Appointments in React Schedule component
12 Jul 202424 minutes to read
Appointments can be anything that are scheduled for a specific time period. It can be created on varied time range and each appointments are categorized based on this range. The Scheduler events can be categorized as,
- Normal events
- Spanned events
- All-day events
- Recurring events
To have a quick glance on how to add appointments to the React Scheduler and some of its advanced event-handling options, watch this video:
Normal events
Represents an appointment that is created for any specific time interval within a day.
Creating a normal event
The following example depicts how to define a event on the Scheduler, with event data being loaded from simple data.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 1,
Subject: 'Paris',
StartTime: new Date(2023, 1, 15, 10, 0),
EndTime: new Date(2023, 1, 15, 12, 30),
}];
const eventSettings = { dataSource: data }
return <ScheduleComponent height='550px' selectedDate={new Date(2023, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
Id: 1,
Subject: 'Paris',
StartTime: new Date(2023, 1, 15, 10, 0),
EndTime: new Date(2023, 1, 15, 12, 30),
}];
const eventSettings: EventSettingsModel = { dataSource: data }
return <ScheduleComponent height='550px' selectedDate={new Date(2023, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Spanned events
Represents an appointment that is created for more than 24 hours, and usually displayed on the all-day row. Also, represents another type of appointment that is created for more than one day but less than 24 hours, and usually displayed appropriately on both the days.
For example, if an appointment is created for two days say from November 25, 2018 – 11.00 PM to November 26, 2018 2.00 AM but less than 24 hours time interval, then the appointment is split into two partitions and will be displayed on both the days.
All-day events
Represents an appointment that is created for an entire day such as holiday events. It is usually displayed separately in an all-day row, a separate row for all-day appointments below the date header section. In Timeline views, the all-day appointments displays in the working space area, and no separate all-day row is present in that view.
To change normal appointment into all-day event, set
isAllDay
field to true.
Hide all-day row events
You can make use of the CSS customization to prevent the display of all-day row appointments on the Scheduler UI.
<style>
.e-schedule .e-date-header-wrap .e-schedule-table thead {
display: none;
}
</style>
Expand all day appointments view on initial load
When you have larger number of appointments in all-day view, you can show all all-day events using dataBound
event on at initial load. So, user don’t have to click the toggle to expand all-day events.
import { useRef, useEffect } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, Resize, DragAndDrop } from '@syncfusion/ej2-react-schedule';
const App = () => {
const initialLoad = useRef(true);
const scheduleRef = useRef(null);
useEffect(() => {
if (initialLoad.current) {
const allDayAppointmentSection = scheduleRef.current.element.querySelector('.e-all-day-appointment-section');
if (allDayAppointmentSection) {
allDayAppointmentSection.click();
}
initialLoad.current = false;
}
}, []);
const data = [
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '2',
IsAllDay: true,
StartTime: new Date(2022, 3, 29, 0, 0),
Subject: 'Plumbing Checklist | Jaimungal | 3671 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '4',
IsAllDay: true,
StartTime: new Date(2022, 3, 28, 0, 0),
Subject: 'Underground Plumbing | Jaimungal | 3671 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 12, 30),
Id: '7',
IsAllDay: true,
StartTime: new Date(2022, 3, 24, 0, 0),
Subject: 'Steel/ Checklist | VP Highland Model | 3719 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '9',
IsAllDay: true,
StartTime: new Date(2022, 3, 29, 0, 0),
Subject: 'Tile Selections/ Pavers/ Finish | VP Highland Model | 3719 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '10',
IsAllDay: true,
StartTime: new Date(2022, 3, 26, 0, 0),
Subject: 'Layout/ Form Rebar Shell | VP Highland Model | 3719 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '10',
IsAllDay: true,
StartTime: new Date(2022, 3, 26, 0, 0),
Subject: ' VP Highland Model | 3719 :: Pool',
},
];
const eventSettings = { dataSource: data };
return (
<ScheduleComponent
height="550px"
ref={scheduleRef}
selectedDate={new Date(2022, 3, 26)}
eventSettings={eventSettings}
>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Resize]} />
</ScheduleComponent>
);
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import { useRef, useEffect } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, Resize, DragAndDrop, EventSettingsModel } from '@syncfusion/ej2-react-schedule';
const App = () => {
const initialLoad = useRef<Boolean>(true);
const scheduleRef = useRef<ScheduleComponent>(null);
useEffect(() => {
if (initialLoad.current) {
const allDayAppointmentSection = scheduleRef.current.element.querySelector('.e-all-day-appointment-section');
if (allDayAppointmentSection) {
allDayAppointmentSection.click();
}
initialLoad.current = false;
}
}, []);
const data: object[] = [
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '2',
IsAllDay: true,
StartTime: new Date(2022, 3, 29, 0, 0),
Subject: 'Plumbing Checklist | Jaimungal | 3671 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '4',
IsAllDay: true,
StartTime: new Date(2022, 3, 28, 0, 0),
Subject: 'Underground Plumbing | Jaimungal | 3671 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 12, 30),
Id: '7',
IsAllDay: true,
StartTime: new Date(2022, 3, 24, 0, 0),
Subject: 'Steel/ Checklist | VP Highland Model | 3719 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '9',
IsAllDay: true,
StartTime: new Date(2022, 3, 29, 0, 0),
Subject: 'Tile Selections/ Pavers/ Finish | VP Highland Model | 3719 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '10',
IsAllDay: true,
StartTime: new Date(2022, 3, 26, 0, 0),
Subject: 'Layout/ Form Rebar Shell | VP Highland Model | 3719 :: Pool',
},
{
EndTime: new Date(2022, 3, 30, 0, 0),
Id: '10',
IsAllDay: true,
StartTime: new Date(2022, 3, 26, 0, 0),
Subject: ' VP Highland Model | 3719 :: Pool',
},
];
const eventSettings: EventSettingsModel = { dataSource: data };
return (
<ScheduleComponent
height="550px"
ref={scheduleRef}
selectedDate={new Date(2022, 3, 26)}
eventSettings={eventSettings}
>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Resize]} />
</ScheduleComponent>
);
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Customize the rendering of the spanned events
By default, Scheduler will renders the spanned events (appointment with more than 24 hours duration) in the all-day row by setting AllDayRow
will the default type renders to the spannedEventPlacement
option within the eventSettings
property. Now we can customize rendering of the that events inside the work cells itself by modifying the spannedEventPlacement
option as TimeSlot
. In this following example, shows how to render the spanned appointments inside the work cells as follows.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 1,
Subject: 'Paris',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 17, 12, 30),
IsAllDay: false
}, {
Id: 2,
Subject: 'London',
StartTime: new Date(2018, 1, 16, 12, 0),
EndTime: new Date(2018, 1, 18, 13, 0),
IsAllDay: false
}];
const eventSettings = { dataSource: data, spannedEventPlacement: 'TimeSlot' }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
Id: 1,
Subject: 'Paris',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 17, 12, 30),
IsAllDay: false
}, {
Id: 2,
Subject: 'London',
StartTime: new Date(2018, 1, 16, 12, 0),
EndTime: new Date(2018, 1, 18, 13, 0),
IsAllDay: false
}];
const eventSettings: EventSettingsModel = { dataSource: data, spannedEventPlacement: 'TimeSlot' }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Recurring events
Represents an appointment that is created for a certain time interval and occurring repeatedly on a daily, weekly, monthly or yearly basis at the same time interval based on the provided recurrence rule. Usually, the recurring events are indicated by a repeat marker added at the bottom-right position.
Creating a recurring event
The following example depicts how to create a recurring event on Scheduler with the specific recurrence rule. In the following example, an event is made to repeat on daily mode and ends after 5 occurrences.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 2,
Subject: 'Paris',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 15, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=5',
}];
const eventSettings = { dataSource: data };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
Id: 2,
Subject: 'Paris',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 15, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=5',
}];
const eventSettings: EventSettingsModel = { dataSource: data };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Adding exceptions
A few instance of the recurrence series can be excluded on specific dates, by adding those exceptional dates to the recurrenceException
field. These date values should be given in the ISO date time format with no hyphens(-) separating the date elements.
For example, 22nd February 2018 can be represented as 20180222. Also, the time part being represented in UTC format needs to add “Z” after the time portion with no space. “07:30:00 UTC” is therefore represented as “073000Z”.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 1,
Subject: 'Paris',
StartTime: new Date(2018, 0, 28, 10, 0),
EndTime: new Date(2018, 0, 28, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=8',
RecurrenceException: '20180129T043000Z,20180131T043000Z,20180202T043000Z'
}];
const eventSettings = { dataSource: data };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 0, 28)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
Id: 1,
Subject: 'Paris',
StartTime: new Date(2018, 0, 28, 10, 0),
EndTime: new Date(2018, 0, 28, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=8',
RecurrenceException: '20180129T043000Z,20180131T043000Z,20180202T043000Z'
}];
const eventSettings: EventSettingsModel = { dataSource: data };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 0, 28)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Editing an occurrence from a series
To dynamically edit a particular occurrence from an event series and display it on the initial load of Scheduler, the edited occurrence needs to be added as a new event to the dataSource collection, with an additional recurrenceID
field defined to it. The recurrenceID
field of edited occurrence usually maps the ID value of the parent event.
In this example, a recurring instance that displays on the date 30th Jan 2018 is edited with different timings. Therefore, this particular date is excluded from the parent recurring event that repeats from 28th January 2018 to 4th February 2018. This can be done by adding the recurrenceException
field with the excluded date value on the parent event. Also, the edited occurrence event which is created as a new event should carry the . The recurrenceID
field pointing to the parent event’s Id
value.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 1,
Subject: 'Scrum Meeting',
StartTime: new Date(2018, 0, 28, 10, 0),
EndTime: new Date(2018, 0, 28, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=8',
RecurrenceException: '20180130T043000Z'
},
{
Id: 2,
Subject: 'Scrum Meeting',
StartTime: new Date(2018, 0, 30, 9, 0),
EndTime: new Date(2018, 0, 30, 10, 30),
Description: "Meeting time changed based on team activities.",
RecurrenceID: 1
}];
const eventSettings = { dataSource: data };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 0, 28)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
Id: 1,
Subject: 'Scrum Meeting',
StartTime: new Date(2018, 0, 28, 10, 0),
EndTime: new Date(2018, 0, 28, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=8',
RecurrenceException: '20180130T043000Z'
},
{
Id: 2,
Subject: 'Scrum Meeting',
StartTime: new Date(2018, 0, 30, 9, 0),
EndTime: new Date(2018, 0, 30, 10, 30),
Description: "Meeting time changed based on team activities.",
RecurrenceID: 1
}];
const eventSettings: EventSettingsModel = { dataSource: data, editFollowingEvents: true };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 0, 28)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Edit only the current and following events
To edit only the current and following events enable the property editFollowingEvents
within eventSettings
property. The edited occurrence needs to be added as a new event to the dataSource collection, with an additionalfollowingID
field defined to it. The followingID
followingID
field of edited occurrence usually maps the ID value of the immediate parent event.
In this example, a recurring instance that displays on the date 30th Jan 2018 and its following dates are edited with different subject. Therefore, this particular date and its following dates are excluded from the parent recurring event that repeats from 28th January 2018 to 4th February 2018. This can be done by updating the recurrenceRule
field with the until date value on the parent event. Also, the edited events which is created as a new event should carry the followingID
field pointing to the immediate parent event’s Id
value.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 1,
Subject: 'Scrum Meeting',
StartTime: new Date(2018, 0, 28, 10, 0),
EndTime: new Date(2018, 0, 28, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;UNTIL=20180129T043000Z;',
},
{
Id: 2,
Subject: 'Scrum Meeting - Following Edited',
StartTime: new Date(2018, 0, 30, 10, 0),
EndTime: new Date(2018, 0, 30, 12, 30),
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;UNTIL=20180204T043000Z;',
FollowingID: 1
}];
let eventSettings = { dataSource: data, editFollowingEvents: true };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 0, 28)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]}/>
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, EventSettingsModel, Inject
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
Id: 1,
Subject: 'Scrum Meeting',
StartTime: new Date(2018, 0, 28, 10, 0),
EndTime: new Date(2018, 0, 28, 12, 30),
IsAllDay: false,
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;UNTIL=20180129T043000Z;',
},
{
Id: 2,
Subject: 'Scrum Meeting - Following Edited',
StartTime: new Date(2018, 0, 30, 10, 0),
EndTime: new Date(2018, 0, 30, 12, 30),
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;UNTIL=20180204T043000Z;',
FollowingID: 1
}];
let eventSettings: EventSettingsModel = { dataSource: data, editFollowingEvents: true };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 0, 28)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Recurrence options and rules
Events can be repeated on a daily, weekly, monthly or yearly basis based on the recurrence rule which accepts the string value. The following details should be assigned to the recurrenceRule
property to generate the recurring instances.
- Repeat type - daily/weekly/monthly/yearly.
- How many times it needs to be repeated?
- The interval duration.
- The time period to render the appointment, etc.
There are four repeat types available namely,
- Daily - Creates the recurring instances on daily basis.
- Weekly - Creates the recurring instances on weekly basis for the selected days.
- Monthly - Creates the recurring instances on monthly basis for the selected months and other provided recurrence criteria.
- Yearly - Creates the recurring instances on yearly basis.
Recurrence properties
The properties based on which the recurrence appointments are created with its respective time period are depicted in the following table. Also, the valid rule string can be referred from iCalendar
specifications.
Refer
iCalendar
specifications for valid recurrence rule string.
Property | Purpose | Example |
---|---|---|
FREQ | Maintains the repeat type (Daily, Weekly, Monthly, Yearly) value of the appointment. | FREQ=DAILY;INTERVAL=1 |
INTERVAL | Maintains the interval value of the appointments. When you create the daily appointment at an interval of 2, the appointments are rendered on the days Monday, Wednesday and Friday (Creates an appointment on all days by leaving the interval of one day gap). | FREQ=DAILY;INTERVAL=2 |
COUNT | It holds the appointment’s count value. When the COUNT value is 10, then 10 instances of appointments are created in the recurrence series. | FREQ=DAILY;INTERVAL=1;COUNT=10 |
UNTIL | This property holds the end date value (in ISO format) denoting when the recurrence actually ends. | FREQ=DAILY;INTERVAL=1;UNTIL=20180530T041343Z; |
BYDAY | It holds the day value(s), representing on which the appointments actually renders. Create the weekly appointment, and select the day(s) from the day options (Monday/Tuesday/Wednesday/Thursday/Friday/Saturday/Sunday). When Monday is selected, the first two letters of the selected day “MO” is saved in the BYDAY property. When multiple days are selected, the values are separated by commas. | FREQ=WEEKLY;INTERVAL=1;BYDAY=MO,WE;COUNT=10 |
BYMONTHDAY | This property is used to store the date value of the Month, while creating the Month recurrence appointment. When you create a Monthly recurrence appointment for every 3rd day of the month, then BYMONTHDAY holds the value 3 and creates the appointment on 3rd day of every month. | FREQ=MONTHLY;BYMONTHDAY=3;INTERVAL=1;COUNT=10 |
BYMONTH | This property is used to store the index value of the selected Month while creating the yearly appointments. When you create the yearly appointment on June month, the index value of June month 6 will get stored in the BYMONTH field. The appointment is created on every 6th month of a year. | FREQ=YEARLY;BYMONTHDAY=16;BYMONTH=6;INTERVAL=1;COUNT=10 |
BYSETPOS | This property is used to store the index value of the week. When you create the monthly appointment in second week of a month, the index value of the second week (2) is stored in BYSETPOS. | FREQ=MONTHLY;BYDAY=MO;BYSETPOS=2;COUNT=10 |
The default recurrence related validation has been included for recurrence appointments similar to the one available in Outlook. The validation usually occurs during the recurrence appointment creation, editing, drag and drop or resizing of the recurrence appointments and also if any single occurrence changes.
Daily Frequency
Description | Example |
---|---|
Daily recurring event that never ends | FREQ=DAILY; INTERVAL=1 |
Daily recurring event that ends after 5 occurrences | FREQ=DAILY; INTERVAL=1; COUNT=5 |
Daily recurring event that ends exactly on 12/12/2018 | FREQ=DAILY; INTERVAL=1; UNTIL=20181212T041343Z |
Daily event that recurs on alternative days and repeats for 10 occurrences | FREQ=DAILY; INTERVAL=2; COUNT=10 |
Daily recurring appointment ends on 12/12/2018 by excluding single occurrence on 12/10/2018 | FREQ=DAILY; INTERVAL=2; UNTIL=20181212T041343Z; |
Weekly Frequency
Description | Example |
---|---|
Weekly recurring event that repeats on every Monday, Wednesday and Friday and never ends | FREQ=WEEKLY; INTERVAL=1; BYDAY=MO,WE,FR |
Repeats every week Thursday and ends after 10 occurrences | FREQ=WEEKLY; INTERVAL=1; BYDAY=TH; COUNT=10 |
Repeats every week Monday and ends on 12/12/2018 | FREQ=WEEKLY; INTERVAL=1; BYDAY=MO; UNTIL=20181212T041343Z |
Repeats on Monday, Wednesday and Friday of alternative weeks and ends after 10 occurrences | FREQ=WEEKLY; INTERVAL=2; BYDAY=MO, WE, FR; COUNT=10 |
Repeats every week on weekdays and ends after 12/12/2018 by excluding single occurrence on 12/10/2018 | FREQ=WEEKLY; BYDAY=MO, TU, WE, TH, FR; UNTIL=20181212T041343Z; |
Monthly Frequency
Description | Example |
---|---|
Monthly recurring event that repeats on every 15th day of a month and never ends | FREQ=MONTHLY; BYMONTHDAY=15; INTERVAL=1 |
Monthly recurring event that repeats on every 16th day of a month and ends after 10 occurrences | FREQ=MONTHLY; BYMONTHDAY=16; INTERVAL=1; COUNT=10 |
Repeats every 17th day of a month and ends on 12/12/2018 | FREQ=MONTHLY; BYMONTHDAY=17; INTERVAL=1; UNTIL=20181212T041343Z |
Repeats every 2nd Friday of a month and never ends | FREQ=MONTHLY; BYDAY=FR; BYSETPOS=2; INTERVAL=1 |
Repeats every 4th Wednesday of a month and ends after 10 occurrences | FREQ=MONTHLY; BYDAY=WE; BYSETPOS=4; INTERVAL=1; COUNT=10 |
Repeats every 4th Friday of a month and ends on 12/12/2018 | FREQ=MONTHLY; BYDAY=FR; BYSETPOS=4; INTERVAL=1; UNTIL=20181212T041343Z |
Yearly Frequency
Description | Example |
---|---|
Yearly event that repeats on every 15th day of December month and never ends | FREQ=YEARLY; BYMONTHDAY=15; BYMONTH=12; INTERVAL=1 |
Event that repeats on every 10th day of December month and ends after 10 occurrences | FREQ=YEARLY; BYMONTHDAY=10; BYMONTH=12; INTERVAL=1; COUNT=10 |
Repeats on every 12th day of December month and ends on 12/12/2025 | FREQ=YEARLY; BYMONTHDAY=12; BYMONTH=12; INTERVAL=1; UNTIL=20251212T041343Z |
Repeats on every 3rd Friday of December month and never ends | FREQ=YEARLY; BYDAY=FR; BYMONTH=12; BYSETPOS=3; INTERVAL=1 |
Repeats on every 3rd Tuesday of December month and ends after 10 occurrences | FREQ=YEARLY; BYDAY=TU; BYMONTH=12; BYSETPOS=3; INTERVAL=1; COUNT=10 |
Repeats on every 4th Wednesday of December month and ends on 12/12/2028 | FREQ=YEARLY; BYDAY=WE; BYMONTH=12; BYSETPOS=4; INTERVAL=1; UNTIL=20181212T041343Z |
Recurrence Validation
The built-in validation support has been added by default for recurring appointments during its creation, edit, drag and drop or resize action. The following are the possible validation alerts that displays on Scheduler while creating or editing the recurring events.
Validation messages | Description |
---|---|
The recurrence pattern is not valid. | This alert will raise, when the selected recurrence rule value is not a valid one. For example, when you try to select the end date value (using Until option) for a recurring event, which occurs before the start date, an alert will popup out saying that the chosen pattern is invalid. |
The changes made to specific instances of this series will be cancelled and those events will match the series again. | This alert will raise, when you try to edit the whole series, whose occurrence might have been already edited. For example, If there are five occurrences and one of the occurrence is already edited. Now, when you try to edit the entire series, you will get this validation alert. |
The duration of the event must be shorter than how frequently it occurs. Shorten the duration, or change the recurrence pattern in the recurrence event editor. | This validation will occur, if the event duration is longer than the selected frequency. For example, if you create a recurring appointment with two days duration in Daily frequency with no intervals set to it, you may get this alert. |
Some months have fewer than the selected date. For these months, the occurrence will fall on the last date of the month. | When you try to create a recurring appointment on 31st of every month, where few months won’t have 31 days and in this scenario, you will get this alert. |
Two occurrences of the same event cannot occur on the same day. | This validation will occur, when you try to edit or move any single occurrence to some other date, where another occurrence of the same event is already present. |
Event fields
The Scheduler dataSource usually holds the event instances, where each of the instance includes a collection of appropriate fields
. It is mandatory to map these fields with the equivalent fields of database, when remote data is bound to it. When the local JSON data is bound, then the field names defined within the instances needs to be mapped with the scheduler event fields correctly.
To create an event on Scheduler, it is enough to define the
startTime
andendTime
. Alsoid
field becomes mandatory to process CRUD actions on appropriate events.
Built-in fields
The built-in fields available on Scheduler event object are as follows.
Field name | Description |
---|---|
id | The id field needs to be defined as mandatory and this field usually assigns a unique ID value to each of the events. |
subject | The subject field is optional, and usually assigns the summary text to each of the events. |
startTime | The startTime field defines the start time of an event and it is mandatory to provide it for any of the valid event objects. |
endTime | The endTime field defines the end time of an event and it is mandatory to provide the end time for any of the valid event objects. |
startTimezone | It maps the startTimezone field from the dataSource and usually accepts the valid IANA timezone names. It is assumed that the value provided for this field is taken into consideration while processing the startTime field. When this field is not mapped with any timezone names, then the events will be processed based on the timezone assigned to the Scheduler. |
endTimezone | It maps the endTimezone field from the dataSource and usually accepts the valid IANA timezone names. It is assumed that the value provided for this field is taken into consideration while processing the endTime field. When this field is not mapped with any timezone names, then the events will be processed based on the timezone assigned to the Scheduler. |
location | It maps the location field from the dataSource and the location text value will be displayed over the events. |
description | It maps the description field from the dataSource and denotes the event description which is optional. |
isAllDay | The isAllDay field is mapped from the dataSource and is used to denote whether an event is created for an entire day or for specific time alone. Usually, an event with isAllDay field set to true will be considered as an all-day event. |
recurrenceID | It maps the recurrenceID field from dataSource and usually holds the ID value of the parent recurrence event. This field is applicable only for the edited occurrence events. |
recurrenceRule | It maps the recurrenceRule field from dataSource and holds the recurrence rule value in a string format. Also, it uniquely identifies whether the event belongs to a recurring type or normal ones. |
recurrenceException | It maps the recurrenceException field from dataSource and is used to hold the collection of exception dates, on which the recurring occurrences needs to be excluded. The recurrenceException should be specified in UTC format. |
isReadonly | It maps the isReadonly field from dataSource. It is mainly used to make specific appointments as readonly when set to true . |
isBlock | It maps the isBlock field from dataSource. It is used to block the particular time ranges in the Scheduler and prevents the event creation on those time slots. |
Binding different field names
When the fields of event instances has the default mapping name, it is not mandatory to map them manually. If a Scheduler’s dataSource holds the events collection with different field names, then it is necessary to map them with its equivalent field name within the eventSettings
property.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
TravelId: 2,
TravelSummary: 'Paris',
DepartureTime: new Date(2018, 1, 15, 10, 0),
ArrivalTime: new Date(2018, 1, 15, 12, 30),
FullDay: false,
Source: 'London',
Comments: 'Summer vacation planned for outstation.',
Origin: 'Asia/Yekaterinburg',
Destination: 'Asia/Yekaterinburg'
}];
const fieldsData = {
id: 'TravelId',
subject: { name: 'TravelSummary' },
isAllDay: { name: 'FullDay' },
location: { name: 'Source' },
description: { name: 'Comments' },
startTime: { name: 'DepartureTime' },
endTime: { name: 'ArrivalTime' },
startTimezone: { name: 'Origin' },
endTimezone: { name: 'Destination' }
}
const eventSettings = { dataSource: data, fields: fieldsData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
TravelId: 2,
TravelSummary: 'Paris',
DepartureTime: new Date(2018, 1, 15, 10, 0),
ArrivalTime: new Date(2018, 1, 15, 12, 30),
FullDay: false,
Source: 'London',
Comments: 'Summer vacation planned for outstation.',
Origin: 'Asia/Yekaterinburg',
Destination: 'Asia/Yekaterinburg'
}];
const fieldsData = {
id: 'TravelId',
subject: { name: 'TravelSummary' },
isAllDay: { name: 'FullDay' },
location: { name: 'Source' },
description: { name: 'Comments' },
startTime: { name: 'DepartureTime' },
endTime: { name: 'ArrivalTime' },
startTimezone: { name: 'Origin' },
endTimezone: { name: 'Destination' }
}
const eventSettings: EventSettingsModel = { dataSource: data, fields: fieldsData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
The mapper field id is of string type and has no additional validation options, whereas all other fields are of
Object
type and has additional options.
Event field settings
Each field of the Scheduler events are provided with additional settings such as options to set default value, to map with appropriate data source fields, to validate every event fields and to provide label values for those fields in the event window.
Options | Description |
---|---|
default | Accepts the default value to the applicable fields (Subject, Location and Description), when no values are provided to them from dataSource. |
name | Accepts the field name to be mapped from the dataSource fields. |
title | Accepts the label values to be displayed for the fields of event editor. |
validation | Defines the validation rules to be applied on the event fields within the event editor. |
In following example, the Subject field in event editor will display its appropriate label as Summary. When no subject value is provided while saving an event, then the appointment will be saved with the default subject value as Add Summary.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
TravelId: 2,
TravelSummary: 'Paris',
DepartureTime: new Date(2018, 1, 15, 10, 0),
ArrivalTime: new Date(2018, 1, 15, 12, 30),
Source: 'London',
Comments: 'Summer vacation planned for outstation.'
}];
const fieldsData = {
id: 'TravelId',
subject: { name: 'TravelSummary', title: 'Summary', default: 'Add Summary' },
location: { name: 'Source', default: 'USA' },
description: { name: 'Comments' },
startTime: { name: 'DepartureTime' },
endTime: { name: 'ArrivalTime' }
}
const eventSettings = { dataSource: data, fields: fieldsData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: object[] = [{
TravelId: 2,
TravelSummary: 'Paris',
DepartureTime: new Date(2018, 1, 15, 10, 0),
ArrivalTime: new Date(2018, 1, 15, 12, 30),
Source: 'London',
Comments: 'Summer vacation planned for outstation.'
}];
const fieldsData = {
id: 'TravelId',
subject: { name: 'TravelSummary', title: 'Summary', default: 'Add Summary' },
location: { name: 'Source', default: 'USA' },
description: { name: 'Comments' },
startTime: { name: 'DepartureTime' },
endTime: { name: 'ArrivalTime' }
}
const eventSettings: EventSettingsModel = { dataSource: data, fields: fieldsData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Adding Custom fields
Apart from the default Scheduler fields, the user can include ‘n’ number of custom fields for appointments. The following code example shows how to include two custom fields namely Status and Priority within event collection. It is not necessary to bind the custom fields within the eventSettings
. However, those additional fields can be accessed easily, for internal processing as well as from application end.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 2,
Subject: 'Meeting',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 15, 12, 30),
IsAllDay: false,
Status: 'Completed',
Priority: 'High'
}];
const fieldsData = {
id: 'Id',
subject: { name: 'Subject' },
isAllDay: { name: 'IsAllDay' },
startTime: { name: 'StartTime' },
endTime: { name: 'EndTime' }
}
const eventSettings = { dataSource: data, fields: fieldsData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: Object[] = [{
Id: 2,
Subject: 'Meeting',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 15, 12, 30),
IsAllDay: false,
Status: 'Completed',
Priority: 'High'
}];
const fieldsData = {
id: 'Id',
subject: { name: 'Subject' },
isAllDay: { name: 'IsAllDay' },
startTime: { name: 'StartTime' },
endTime: { name: 'EndTime' }
}
const eventSettings: EventSettingsModel = { dataSource: data, fields: fieldsData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Customize the order of the overlapping events
By default, the scheduler will render the overlapping events based on the start and end time. Now we can customize the order of the overlapping events based on the custom fields by using the sortComparer
property grouped under the eventSettings
property. The following code example shows how to sort the appointments based on the custom field as follows.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const comparerFun = (args) => {
args.sort((event1, event2) => event1.RankId.localeCompare(event2.RankId, undefined, { numeric: true }));
return args;
}
const data = [{
Id: 1,
Subject: 'Rank 1',
StartTime: new Date(2017, 9, 29, 10, 0),
EndTime: new Date(2017, 9, 29, 11, 30),
IsAllDay: false,
RankId: '1'
}, {
Id: 2,
Subject: 'Rank 3',
StartTime: new Date(2017, 9, 29, 10, 30),
EndTime: new Date(2017, 9, 29, 12, 30),
IsAllDay: false,
RankId: '3'
}, {
Id: 3,
Subject: 'Rank 6',
StartTime: new Date(2017, 9, 29, 7, 0),
EndTime: new Date(2017, 9, 29, 14, 30),
IsAllDay: false,
RankId: '6'
}, {
Id: 4,
Subject: 'Rank 9',
StartTime: new Date(2017, 9, 29, 11, 0),
EndTime: new Date(2017, 9, 29, 15, 30),
IsAllDay: false,
RankId: '9'
}];
const eventSettings = { dataSource: data, sortComparer: comparerFun }
return <ScheduleComponent height='550px' selectedDate={new Date(2017, 9, 29)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const comparerFun = (args: Record<string, any>[]) => {
args.sort((event1: Record<string, any>, event2: Record<string, any>) => event1.RankId.localeCompare(event2.RankId, undefined, { numeric: true }));
return args;
}
const data: Object[] = [{
Id: 1,
Subject: 'Rank 1',
StartTime: new Date(2017, 9, 29, 10, 0),
EndTime: new Date(2017, 9, 29, 11, 30),
IsAllDay: false,
RankId: '1'
}, {
Id: 2,
Subject: 'Rank 3',
StartTime: new Date(2017, 9, 29, 10, 30),
EndTime: new Date(2017, 9, 29, 12, 30),
IsAllDay: false,
RankId: '3'
}, {
Id: 3,
Subject: 'Rank 6',
StartTime: new Date(2017, 9, 29, 7, 0),
EndTime: new Date(2017, 9, 29, 14, 30),
IsAllDay: false,
RankId: '6'
}, {
Id: 4,
Subject: 'Rank 9',
StartTime: new Date(2017, 9, 29, 11, 0),
EndTime: new Date(2017, 9, 29, 15, 30),
IsAllDay: false,
RankId: '9'
}];
const eventSettings: EventSettingsModel = { dataSource: data, sortComparer: comparerFun }
return <ScheduleComponent height='550px' selectedDate={new Date(2017, 9, 29)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Drag and drop appointments
Appointments can be rescheduled to any time by dragging and dropping them onto the desired location. To work with drag and drop functionality, it is necessary to inject the module DragAndDrop
and make sure that allowDragAndDrop
is set to true
on Scheduler. In mobile mode, you can drag and drop the events by tap holding an event and dropping them on to the desired location.
Learn the advanced options of Drag and Resize actions for React Scheduler from this video:
By default, drag and drop action is applicable on all Scheduler views, except Agenda, Month-Agenda and Year view.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, TimelineViews, TimelineMonth, Month, Agenda, DragAndDrop, ViewsDirective, ViewDirective, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='TimelineDay' />
<ViewDirective option='Day' />
<ViewDirective option='Week' />
<ViewDirective option='TimelineMonth' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, TimelineViews, TimelineMonth, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, TimelineViews, TimelineMonth, Month, Agenda, DragAndDrop, ViewsDirective, ViewDirective, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='TimelineDay' />
<ViewDirective option='Day' />
<ViewDirective option='Week' />
<ViewDirective option='TimelineMonth' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, TimelineViews, TimelineMonth, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Drag and drop multiple appointments
We can drag and drop multiple appointments by enabling the allowMultiDrag
property. We can select multiple appointments by holding the CTRL key. Once the events are selected, we can leave the CTRL key and start dragging the event.
We can also drag multiple events from one resource to another resource. In this case, if all the selected events are in the different resources, then all the events should be moved to the single resource that is related to the target event.
Note: Multiple events drag and drop is not supported on mobile devices.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} allowMultiDrag={true} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]}/>
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} allowMultiDrag={true} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Disable the drag action
By default, you can drag and drop the events within any of the applicable scheduler views, and to disable it, set false
to the allowMultiDrag
property.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} allowDragAndDrop={false} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]}/>
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} allowDragAndDrop={false} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Preventing drag and drop on specific targets
It is possible to prevent the drag action on particular target, by passing the target to be excluded in the excludeSelectors
option within dragStart
event. In the following example, we have prevented the drag action on all-day row.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args) => {
args.excludeSelectors = 'e-header-cells,e-header-day,e-header-date,e-all-day-cells';
}
const eventSettings = { dataSource: scheduleData };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, DragEventArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args: DragEventArgs): void => {
args.excludeSelectors = 'e-header-cells,e-header-day,e-header-date,e-all-day-cells';
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData };
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Disable scrolling on drag action
By default, while dragging an appointment to the edges, either top or bottom of the Scheduler, scrolling action takes place automatically. To prevent this scrolling, set false
to the scroll
value within the dragStart
event arguments.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args) => {
args.scroll = { enable: false };
}
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, DragEventArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args: DragEventArgs): void => {
args.scroll = { enable: false };
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Controlling scroll speed while dragging an event
The speed of the scrolling action while dragging an appointment to the Scheduler edges, can be controlled within the dragStart
event by setting the desired value to the scrollBy
and timeDelay
option whereas its default value is 30 minutes and 100ms.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args) => {
args.scroll = { enable: true, scrollBy: 5, timeDelay: 200 };
}
const eventSettings = { dataSource: scheduleData}
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, DragEventArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args: DragEventArgs): void => {
args.scroll = { enable: true, scrollBy: 5, timeDelay: 200 };
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Auto navigation of date ranges on dragging an event
When an event is dragged either to the left or right extreme edges of the Scheduler and kept hold for few seconds without dropping, the auto navigation of date ranges will be enabled allowing the Scheduler to navigate from current date range to back and forth respectively. This action is set to false
by default and to enable it, you need to set navigation
to true within the dragStart
event.
By default, the navigation delay is set to 2000ms. The navigation delay decides how long the user needs to drag and hold the appointments at the extremities. You can also set your own delay value for letting the users to navigate based on it, using the timeDelay
within the dragStart
event.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args) => {
args.navigation = { enable: true, timeDelay: 4000 };
}
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, DragEventArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args: DragEventArgs): void => {
args.navigation = { enable: true, timeDelay: 4000 }
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Setting drag time interval
By default, while dragging an appointment, it moves at an interval of 30 minutes. To change the dragging time interval, pass the appropriate values to the interval
option within the dragStart
event.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args) => {
args.interval = 10;
}
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, DragEventArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onDragStart = (args: DragEventArgs): void => {
args.interval = 10;
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStart={(onDragStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Drag and drop items from external source
It is possible to drag and drop the unplanned items from any of the external source into the scheduler, by manually saving those dropped item as a new appointment data through addEvent
method of Scheduler.
In this example, we have used the tree view control as an external source and the child nodes from the tree view component are dragged and dropped onto the Scheduler. Therefore, it is necessary to make use of the nodeDragStop
event of the TreeView component, where we can form an event object and save it using the addEvent
method.
Learn how to drag an external item into the React Scheduler by watching this video:
import * as ReactDOM from 'react-dom';
import * as React from 'react';
import { useRef } from 'react';
import { ScheduleComponent, ViewsDirective, ViewDirective, Inject, TimelineViews, Resize, DragAndDrop } from '@syncfusion/ej2-react-schedule';
import { eventData, waitingList } from './datasource';
import { closest, remove, addClass } from '@syncfusion/ej2-base';
import { TreeViewComponent } from '@syncfusion/ej2-react-navigations';
const App = () => {
const scheduleObj = useRef(null);
const treeObj = useRef(null);
let isTreeItemDropped = false;
let draggedItemId = '';
let allowDragAndDrops = true;
const fields = { dataSource: waitingList, id: 'Id', text: 'Name' };
const fieldsData = {
subject: { title: 'Patient Name', name: 'Name' },
startTime: { title: "From", name: "StartTime" },
endTime: { title: "To", name: "EndTime" },
description: { title: 'Reason', name: 'Description' }
}
const eventSettings = { dataSource: eventData, fields: fieldsData };
const treeTemplate = (props) => {
return (<div id="waiting"><div id="waitdetails"><div id="waitlist">{props.Name}</div>
<div id="waitcategory">{props.DepartmentName}</div></div></div>);
}
const onItemDrag = (event) => {
if (scheduleObj.current.isAdaptive) {
let classElement = scheduleObj.current.element.querySelector('.e-device-hover');
if (classElement) {
classElement.classList.remove('e-device-hover');
}
if (event.target.classList.contains('e-work-cells')) {
addClass([event.target], 'e-device-hover');
}
}
if (document.body.style.cursor === 'not-allowed') {
document.body.style.cursor = '';
}
if (event.name === 'nodeDragging') {
let dragElementIcon = document.querySelectorAll('.e-drag-item.treeview-external-drag .e-icon-expandable');
for (let i = 0; i < dragElementIcon.length; i++) {
dragElementIcon[i].style.display = 'none';
}
}
}
const onActionBegin = (event) => {
if (event.requestType === 'eventCreate' && isTreeItemDropped) {
let treeViewdata = treeObj.current.fields.dataSource;
const filteredPeople = treeViewdata.filter((item) => item.Id !== parseInt(draggedItemId, 10));
treeObj.current.fields.dataSource = filteredPeople;
let elements = document.querySelectorAll('.e-drag-item.treeview-external-drag');
for (let i = 0; i < elements.length; i++) {
remove(elements[i]);
}
}
}
const onTreeDragStop = (event) => {
let treeElement = closest(event.target, '.e-treeview');
let classElement = scheduleObj.current.element.querySelector('.e-device-hover');
if (classElement) {
classElement.classList.remove('e-device-hover');
}
if (!treeElement) {
event.cancel = true;
let scheduleElement = closest(event.target, '.e-content-wrap');
if (scheduleElement) {
let treeviewData = treeObj.current.fields.dataSource;
if (event.target.classList.contains('e-work-cells')) {
const filteredData = treeviewData.filter((item) => item.Id === parseInt(event.draggedNodeData.id, 10));
let cellData = scheduleObj.current.getCellDetails(event.target);
let eventData = {
Name: filteredData[0].Name,
StartTime: cellData.startTime,
EndTime: cellData.endTime,
IsAllDay: cellData.isAllDay,
Description: filteredData[0].Description
};
scheduleObj.current.addEvent(eventData);
isTreeItemDropped = true;
draggedItemId = event.draggedNodeData.id;
}
}
}
}
return (<div className='schedule-control-section'>
<div className='col-lg-12 control-section'>
<div className='content-wrapper'>
<div className="schedule-container">
<div className="title-container">
<div className="title-text">Scheduler</div>
</div>
<ScheduleComponent ref={scheduleObj} cssClass='schedule-drag-drop' width='100%' height='650px' selectedDate={new Date(2018, 7, 1)} currentView='TimelineDay' eventSettings={eventSettings} actionBegin={onActionBegin} drag={onItemDrag}>
<ViewsDirective>
<ViewDirective option='TimelineDay' />
</ViewsDirective>
<Inject services={[TimelineViews, Resize, DragAndDrop]} />
</ScheduleComponent>
</div>
<div className="treeview-container">
<div className="title-container">
<div className="title-text">Waiting List</div>
</div>
<TreeViewComponent ref={treeObj} cssClass='treeview-external-drag' nodeTemplate={treeTemplate} fields={fields} nodeDragStop={onTreeDragStop} nodeDragging={onItemDrag} allowDragAndDrop={allowDragAndDrops} />
</div>
</div>
</div>
</div>);
}
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as ReactDOM from 'react-dom';
import * as React from 'react';
import { useRef } from 'react';
import {
ScheduleComponent, ViewsDirective, ViewDirective, Inject, TimelineViews,
Resize, DragAndDrop, ActionEventArgs, CellClickEventArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { eventData, waitingList } from './datasource';
import { closest, remove, addClass } from '@syncfusion/ej2-base';
import { DragAndDropEventArgs } from '@syncfusion/ej2-navigations';
import { TreeViewComponent } from '@syncfusion/ej2-react-navigations';
const App = () => {
const scheduleObj = useRef<ScheduleComponent>(null);
const treeObj = useRef<TreeViewComponent>(null);
let isTreeItemDropped: boolean = false;
let draggedItemId: string = '';
let allowDragAndDrops: boolean = true;
const fields: Object = { dataSource: waitingList, id: 'Id', text: 'Name' };
const fieldsData = {
subject: { title: 'Patient Name', name: 'Name' },
startTime: { title: "From", name: "StartTime" },
endTime: { title: "To", name: "EndTime" },
description: { title: 'Reason', name: 'Description' }
}
const eventSettings: EventSettingsModel = { dataSource: eventData, fields: fieldsData };
const treeTemplate = (props: any): JSX.Element => {
return (<div id="waiting"><div id="waitdetails"><div id="waitlist">{props.Name}</div>
<div id="waitcategory">{props.DepartmentName}</div></div></div>);
}
const onItemDrag = (event: any): void => {
if (scheduleObj.current.isAdaptive) {
let classElement: HTMLElement = scheduleObj.current.element.querySelector('.e-device-hover');
if (classElement) {
classElement.classList.remove('e-device-hover');
}
if (event.target.classList.contains('e-work-cells')) {
addClass([event.target], 'e-device-hover');
}
}
if (document.body.style.cursor === 'not-allowed') {
document.body.style.cursor = '';
}
if (event.name === 'nodeDragging') {
let dragElementIcon: NodeListOf<HTMLElement> =
document.querySelectorAll('.e-drag-item.treeview-external-drag .e-icon-expandable');
for (let i: number = 0; i < dragElementIcon.length; i++) {
dragElementIcon[i].style.display = 'none';
}
}
}
const onActionBegin = (event: ActionEventArgs): void => {
if (event.requestType === 'eventCreate' && isTreeItemDropped) {
let treeViewdata: { [key: string]: Object }[] = treeObj.current.fields.dataSource as { [key: string]: Object }[];
const filteredPeople: { [key: string]: Object }[] =
treeViewdata.filter((item: any) => item.Id !== parseInt(draggedItemId, 10));
treeObj.current.fields.dataSource = filteredPeople;
let elements: NodeListOf<HTMLElement> = document.querySelectorAll('.e-drag-item.treeview-external-drag');
for (let i: number = 0; i < elements.length; i++) {
remove(elements[i]);
}
}
}
const onTreeDragStop = (event: DragAndDropEventArgs): void => {
let treeElement: Element = closest(event.target, '.e-treeview');
let classElement: HTMLElement = scheduleObj.current.element.querySelector('.e-device-hover');
if (classElement) {
classElement.classList.remove('e-device-hover');
}
if (!treeElement) {
event.cancel = true;
let scheduleElement: Element = closest(event.target, '.e-content-wrap');
if (scheduleElement) {
let treeviewData: { [key: string]: Object }[] =
treeObj.current.fields.dataSource as { [key: string]: Object }[];
if (event.target.classList.contains('e-work-cells')) {
const filteredData: { [key: string]: Object }[] =
treeviewData.filter((item: any) => item.Id === parseInt(event.draggedNodeData.id as string, 10));
let cellData: CellClickEventArgs = scheduleObj.current.getCellDetails(event.target);
let eventData: { [key: string]: Object } = {
Name: filteredData[0].Name,
StartTime: cellData.startTime,
EndTime: cellData.endTime,
IsAllDay: cellData.isAllDay,
Description: filteredData[0].Description
};
scheduleObj.current.addEvent(eventData);
isTreeItemDropped = true;
draggedItemId = event.draggedNodeData.id as string;
}
}
}
}
return (
<div className='schedule-control-section'>
<div className='col-lg-12 control-section'>
<div className='content-wrapper'>
<div className="schedule-container">
<div className="title-container">
<div className="title-text">Scheduler</div>
</div>
<ScheduleComponent ref={scheduleObj} cssClass='schedule-drag-drop' width='100%' height='650px' selectedDate={new Date(2018, 7, 1)}
currentView='TimelineDay'
eventSettings={eventSettings}
actionBegin={onActionBegin} drag={onItemDrag} >
<ViewsDirective>
<ViewDirective option='TimelineDay' />
</ViewsDirective>
<Inject services={[TimelineViews, Resize, DragAndDrop]} />
</ScheduleComponent>
</div>
<div className="treeview-container">
<div className="title-container">
<div className="title-text">Waiting List</div>
</div>
<TreeViewComponent ref={treeObj} cssClass='treeview-external-drag' nodeTemplate={treeTemplate} fields={fields} nodeDragStop={onTreeDragStop} nodeDragging={onItemDrag} allowDragAndDrop={allowDragAndDrops} />
</div>
</div>
</div>
</div>
);
}
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Opening the editor window on drag stop
There are scenarios where you want to open the editor filled with data on newly dropped location and may need to proceed to save it, only when Save
button is clicked on the editor. On clicking the cancel button should revert these changes. This can be achieved using the dragStop
event of Scheduler.
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef(null);
const onDragStop = (args) => {
args.cancel = true; //cancels the drop action
scheduleObj.current.openEditor(args.data, "Save"); //open the event window with updated start and end time
}
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStop={(onDragStop)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, DragAndDrop, Inject, DragEventArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef<ScheduleComponent>(null);
const onDragStop = (args: DragEventArgs): void => {
args.cancel = true; //cancels the drop action
scheduleObj.current.openEditor(args.data, "Save"); //open the event window with updated start and end time
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} dragStop={(onDragStop)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, DragAndDrop]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Inline Appointment
In Scheduler, another easier way for adding
or editing
the appointment’s subject alone can be achieved by using the inline Add/Edit support. It allows the user to add and edit the appointments inline. To get familiar with the inline Add mode, single click on any of the Scheduler cells or press enter key on the selected cells.
When the inline adding mode is ON, a text box will get created within the clicked Scheduler cells with a blinking cursor in it, requiring the user to enter the subject of an appointment. Once the subject is entered, the appointment will be saved on pressing the enter key.
To enable the inline edit mode, single click on any of the existing appointment’s subject, so that the user can edit the subject of that appointment. The edited subject of that appointment will be updated on pressing the enter key.
The inline option can be enabled/disabled on the Scheduler by using the allowInline API, whereas its default value is set to false.
While using the allowInline
the showQuickInfo
will be turned off. The quickPopup
will not show on clicking the work cell or clicking the appointment when the allowInline
property is set to true
.
In work cells, select multiple cells using keyboard, and then press enter key. The appointment wrapper will be created, and focus will be on the subject field. Also, consider the overlapping scenarios when creating an inline event.
Normal Event
While editing appointments, single-click the appointment subject, the editable
option will be enabled in UI and the cursor will focus at the end of the text. Inline editing will be considered for all possible views.
Recurrence Event
While editing the occurrence from the recurrence series, it is only possible to edit a single occurrence
, not an entire series.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Agenda, Month, Inject, ViewsDirective, ViewDirective } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent width='100%' height='550px' currentView='Month' selectedDate={new Date(2018, 1, 17)} allowInline={true} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Day' />
<ViewDirective option='Week' />
<ViewDirective option='WorkWeek' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, WorkWeek, Agenda, Month]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Agenda, Month, Inject, EventSettingsModel,
ViewsDirective, ViewDirective
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent width='100%' height='550px' currentView='Month'
selectedDate={new Date(2018, 1, 17)} allowInline={true} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Day' />
<ViewDirective option='Week' />
<ViewDirective option='WorkWeek' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, WorkWeek, Agenda, Month]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Appointment Resizing
Another way of rescheduling an appointment can be done by resizing it through either of its handlers. To work with resizing functionality, it is necessary to inject the module Resize
and make sure that allowResizing
property is set to true.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, TimelineViews, TimelineMonth, Month, Agenda, Resize, ViewsDirective, ViewDirective, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Day' />
<ViewDirective option='TimelineWeek' />
<ViewDirective option='Week' />
<ViewDirective option='TimelineMonth' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, TimelineViews, TimelineMonth, Month, Agenda, Resize]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, TimelineViews, TimelineMonth, Month, Agenda, Resize, ViewsDirective, ViewDirective, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Day' />
<ViewDirective option='TimelineWeek' />
<ViewDirective option='Week' />
<ViewDirective option='TimelineMonth' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, TimelineViews, TimelineMonth, Month, Agenda, Resize]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Disable the resize action
By default, resizing of events is allowed on all Scheduler views except Agenda and Month-Agenda view. To disable this event resizing action, set false
to the allowResizing
property.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} allowResizing={false} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} allowResizing={false} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Disable scrolling on resize action
By default, while resizing an appointment, when its handler reaches the extreme edges of the Scheduler, scrolling action will takes place along with event resizing. To prevent this scrolling action, set false
to scroll value within the resizeStart
event.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onResizeStart = (args) => {
args.scroll = { enable: false };
}
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} resizeStart={onResizeStart}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, ResizeEventArgs, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onResizeStart = (args: ResizeEventArgs): void => {
args.scroll = { enable: false };
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} resizeStart={onResizeStart}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Controlling scroll speed while resizing an event
The speed of the scrolling action while resizing an appointment to the Scheduler edges, can be controlled within the resizeStart
event by setting the desired value to the scrollBy
option.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onResizeStart = (args) => {
args.scroll = { enable: true, scrollBy: 15 };
}
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} resizeStart={onResizeStart}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, ResizeEventArgs, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onResizeStart = (args: ResizeEventArgs): void => {
args.scroll = { enable: true, scrollBy: 15 };
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} resizeStart={onResizeStart}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Setting resize time interval
By default, while resizing an appointment, it extends or shrinks at an interval of 30 minutes. To change this default resize interval, set appropriate values to interval
option within the resizeStart
event.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onResizeStart = (args) => {
args.interval = 10;
}
const eventSettings = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} resizeStart={(onResizeStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>;
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Resize, ResizeEventArgs, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const onResizeStart = (args: ResizeEventArgs): void => {
args.interval = 10;
}
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return <ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} resizeStart={(onResizeStart)}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda, Resize]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Appointment customization
The look and feel of the Scheduler events can be customized using any one of the following ways.
Using template
Any kind of text, images and links can be added to customize the look of the events. The user can format and change the default appearance of the events by making use of the template
option available within the eventSettings
property. The following code example customizes the appointment’s default color and time format.
Learn how easily you can customize the basic look and feel of React Scheduler appointments using template from this video:
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject
} from '@syncfusion/ej2-react-schedule';
import { webinarData } from './datasource';
import { Internationalization } from '@syncfusion/ej2-base';
const App = () => {
const instance = new Internationalization();
const getTimeString = (value) => {
return instance.formatDate(value, { skeleton: 'hm' });
}
const eventTemplate = (props) => {
const secondaryColor = { background: props.SecondaryColor };
const primaryColor_1 = { background: props.PrimaryColor };
const primaryColor_2 = { background: props.PrimaryColor };
return (<div className="template-wrap" style={secondaryColor}>
<div className="subject" style={primaryColor_1}>{props.Subject}</div>
<div className="time" style={primaryColor_2}>
Time: {getTimeString(props.StartTime)} - {getTimeString(props.EndTime)}</div>
</div>);
}
const eventSettings = { dataSource: webinarData, template: eventTemplate };
return <ScheduleComponent width='100%' height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} readonly={true}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { webinarData } from './datasource';
import { Internationalization } from '@syncfusion/ej2-base';
const App = () => {
const instance: Internationalization = new Internationalization();
const getTimeString = (value: Date) => {
return instance.formatDate(value, { skeleton: 'hm' });
}
const eventTemplate = (props) => {
const secondaryColor = { background: props.SecondaryColor };
const primaryColor_1 = { background: props.PrimaryColor };
const primaryColor_2 = { background: props.PrimaryColor }
return (<div className="template-wrap" style={secondaryColor}>
<div className="subject" style={primaryColor_1}>{props.Subject}</div>
<div className="time" style={primaryColor_2}>
Time: {getTimeString(props.StartTime)} - {getTimeString(props.EndTime)}</div>
</div>);
}
const eventSettings: EventSettingsModel = { dataSource: webinarData, template: eventTemplate };
return <ScheduleComponent width='100%' height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} readonly={true}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<link href="index.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
All the built-in fields that are mapped to the appropriate field properties within the
eventSettings
, as well as custom mapped fields from the Scheduler dataSource can be accessed within the template code.
Using eventRendered event
The eventRendered
event triggers before the appointment renders on the Scheduler. Therefore, this client-side event can be utilized to customize the look of events based on any specific criteria, before rendering them on the scheduler.
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef(null);
const eventSettings = { dataSource: scheduleData }
const onEventRendered = (args) => {
applyCategoryColor(args, scheduleObj.current.currentView);
}
const applyCategoryColor = (args, currentView) => {
let categoryColor = args.data.CategoryColor;
if (!args.element || !categoryColor) {
return;
}
if (currentView === 'Agenda') {
args.element.firstChild.style.borderLeftColor = categoryColor;
}
else {
args.element.style.backgroundColor = categoryColor;
}
}
return (<ScheduleComponent width='100%' height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} eventRendered={onEventRendered}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventRenderedArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef<ScheduleComponent>(null);
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
const onEventRendered = (args: EventRenderedArgs): void => {
applyCategoryColor(args, scheduleObj.current.currentView);
}
const applyCategoryColor = (args: EventRenderedArgs, currentView: string): void => {
let categoryColor: string = args.data.CategoryColor as string;
if (!args.element || !categoryColor) {
return;
}
if (currentView === 'Agenda') {
(args.element.firstChild as HTMLElement).style.borderLeftColor = categoryColor;
} else {
args.element.style.backgroundColor = categoryColor;
}
}
return (
<ScheduleComponent width='100%' height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} eventRendered={onEventRendered}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Using cssClass
The customization of events can also be achieved using cssClass
property of the Scheduler. In the following example, the background of appointments has been changed using the cssClass.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return (<ScheduleComponent width='100%' height='550px' cssClass='custom-class' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return (
<ScheduleComponent width='100%' height='550px' cssClass='custom-class' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Setting minimum height
It is possible to set minimal height for appointments on Scheduler using eventRendered
event, when its start and end time duration is less than the default duration of a single slot.
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const scheduleObj = useRef(null);
const data = [{
Id: 13,
Subject: 'Myths of Andromeda Galaxy',
StartTime: new Date(2018, 1, 16, 10, 30),
EndTime: new Date(2018, 1, 16, 10, 40)
}, {
Id: 14,
Subject: 'Aliens vs Humans',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 15, 10, 20)
}];
const eventSettings = { dataSource: data }
const onEventRendered = (args) => {
let cellHeight = scheduleObj.current.element.querySelector('.e-work-cells').offsetHeight;
let appHeight = (args.data.EndTime.getTime() - args.data.StartTime.getTime()) / (60 * 1000) * (cellHeight * scheduleObj.current.timeScale.slotCount) / scheduleObj.current.timeScale.interval;
args.element.style.height = appHeight + 'px';
}
return (
<ScheduleComponent width='100%' height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} eventRendered={onEventRendered}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventRenderedArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const scheduleObj = useRef<ScheduleComponent>(null);
const data: Object[] = [{
Id: 13,
Subject: 'Myths of Andromeda Galaxy',
StartTime: new Date(2018, 1, 16, 10, 30),
EndTime: new Date(2018, 1, 16, 10, 40)
}, {
Id: 14,
Subject: 'Aliens vs Humans',
StartTime: new Date(2018, 1, 15, 10, 0),
EndTime: new Date(2018, 1, 15, 10, 20)
}];
const eventSettings: EventSettingsModel = { dataSource: data }
const onEventRendered = (args: EventRenderedArgs): void => {
let cellHeight: number = (scheduleObj.current.element.querySelector('.e-work-cells') as HTMLElement).offsetHeight;
let appHeight: number = ((args.data.EndTime as Date).getTime() - (args.data.StartTime as Date).getTime()) / (60 * 1000) * (cellHeight * scheduleObj.current.timeScale.slotCount) / scheduleObj.current.timeScale.interval;
args.element.style.height = appHeight + 'px';
}
return (
<ScheduleComponent width='100%' height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} eventRendered={onEventRendered}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Block Dates and Times
It is possible to block a set of dates or a particular time ranges on the Scheduler. To do so, define an appointment object within eventSettings
along with the required time range to block and set the isBlock
field to true. Usually, the event objects defined with isBlock field set to true will block the entire time cells lying within the appropriate time ranges specified through startTime
and endTime
fields.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { blockData } from './datasource';
const App = () => {
const eventSettings = { dataSource: blockData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { blockData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: blockData }
return (
<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Block events can also be defined to repeat on several days as shown in the following code example.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, TimelineViews, Month, Agenda, ViewsDirective, ViewDirective, Inject } from '@syncfusion/ej2-react-schedule';
const App = () => {
const data = [{
Id: 1,
Subject: 'Explosion of Betelgeuse Star',
StartTime: new Date(2018, 1, 15, 9, 30),
EndTime: new Date(2018, 1, 15, 11, 0),
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=5',
IsBlock: true
}, {
Id: 2,
Subject: 'Thule Air Crash Report',
StartTime: new Date(2018, 1, 14, 12, 0),
EndTime: new Date(2018, 1, 14, 14, 0)
}];
const eventSettings = { dataSource: data }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Day' />
<ViewDirective option='Week' />
<ViewDirective option='TimelineWeek' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, TimelineViews, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, TimelineViews, Month, Agenda,
ViewsDirective, ViewDirective, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
const App = () => {
const data: Object[] = [{
Id: 1,
Subject: 'Explosion of Betelgeuse Star',
StartTime: new Date(2018, 1, 15, 9, 30),
EndTime: new Date(2018, 1, 15, 11, 0),
RecurrenceRule: 'FREQ=DAILY;INTERVAL=1;COUNT=5',
IsBlock: true
}, {
Id: 2,
Subject: 'Thule Air Crash Report',
StartTime: new Date(2018, 1, 14, 12, 0),
EndTime: new Date(2018, 1, 14, 14, 0)
}];
const eventSettings: EventSettingsModel = { dataSource: data }
return (
<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Day' />
<ViewDirective option='Week' />
<ViewDirective option='TimelineWeek' />
<ViewDirective option='Month' />
<ViewDirective option='Agenda' />
</ViewsDirective>
<Inject services={[Day, Week, TimelineViews, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Readonly
An interaction with the appointments of Scheduler can be enabled/disabled using the readonly
property. With this property enabled, you can simply navigate between the Scheduler dates, views and can be able to view the appointment details in the quick info window. Most importantly, the users are not allowed to perform any CRUD actions on Scheduler, when this property is set to true. By default, it is set as false
.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} readonly={true} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
return (
<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} readonly={true} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Make specific events readonly
There are scenarios where you need to restrict the CRUD action on specific appointments alone based on certain conditions. In the following example, the events that has occurred on the past hours from the current date of the Scheduler are made as read-only and the CRUD actions has been prevented only on those appointments. This can be achieved by setting isReadonly
field of read-only events to true
.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { readOnlyData } from './datasource';
const App = () => {
const eventSettings = { dataSource: readOnlyData }
return (<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { readOnlyData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: readOnlyData }
return (
<ScheduleComponent height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
By default, the event editor is prevented to open on the read-only events when
isReadonly
field is set totrue
.
Restricting event creation on specific time slots
You can restrict the users to create and update more than one appointment on specific time slots. Also, you can disable the CRUD action on those time slots if it is already occupied, which can be achieved using Scheduler’s public method isSlotAvailable
.
Note: The isSlotAvailable is centered around verifying appointments within the present view’s date range. Yet, it does not encompass an evaluation of availability for recurrence occurrences that fall beyond this particular date range.
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef(null);
const eventSettings = { dataSource: scheduleData }
const onActionBegin = (args) => {
if (args.requestType === 'eventCreate' && args.data.length > 0) {
let eventData = args.data[0];
let eventField = scheduleObj.current.eventFields;
let startDate = eventData[eventField.startTime];
let endDate = eventData[eventField.endTime];
args.cancel = !scheduleObj.current.isSlotAvailable(startDate, endDate);
}
}
return (<ScheduleComponent ref={scheduleObj} width='100%' height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} actionBegin={onActionBegin}>
<Inject services={[Day, Week, WorkWeek]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Inject,
ActionEventArgs, EventFieldsMapping, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef<ScheduleComponent>(null);
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
const onActionBegin = (args: ActionEventArgs): void => {
if (args.requestType === 'eventCreate' && (args.data as Object).length > 0) {
let eventData: { [key: string]: Object } = args.data[0] as { [key: string]: Object };
let eventField: EventFieldsMapping = scheduleObj.current.eventFields;
let startDate: Date = eventData[eventField.startTime] as Date;
let endDate: Date = eventData[eventField.endTime] as Date;
args.cancel = !scheduleObj.current.isSlotAvailable(startDate, endDate);
}
}
return (
<ScheduleComponent ref={scheduleObj} width='100%' height='550px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} actionBegin={onActionBegin}>
<Inject services={[Day, Week, WorkWeek]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Differentiate the past time events
To differentiate the appearance of the appointments based on specific criteria such as displaying the past hour appointments with different colors on Scheduler, eventRendered
event can be used which triggers before the appointment renders on the Scheduler.
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef < ScheduleComponent > (null);
const eventSettings = { dataSource: scheduleData }
const onEventRendered = (args) => {
if (args.data.EndTime < scheduleObj.current.selectedDate) {
args.element.classList.add('e-past-app');
}
}
return (<ScheduleComponent width='100%' height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} eventRendered={onEventRendered}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import { useRef } from 'react';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventRenderedArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef<ScheduleComponent>(null);
const eventSettings: EventSettingsModel = { dataSource: scheduleData }
const onEventRendered = (args: EventRenderedArgs): void => {
if (args.data.EndTime < scheduleObj.current.selectedDate) {
args.element.classList.add('e-past-app');
}
}
return (
<ScheduleComponent width='100%' height='550px' ref={scheduleObj} selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings} eventRendered={onEventRendered}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Appointments occupying entire cell
The Scheduler allows the event to occupies the full height of the cell without its header part by setting true
for enableMaxHeight
Property.
We can show more indicator if more than one appointment is available in a same cell by setting true
to enableIndicator
property whereas its default value is false
.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, TimelineViews, TimelineMonth, ViewsDirective, ViewDirective, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData, enableMaxHeight: true, enableIndicator: false }
return (<ScheduleComponent width='100%' height='500px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='TimelineWeek' />
<ViewDirective option='TimelineMonth' />
</ViewsDirective>
<Inject services={[TimelineViews, TimelineMonth]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, TimelineViews, TimelineMonth, ViewsDirective, ViewDirective, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData, enableMaxHeight: true, enableIndicator: false }
return (
<ScheduleComponent width='100%' height='500px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='TimelineWeek' />
<ViewDirective option='TimelineMonth' />
</ViewsDirective>
<Inject services={[TimelineViews, TimelineMonth]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
How to limit maximum number of events to display
In the Scheduler, the default behavior is to display concurrent events based on cell height, with each new event represented as
+n more
characters. However, you may want to improve the quality of the presentation by limiting the number of concurrent events. This can be accomplished by using the maxEventsPerRow
property, which is defaulted to the views
property.
The maxEventsPerRow
property is specific to the month, timeline month, and timeline year views, allowing you to view events visually in these rows. Below is a code example that demonstrates how to use this constraint and the events displayed in a cell have been created:
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Month, Inject, ViewsDirective, ViewDirective } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData };
return (<ScheduleComponent width='100%' height='380px' selectedDate={new Date(2023, 11, 15)} eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Month' maxEventsPerRow={3}/>
</ViewsDirective>
<Inject services={[Month]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Inject, Month,
ViewsDirective, ViewDirective
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData };
return (<ScheduleComponent width='100%' height='380px' selectedDate={new Date(2023, 11, 15)}
eventSettings={eventSettings}>
<ViewsDirective>
<ViewDirective option='Month' maxEventsPerRow={3} />
</ViewsDirective>
<Inject services={[Month]} />
</ScheduleComponent>)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<link href="index.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
The property
maxEventsPerRow
will be applicable only whenrowAutoHeight
feature is disabled in the Scheduler.
Display tooltip for appointments
The tooltip shows the Scheduler appointment’s information in a formatted style by making use of the tooltip related options.
Show or hide built-in tooltip
The tooltip can be displayed for appointments by setting true
to the enableTooltip
option within the eventSettings
property.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, TimelineViews, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings = { dataSource: scheduleData, enableTooltip: true }
return (<ScheduleComponent width='100%' height='500px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, TimelineViews, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, TimelineViews, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = { dataSource: scheduleData, enableTooltip: true }
return (
<ScheduleComponent width='100%' height='500px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, TimelineViews, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
.e-past-app {
background-color: chocolate !important;
}
.custom-class.e-schedule .e-vertical-view .e-all-day-appointment-wrapper .e-appointment,
.custom-class.e-schedule .e-vertical-view .e-day-wrapper .e-appointment,
.custom-class.e-schedule .e-month-view .e-appointment {
background: green;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
Customizing event tooltip using template
After enabling the default tooltip, it is possible to customize the display of needed event information on tooltip by making use of the tooltipTemplate
option within the eventSettings
.
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject } from '@syncfusion/ej2-react-schedule';
import { eventsData } from './datasource';
const App = () => {
const eventSettings = {
dataSource: eventsData, enableTooltip: true,
tooltipTemplate: template
};
const template = (props) => {
return (<div className="tooltip-wrap">
<div className="content-area"><div className="name">{props.Subject}</div>
{(props.City !== null && props.City !== undefined) ? <div className="city">{props.City}</div> : ''}
<div className="time">From :{props.StartTime.toLocaleString()}</div>
<div className="time">To :{props.EndTime.toLocaleString()}</div></div></div>);
}
return (<ScheduleComponent width='100%' height='500px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>);
}
;
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import * as ReactDOM from 'react-dom';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { eventsData } from './datasource';
const App = () => {
const eventSettings: EventSettingsModel = {
dataSource: eventsData, enableTooltip: true,
tooltipTemplate: template
};
const template = (props) => {
return (<div className="tooltip-wrap">
<div className="content-area"><div className="name">{props.Subject}</div>
{(props.City !== null && props.City !== undefined) ? <div className="city">{props.City}</div> : ''}
<div className="time">From :{props.StartTime.toLocaleString()}</div>
<div className="time">To :{props.EndTime.toLocaleString()}</div></div></div>);
}
return (
<ScheduleComponent width='100%' height='500px' selectedDate={new Date(2018, 1, 15)} eventSettings={eventSettings}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<link href="index.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div id='schedule'>
<div id='loader'>Loading....</div>
</div>
</body>
</html>
All the field names that are mapped from the Scheduler dataSource to the appropriate field properties such as subject, description, location, startTime and endTime within the
eventSettings
can be accessed within the template.
Appointment selection
Appointment selection can be done either through mouse or keyboard actions. The selected events in UI will have a box shadow effect around to differentiate it from other appointments.
Action | Description |
---|---|
Mouse click or Single tap on appointments | Selects single appointment. |
Ctrl + [Mouse click] or [Single tap] on appointments | Selects multiple appointments. |
Deleting multiple appointments
With the options available to select multiple appointments, it is also possible to delete the multiple selected appointments simply by pressing the delete
key. In case of deleting multiple selected occurrences of an event series, only those occurrences will be deleted and not the entire series.
Retrieve event details from the UI of an event
It is possible to access the information about the event fields of an appointment element displayed on the Scheduler UI. This can be achieved by passing an appointment element as argument to the public method getEventDetails
.
In the following example, the subject of the appointment clicked has been displayed.
import * as React from 'react';
import { useRef } from 'react';
import * as ReactDOM from 'react-dom';
import { ButtonComponent } from '@syncfusion/ej2-react-buttons';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef(null);
const eventLog = useRef(null);
const eventSettings = { dataSource: scheduleData };
const onEventClick = (args) => {
let event = scheduleObj.current.getEventDetails(args.element);
appendElement(event.Subject + '<hr>');
}
const appendElement = (html) => {
let span = document.createElement('span');
span.innerHTML = html;
let log = eventLog.current;
log.insertBefore(span, log.firstChild);
}
const onClick = () => {
eventLog.current.innerHTML = '';
}
return (
<div className='content-wrapper'>
<div className='col-lg-9 control-section'>
<ScheduleComponent ref={scheduleObj} width='100%' height='550px' selectedDate=
{new Date(2018, 1, 15)} eventSettings={eventSettings} eventClick={onEventClick}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
</div>
<div className='col-lg-3 property-section'>
<div title='Event Trace'>
<table id='property' title='Properties' className='property-panel-table' style=>
<tbody>
<tr style=>
<td>
<div className='eventarea' style=>
<span className='EventLog' ref={eventLog} style=></span>
</div>
</td>
</tr>
<tr style=>
<td style=>
<div className='evtbtn' style=>
<ButtonComponent title='Clear' onClick={onClick}>Clear</ButtonComponent>
</div>
</td>
</tr>
</tbody>
</table>
</div>
</div>
</div>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
import * as React from 'react';
import { useRef } from 'react';
import * as ReactDOM from 'react-dom';
import { ButtonComponent } from '@syncfusion/ej2-react-buttons';
import {
ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventClickArgs, EventSettingsModel
} from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef<ScheduleComponent>(null);
const eventLog = useRef(null);
const eventSettings: EventSettingsModel = { dataSource: scheduleData };
const onEventClick = (args: EventClickArgs): void => {
let event: object = scheduleObj.current.getEventDetails(args.element as HTMLElement);
appendElement(event.Subject + '<hr>');
}
const appendElement = (html: string): void => {
let span: HTMLElement = document.createElement('span');
span.innerHTML = html;
let log: HTMLElement = eventLog.current;
log.insertBefore(span, log.firstChild);
}
const onClick = (): void => {
eventLog.current.innerHTML = '';
}
return (
<div className='content-wrapper'>
<div className='col-lg-9 control-section'>
<ScheduleComponent ref={scheduleObj} width='100%' height='550px' selectedDate=
{new Date(2018, 1, 15)} eventSettings={eventSettings} eventClick={onEventClick}>
<Inject services={[Day, Week, WorkWeek, Month, Agenda]} />
</ScheduleComponent>
</div>
<div className='col-lg-3 property-section'>
<div title='Event Trace'>
<table id='property' title='Properties' className='property-panel-table' style=>
<tbody>
<tr style=>
<td>
<div className='eventarea' style=>
<span className='EventLog' ref={eventLog} style=></span>
</div>
</td>
</tr>
<tr style=>
<td style=>
<div className='evtbtn' style=>
<ButtonComponent title='Clear' onClick={onClick}>Clear</ButtonComponent>
</div>
</td>
</tr>
</tbody>
</table>
</div>
</div>
</div>
)
};
const root = ReactDOM.createRoot(document.getElementById('schedule'));
root.render(<App />);
<!DOCTYPE html>
<html lang="en">
<head>
<title>Syncfusion React Schedule</title>
<meta charset="utf-8" />
<meta name="viewport" content="width=device-width, initial-scale=1.0" />
<meta name="description" content="Essential JS 2 for React Components" />
<meta name="author" content="Syncfusion" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-base/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-buttons/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-calendars/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-inputs/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-navigations/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-popups/styles/material.css" rel="stylesheet" />
<link href="https://cdn.syncfusion.com/ej2/27.1.48/ej2-react-schedule/styles/material.css" rel="stylesheet" />
<link href="https://maxcdn.bootstrapcdn.com/bootstrap/3.3.7/css/bootstrap.min.css" rel="stylesheet" />
<script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
<link href="index.css" rel="stylesheet" />
<script src="systemjs.config.js"></script>
<style>
#loader {
color: #008cff;
height: 40px;
left: 45%;
position: absolute;
top: 45%;
width: 30%;
}
</style>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>
<div>
<div id="schedule">
<div id='loader'>Loading....</div>
</div>
</div>
</body>
</html>
Get the current view appointments
To retrieve the appointments present in the current view of the Scheduler, you can make use of the getCurrentViewEvents
public method. In the following example, the count of current view appointment collection rendered has been traced in dataBound
event.
import * as React from 'react';
import { useRef } from 'react';
import * as ReactDOM from 'react-dom';
import { ButtonComponent } from '@syncfusion/ej2-react-buttons';
import { ScheduleComponent, Day, Week, WorkWeek, Month, Agenda, Inject, EventSettingsModel } from '@syncfusion/ej2-react-schedule';
import { scheduleData } from './datasource';
const App = () => {
const scheduleObj = useRef(null);
const eventLog = useRef(null);
const eventSettings = { dataSource: scheduleData };
const onDataBound = () => {
let event = scheduleObj.current.getCurrentViewEvents();
if (event.length > 0) {
appendElement('Events present on current view <b>' + event.length + '<b><hr>');
} else {
appendElement('No Events available in this view.<hr>');
}
}
const appendElement = (html) => {
let span = document.createElement('span');
