How to insert text or image in table programmatically in Document Editor component

26 May 20222 minutes to read

Using Document editor API’s, you can insert [text] or [image] in [table] programmatically based on your requirement.

Use [selection] API’s to navigate between rows and cells.

The following example illustrates how to create 2*2 table and then add text and image programmatically.

CSHTML

@Html.EJS().DocumentEditorContainer("container").Created("onCreated").EnableToolbar(true).Render()

<script>
  var documenteditor;
  var container;
  function onCreated() {
    var documenteditorElement = document.getElementById("container");
    container = documenteditorElement.ej2_instances[0];
    // To insert the table in cursor position
    container.documentEditor.editor.insertTable(2, 2);
    // To insert the image at table first cell
    // To move the cursor to next cell
    moveCursorToNextCell();
    // To insert the image at table second cell
    // To move the cursor to next row
    moveCursorToNextRow();
    // To insert text in cursor position
    container.documentEditor.editor.insertText('Text');
    // To move the cursor to next cell
    moveCursorToNextCell();
    // To insert text in cursor position
    container.documentEditor.editor.insertText('Text');
  }
  function moveCursorToNextCell() {
  // To get current selection start offset
  var startOffset = container.documentEditor.selection.startOffset;
  // Increasing cell index to consider next cell
  var startOffsetArray = startOffset.split(';');
  startOffsetArray[3] = parseInt(startOffsetArray[3]) + 1;
  // Changing start offset
  startOffset = startOffsetArray.join(';');
  // Navigating selection using select method
  container.documentEditor.selection.select(startOffset, startOffset);
}

function moveCursorToNextRow() {
  // To get current selection start offset
  var startOffset = container.documentEditor.selection.startOffset;
  // Increasing row index to consider next row
  var startOffsetArray = startOffset.split(';');
  startOffsetArray[2] = parseInt(startOffsetArray[2]) + 1;
  // Going back to first cell
  startOffsetArray[3] = 0;
  // Changing start offset
  startOffset = startOffsetArray.join(';');
  // Navigating selection using select method
  container.documentEditor.selection.select(startOffset, startOffset);
}
</script>

The output will be like below.
