Getting started with React MultiSelect component

14 Apr 2021 / 4 minutes to read

This section explains how to create a simple MultiSelect component and configure its available functionalities in React.

Dependencies

The following list of dependencies are required to use the MultiSelect component in your application.

Copied to clipboard
|-- @syncfusion/ej2-react-dropdowns
|-- @syncfusion/ej2-react-base
|-- @syncfusion/ej2-dropdowns
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-data
    |-- @syncfusion/ej2-lists
    |-- @syncfusion/ej2-inputs
    |-- @syncfusion/ej2-navigations
    |-- @syncfusion/ej2-popups
        |-- @syncfusion/ej2-buttons

Installation and configuration

You can use Create-react-app to setup the applications. To install create-react-app run the following command.

Copied to clipboard
npm install -g create-react-app

Start a new project using create-react-app command as follows

Copied to clipboard
create-react-app quickstart --scripts-version=react-scripts-ts

cd quickstart

Adding syncfusion packages

All the available Essential JS 2 packages are published in npmjs.com public registry. You can choose the component that you want to install.

To install MultiSelect component, use the following command

Copied to clipboard
npm install @syncfusion/ej2-react-dropdowns --save

Adding MultiSelect component

Now, you can start adding MultiSelect component in the application. For getting started, add the MultiSelect component in src/App.tsx file using following code.

Add the below code in the src/App.tsx to initialize the MultiSelect.

Copied to clipboard
import { MultiSelectComponent  } from '@syncfusion/ej2-react-dropdowns';
import * as React from 'react';
import * as ReactDOM from "react-dom";

export default class App extends React.Component<{}, {}> {
  public render() {
    return (
       // specifies the tag for render the MultiSelect component
      <MultiSelectComponent  id='mtselement'/>
    );
  }
}

ReactDOM.render(<App />, document.getElementById('sample'));

Adding CSS reference

Import the MultiSelect component required CSS references as follows in src/App.css.

Copied to clipboard
/* import the MultiSelect dependency styles */

@import "../node_modules/@syncfusion/ej2-base/styles/material.css";
@import "../node_modules/@syncfusion/ej2-buttons/styles/material.css";
@import "../node_modules/@syncfusion/ej2-inputs/styles/material.css";
@import "../node_modules/@syncfusion/ej2-react-dropdowns/styles/material.css";

Binding data source

After initialization, populate the data using dataSource  property. Here, an array of string values is passed to the MultiSelect component.

Copied to clipboard
import { MultiSelectComponent } from '@syncfusion/ej2-react-dropdowns';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

export default class App extends React.Component<{}, {}> {
  // define the array of data
  private sportsData: string[] = ['Badminton', 'Basketball', 'Cricket', 'Football', 'Golf', 'Gymnastics', 'Hockey', 'Rugby', 'Snooker', 'Tennis'];
  public render() {
    return (
        // specifies the tag for render the MultiSelect component
      <MultiSelectComponent id="mtselement" dataSource={this.sportsData} />
    );
  }
}
ReactDOM.render(<App />, document.getElementById('sample'));

Run the application

After completing the configuration required to render a basic MultiSelect, run the following command to display the output in your default browser.

Copied to clipboard
npm start
Source
Preview
index.tsx
index.html
Copied to clipboard
import { MultiSelectComponent } from '@syncfusion/ej2-react-dropdowns';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

export default class App extends React.Component<{}, {}> {
  // define the array of data
  private sportsData: string[] = ['Badminton', 'Cricket', 'Football', 'Golf', 'Tennis'];
  public render() {
    return (
        // specifies the tag for render the MultiSelect component
      <MultiSelectComponent id="mtselement" dataSource={this.sportsData}  placeholder="Find a game" />
    );
  }
}
ReactDOM.render(<App />, document.getElementById('sample'));
Copied to clipboard
<!DOCTYPE html>
<html lang="en">

<head>
    <title>Syncfusion React MultiSelect</title>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <meta name="description" content="Essential JS 2 for React Components" />
    <meta name="author" content="Syncfusion" />
    <link href="//cdn.syncfusion.com/ej2/ej2-base/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/ej2-react-inputs/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/ej2-react-buttons/styles/material.css" rel="stylesheet" />
    <script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
    <script src="systemjs.config.js"></script>
    <style>
        #loader {
            color: #008cff;
            height: 40px;
            left: 45%;
            position: absolute;
            top: 45%;
            width: 30%;
        }
    </style>
</head>

<body>
    <div id='sample' style="margin: 20px auto 0; width:250px;">
        <div id='loader'>Loading....</div>
    </div>
</body>

</html>

Configure the Popup List

By default, the width of the popup list automatically adjusts according to the MultiSelect input element’s width and the height of the popup list has ‘300px’.

You can also customize the suggestion list height and width using popupHeight  and popupWidth properties respectively.

In the following sample, popup list’s width and height are configured.

Source
Preview
index.tsx
index.html
Copied to clipboard
import { MultiSelectComponent } from '@syncfusion/ej2-react-dropdowns';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

export default class App extends React.Component<{}, {}> {
    // define the array of data
    private sportsData: string[] = ['Badminton', 'Basketball', 'Cricket', 'Football', 'Golf', 'Gymnastics', 'Hockey', 'Rugby','Snooker', 'Tennis'];

    public render() {
        return (
              // specifies the tag for render the MultiSelect component
            <MultiSelectComponent id="mtselement" dataSource={this.sportsData} popupHeight="250px" popupWidth="250px" placeholder="Find a game" />
            );
    }
}
ReactDOM.render(<App />, document.getElementById('sample'));
Copied to clipboard
<!DOCTYPE html>
<html lang="en">

<head>
    <title>Syncfusion React MultiSelect</title>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <meta name="description" content="Essential JS 2 for React Components" />
    <meta name="author" content="Syncfusion" />
    <link href="//cdn.syncfusion.com/ej2/ej2-base/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/ej2-react-inputs/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/ej2-react-dropdowns/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/ej2-react-buttons/styles/material.css" rel="stylesheet" />
    <script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
    <script src="systemjs.config.js"></script>
    <style>
        #loader {
            color: #008cff;
            height: 40px;
            left: 45%;
            position: absolute;
            top: 45%;
            width: 30%;
        }
    </style>
</head>

<body>
    <div id='sample' style="margin: 20px auto 0; width:250px;">
        <div id='loader'>Loading....</div>
    </div>
</body>

</html>
