Getting Started with ASP.NET Core

Starting with v16.2.0.x, if you reference Syncfusion assemblies from trial setup or from the NuGet feed, you also have to include a license key in your projects. Please refer to this link to know about registering Syncfusion license key in your ASP.NET Core application to use our components.

Prerequisites

To get start with ASP.NET Core application, need to ensure the following software to be installed on the machine.

  • Visual Studio 2017
  • DotNet Core 2.0

Setup ASP.NET Core application with Essential JS 2 for ASP.NET Core

The following steps to create ASP.NET Core Application.

Step 1: Create ASP.NET Core Web Application with default template project in Visual Studio 2017.

Alt text

Step 2: Once your project created. We need to add Syncfusion EJ2 package into your application by using Nugget Package Manager.

Open the nuGet package manager.

Alt text

Install the Syncfusion.EJ2 package to the application

Alt text

After Installation complete this will included in the project. You can refer it from the Project Assembly Reference.

We need to install NewtonSoft.JSON as dependency since it Syncfusion.EJ2 dependent to NewtonSoft.JSON package.

Step 3: Open the Views/_ViewImports.cshtml to import Syncfusion.EJ2 package.

@addTagHelper *, Syncfusion.EJ2

Step 4: Add client side resource through CDN or local package in the layout page Views/Shared/_Layout.cshtml.

<head>
@* Syncfusion Essential JS 2 Styles *@
<link rel="stylesheet" href="https://cdn.syncfusion.com/ej2/material.css" />

@* Syncfusion Essential JS 2 Scripts *@
<script src="https://cdn.syncfusion.com/ej2/dist/ej2.min.js"></script>
</head>

Step 5: Adding Script Manager in layout page Views/Shared/_Layout.cshtml.

<body>
    @RenderBody()
    @RenderSection("Scripts", required: false)
<ejs-scripts></ejs-scripts>
</body>

Adding component to the Application

  • Now open your view page to render our Syncfusion components.

{% aspCodeBlock razorTemplate=“chart/getting-started/datalabel/razor” %}

<ejs-chart id="container"></ejs-chart>

{% endaspCodeBlock %}

Enable Legend

You can use legend for the chart by setting the visible property to true in legendSettings object.

tagHelper
legend.cs
<ejs-chart id="container" title="Inflation - Consumer Price">
            <e-chart-primaryxaxis valueType="DateTime"
                                  labelFormat="y"
                                  intervalType="Years"></e-chart-primaryxaxis>
            <e-series-collection>
                <e-series dataSource="ViewBag.dataSource" name="Germany" xName="xValue" width="2" opacity="1" yName="yValue" type="@Syncfusion.EJ2.Charts.ChartSeriesType.Line">
                </e-series>
            </e-series-collection>
            <e-chart-legendsettings visible="true"></e-chart-legendsettings>
        </ejs-chart>
public IActionResult Index()
        {
            List<LineChartData> chartData = new List<LineChartData>
            {
                new LineChartData { xValue = new DateTime(2005, 01, 01), yValue = 21, yValue1 = 28 },
                new LineChartData { xValue = new DateTime(2006, 01, 01), yValue = 24, yValue1 = 44 },
                new LineChartData { xValue = new DateTime(2007, 01, 01), yValue = 36, yValue1 = 48 },
                new LineChartData { xValue = new DateTime(2008, 01, 01), yValue = 38, yValue1 = 50 },
                new LineChartData { xValue = new DateTime(2009, 01, 01), yValue = 54, yValue1 = 66 },
                new LineChartData { xValue = new DateTime(2010, 01, 01), yValue = 57, yValue1 = 78 },
                new LineChartData { xValue = new DateTime(2011, 01, 01), yValue = 70, yValue1 = 84 },
            };
            ViewBag.dataSource = chartData;
            return View();
        }
        public class LineChartData
        {
            public DateTime xValue;
            public double yValue;
            public double yValue1;
        }

Add Data Label

You can add data labels to improve the readability of the chart. This can be achieved by setting the visible property to true in the dataLabel object. Now, the data labels are arranged smartly based on series.

tagHelper
datalabel.cs
<ejs-chart id="container" title="Inflation - Consumer Price">
            <e-chart-primaryxaxis valueType="DateTime"
                                  labelFormat="y"
                                  intervalType="Years"></e-chart-primaryxaxis>
            <e-series-collection>
                <e-series dataSource="ViewBag.dataSource" xName="xValue" width="2" opacity="1" yName="yValue" type="@Syncfusion.EJ2.Charts.ChartSeriesType.Line">
                    <e-series-marker>
                        <e-series-datalabel visible="true"></e-series-datalabel>
                    </e-series-marker>
                </e-series>
            </e-series-collection>
        </ejs-chart>
public IActionResult Index()
        {
            List<LineChartData> chartData = new List<LineChartData>
            {
                new LineChartData { xValue = new DateTime(2005, 01, 01), yValue = 21, yValue1 = 28 },
                new LineChartData { xValue = new DateTime(2006, 01, 01), yValue = 24, yValue1 = 44 },
                new LineChartData { xValue = new DateTime(2007, 01, 01), yValue = 36, yValue1 = 48 },
                new LineChartData { xValue = new DateTime(2008, 01, 01), yValue = 38, yValue1 = 50 },
                new LineChartData { xValue = new DateTime(2009, 01, 01), yValue = 54, yValue1 = 66 },
                new LineChartData { xValue = new DateTime(2010, 01, 01), yValue = 57, yValue1 = 78 },
                new LineChartData { xValue = new DateTime(2011, 01, 01), yValue = 70, yValue1 = 84 },
            };
            ViewBag.dataSource = chartData;
            return View();
        }
        public class LineChartData
        {
            public DateTime xValue;
            public double yValue;
            public double yValue1;
        }

Enable Tooltip

The tooltip is useful when you cannot display information by using the data labels due to space constraints. You can enable tooltip by setting the enable property as true in tooltip object.

tagHelper
tooltip.cs
<ejs-chart id="container" title="Inflation - Consumer Price">
            <e-chart-tooltipsettings enable="true"></e-chart-tooltipsettings>
            <e-chart-primaryxaxis valueType="DateTime"
                                  labelFormat="y"
                                  intervalType="Years"></e-chart-primaryxaxis>
            <e-series-collection>
                <e-series dataSource="ViewBag.dataSource" name="Germany" xName="xValue" width="2" opacity="1" yName="yValue" type="@Syncfusion.EJ2.Charts.ChartSeriesType.Column">
                </e-series>
            </e-series-collection>
        </ejs-chart>
public IActionResult Index()
        {
            List<LineChartData> chartData = new List<LineChartData>
            {
                new LineChartData { xValue = new DateTime(2005, 01, 01), yValue = 21, yValue1 = 28 },
                new LineChartData { xValue = new DateTime(2006, 01, 01), yValue = 24, yValue1 = 44 },
                new LineChartData { xValue = new DateTime(2007, 01, 01), yValue = 36, yValue1 = 48 },
                new LineChartData { xValue = new DateTime(2008, 01, 01), yValue = 38, yValue1 = 50 },
                new LineChartData { xValue = new DateTime(2009, 01, 01), yValue = 54, yValue1 = 66 },
                new LineChartData { xValue = new DateTime(2010, 01, 01), yValue = 57, yValue1 = 78 },
                new LineChartData { xValue = new DateTime(2011, 01, 01), yValue = 70, yValue1 = 84 },
            };
            ViewBag.dataSource = chartData;
            return View();
        }
        public class LineChartData
        {
            public DateTime xValue;
            public double yValue;
            public double yValue1;
        }
