Getting Started

This section explains how to create a simple ContextMenu, and configure its available functionalities in Angular, using Angular quickstart.

Dependencies

The list of dependencies required to use the ContextMenu component in your application is given below:

|-- @syncfusion/ej2-ng-navigations
    |-- @syncfusion/ej2-ng-base
    |-- @syncfusion/ej2-navigations
        |-- @syncfusion/ej2-base
        |-- @syncfusion/ej2-data
        |-- @syncfusion/ej2-lists
        |-- @syncfusion/ej2-inputs
        |-- @syncfusion/ej2-splitbuttons
        |-- @syncfusion/ej2-popups
            |-- @syncfusion/ej2-buttons

Installation and configuration

To setup basic Angular sample use following commands.

git clone https://github.com/angular/quickstart.git quickstart
cd quickstart
npm install

For more information about Angular application configuration, refer to Angular sample setup.

Install Syncfusion ContextMenu packages using below command.

npm install @syncfusion/ej2-ng-navigations --save

The above package installs ContextMenu dependencies which are required to render the component in the Angular environment.

Syncfusion ej2-ng-navigations packages needs to be mapped in systemjs.config.js configuration file.

/**
 * System configuration for Angular samples
 * Adjust as necessary for your application needs.
 */
(function (global) {
  System.config({
    paths: {
      // paths serve as alias
      'npm:': 'node_modules/',
      "syncfusion:": "node_modules/@syncfusion/", // syncfusion alias

    },
    // map tells the System loader where to look for things
    map: {
      // our app is within the app folder
      'app': 'app',

      // angular bundles
      '@angular/core': 'npm:@angular/core/bundles/core.umd.js',
      '@angular/common': 'npm:@angular/common/bundles/common.umd.js',
      '@angular/compiler': 'npm:@angular/compiler/bundles/compiler.umd.js',
      '@angular/platform-browser': 'npm:@angular/platform-browser/bundles/platform-browser.umd.js',
      '@angular/platform-browser-dynamic': 'npm:@angular/platform-browser-dynamic/bundles/platform-browser-dynamic.umd.js',
      '@angular/http': 'npm:@angular/http/bundles/http.umd.js',
      '@angular/router': 'npm:@angular/router/bundles/router.umd.js',
      '@angular/forms': 'npm:@angular/forms/bundles/forms.umd.js',

      // syncfusion bundles
      //Syncfusion packages
      '@syncfusion/ej2-ng-navigations': 'syncfusion:ej2-ng-navigations/dist/ej2-ng-navigations.umd.min.js',
      '@syncfusion/ej2-ng-base': 'syncfusion:ej2-ng-base/dist/ej2-ng-base.umd.min.js',
      '@syncfusion/ej2-navigations': 'syncfusion:ej2-navigations/dist/ej2-navigations.umd.min.js',
      '@syncfusion/ej2-base': 'syncfusion:ej2-base/dist/ej2-base.umd.min.js',
      '@syncfusion/ej2-buttons': 'syncfusion:ej2-buttons/dist/ej2-buttons.umd.min.js',
      '@syncfusion/ej2-splitbuttons': 'syncfusion:ej2-splitbuttons/dist/ej2-splitbuttons.umd.min.js',
      '@syncfusion/ej2-data': 'syncfusion:ej2-data/dist/ej2-data.umd.min.js',
      '@syncfusion/ej2-lists': 'syncfusion:ej2-lists/dist/ej2-lists.umd.min.js',
      '@syncfusion/ej2-popups': 'syncfusion:ej2-popups/dist/ej2-popups.umd.min.js',
      '@syncfusion/ej2-inputs': 'syncfusion:ej2-inputs/dist/ej2-inputs.umd.min.js',

      // other libraries
      'rxjs':                      'npm:rxjs',
      'angular-in-memory-web-api': 'npm:angular-in-memory-web-api/bundles/in-memory-web-api.umd.js'
    },
    // packages tells the System loader how to load when no filename and/or no extension
    packages: {
      app: {
        defaultExtension: 'js',
        meta: {
          './*.js': {
            loader: 'systemjs-angular-loader.js'
          }
        }
      },
      rxjs: {
        defaultExtension: 'js'
      }
    }
  });
})(this);
  • Add ContextMenu component’s styles as given below in style.css.
@import "../node_modules/@syncfusion/ej2-ng-navigations/styles/material.css";

//Context Menu target
#target {
    border: 1px dashed;
    height: 150px;
    padding: 10px;
    position: relative;
    text-align: justify;
    color: gray;
    user-select: none;
}

Add ContextMenu to the project

  • Import ContextMenu module into Angular application(app.module.ts) from the package @syncfusion/ej2-ng-navigations.
import { NgModule }      from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';

//Syncfusion ej2-ng-navigations module
import { ContextMenuModule } from '@syncfusion/ej2-ng-navigations';

import { AppComponent }  from './app.component';

@NgModule({
  imports:      [ BrowserModule, ContextMenuModule ], //declaration of ej2-ng-buttons module into NgModule
  declarations: [ AppComponent ],
  bootstrap:    [ AppComponent ]
})
export class AppModule { }
  • Modify the template in app.component.ts file with ej-contextmenu to render the ContextMenu component and the option contains menuItems and target in which ContextMenu will be opened.
import { Component } from '@angular/core';
import { MenuItemModel } from '@syncfusion/ej2-navigations';

@Component({
  selector: 'my-app',
  template: `<!--target element-->
            <div id="target">Right click / Touch hold to open the ContextMenu</div>

            <!-- To Render ContextMenu. -->
            <ejs-contextmenu id='contextmenu' target='#target' [items]= 'menuItems'></ejs-contextmenu>`
})

export class AppComponent {
    public menuItems: MenuItemModel[] = [
    {
        text: 'Cut'
    },
    {
        text: 'Copy'
    },
    {
        text: 'Paste'
    }];
}
  • Now run the application using the below command.
npm start

The following example shows a basic ContextMenu component.

Source
Preview
app.component.ts
app.module.ts
main.ts
import { Component } from '@angular/core';
import { MenuItemModel } from '@syncfusion/ej2-navigations';

@Component({
  selector: 'my-app',
  template: `<!--target element-->
            <div id="target">Right click / Touch hold to open the ContextMenu</div>

            <!-- To Render ContextMenu. -->
            <ejs-contextmenu id='contextmenu' target='#target' [items]= 'menuItems'></ejs-contextmenu>`
})

export class AppComponent {
    public menuItems: MenuItemModel[] = [
    {
        text: 'Cut'
    },
    {
        text: 'Copy'
    },
    {
        text: 'Paste'
    }];
}
import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { AppComponent } from './app.component';
import { ContextMenuModule } from '@syncfusion/ej2-ng-navigations';
import { enableRipple } from '@syncfusion/ej2-base';

enableRipple(true);

/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule,
        ContextMenuModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent]
})
export class AppModule { }
import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

Rendering items with Separator

The Separators are the horizontal lines used to separate the menu items. You cannot select the separators. You can enable separators to group the menu items using the separator property. Cut, Copy, and Paste menu items are grouped using separator property in the following sample.

Source
Preview
app.component.ts
app.module.ts
main.ts
import { Component } from '@angular/core';
import { MenuItemModel } from '@syncfusion/ej2-navigations';

@Component({
  selector: 'my-app',
  template: `<div id="target">Right click / Touch hold to open the ContextMenu</div>
            <ejs-contextmenu id='contextmenu' target='#target' [items]= 'menuItems'></ejs-contextmenu>`
})

export class AppComponent {
    public menuItems: MenuItemModel[] = [
        {
            text: 'Cut'
        },
        {
            text: 'Copy'
        },
        {
            text: 'Paste'
        },
        {
            separator: true
        },
        {
            text: 'Font'
        },
        {
            text: 'Paragraph'
        }
        ];
}
import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { AppComponent } from './app.component';
import { ContextMenuModule } from '@syncfusion/ej2-ng-navigations';
import { enableRipple } from '@syncfusion/ej2-base';

enableRipple(true);

/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule,
        ContextMenuModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent]
})
export class AppModule { }
import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

The separator property should not be given along with the other fields in the MenuItem.
