete', 'Update', 'Cancel'],
    editSettings: { allowEditing: true, allowAdding: true, allowDeleting: true, mode: 'Normal' },
    columns: [
        { field: 'OrderID', headerText: 'Order ID', textAlign: 'Right', width: 100, isPrimaryKey: true, validationRules: { required: true } },
        { field: 'CustomerID', headerText: 'Customer ID', width: 120, validationRules: { required: true, minLength: 3 } },
        { field: 'Freight', headerText: 'Freight', textAlign: 'Right', editType: 'numericedit', width: 120, format: 'C2' },
        { field: 'ShipCountry', headerText: 'Ship Country', editType: 'dropdownedit', width: 150 }
    ],
    height: 273
});
grid.appendTo('#Grid');
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/24.2.3/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>

Custom validation

You can define your own custom validation rules for the specific columns by using Form Validator custom rules.

In the below demo, custom validation applied for CustomerID column.

var customFn = function(args) {
    return args['value'].length >= 5;
};
ej.grids.Grid.Inject(ej.grids.Edit, ej.grids.Toolbar);
var grid = new ej.grids.Grid({
    dataSource: data,
    toolbar: ['Add', 'Edit', 'Delete', 'Update', 'Cancel'],
    editSettings: { allowEditing: true, allowAdding: true, allowDeleting: true, mode: 'Normal' },
    columns: [
        { field: 'OrderID', headerText: 'Order ID', textAlign: 'Right', width: 100, isPrimaryKey: true, validationRules: { required: true } },
        { field: 'CustomerID', headerText: 'Customer ID', width: 120, validationRules: { required: true, minLength: [customFn, 'Need atleast 5 letters'] } },
        { field: 'Freight', headerText: 'Freight', textAlign: 'Right', editType: 'numericedit', width: 120, format: 'C2' },
        { field: 'ShipCountry', headerText: 'Ship Country', editType: 'dropdownedit', width: 150 }
    ],
    height: 273
});
grid.appendTo('#Grid');
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/24.2.3/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>

Custom validation based on dropdown change

You can apply validation rules and messages to a column based on another column value in edit mode. You can achieve this requirement by using the custom validation feature of Grid.

In the following sample, dropdownlist edit type is used for the Role and Salary columns. Here, you can apply the custom validation in the Salary column based on the value selected in the Role column.

var jobRole = [
    { role: 'TeamLead', destId: '0' },
    { role: 'Manager', destId: '1' },
    { role: 'Engineer', destId: '2' },
    { role: 'Sales', destId: '3' },
    { role: 'Support', destId: '4' },
];

var salaryDetails= [
    { salary: '11000', destId: '1' },
    { salary: '13500', destId: '2' },
    { salary: '16500', destId: '2' },
    { salary: '18500', destId: '1' },
    { salary: '21500', destId: '2' },
    { salary: '23000', destId: '2' },
];

var grid = new ej.grids.Grid({
    dataSource: employeeDetails,
    allowPaging: true,
    toolbar: ['Add', 'Edit', 'Delete', 'Update', 'Cancel'],
    editSettings: { allowEditing: true, allowAdding: true, allowDeleting: true },
    load: () => {
        var column = grid.getColumnByField('Salary');
        column.validationRules = {
            required: [customFn, window['Please enter valid salary']],
        };
    },
    columns: [
        {
            field: 'EmployeeID',
            headerText: 'Employee ID',
            isPrimaryKey: true,
            textAlign: 'Right',
            width: 120
        },
        {
            field: 'Role',
            headerText: 'Role',
            width: 120,
            editType: 'dropdownedit',
            edit: {
                params: {
                    query: new ej.data.Query(),
                    dataSource: jobRole,
                    fields: { value: 'role', text: 'role' },
                    allowFiltering: true,
                    change: ValChange
                }
           }
        },
        {
            field: 'Salary',
            headerText: 'Salary',
            width: 160,
            editType: 'dropdownedit',
            edit: {
                params: {
                    query: new ej.data.Query(),
                    dataSource: salaryDetails,
                    fields: { value: 'salary', text: 'salary' },
                    allowFiltering: true,
                }
            }
        },
        {
            field: 'Address',
            headerText: 'Address',
            width: 160
        }
    ]
});
grid.appendTo('#Grid');

window.role = '';

function customFn(args) {
    switch (window['role']) {
        case 'Engineer':
            if (args.value > 10000 && args.value < 15000) {
                return true;
            } else {
                this.rules['Salary']['required'][1] = 'Please enter valid Engineer Salary';
            }
        break;

        case 'TeamLead':
            if (args.value > 15000 && args.value < 20000) {
                return true;
            } else {
                this.rules['Salary']['required'][1] = 'Please enter valid TeamLead Salary';
            }
        break;

        case 'Manager':
            if (args.value > 20000 && args.value < 25000) {
                return true;
            } else {
                this.rules['Salary']['required'][1] = 'Please enter valid Manager Salary';
            }
        break;

        case 'Sales':
            if (args.value > 5000 && args.value < 25000) {
                return true;
            } else {
                this.rules['Salary']['required'][1] = 'Please enter valid Manager Salary';
            }
        break;

        case 'Support':
            if (args.value > 10000 && args.value < 19000) {
                return true;
            } else {
                this.rules['Salary']['required'][1] = 'Please enter valid Manager Salary';
            }
        break;
    }
    return false;
}

function ValChange(args) {
    window['role'] = args.value;
}
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/24.2.3/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/24.2.3/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>
