Getting started with Angular TreeView component

This section explains the steps required to create a simple TreeView component, and configure its available functionalities in Angular using the Essential JS 2 quickstart seed repository. This seed repository is preconfigured with all the Essential JS 2 packages.

Dependencies

The following list of dependencies are required to use the TreeView component in your application.

|-- @syncfusion/ej2-angular-navigations
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-data
    |-- @syncfusion/ej2-lists
    |-- @syncfusion/ej2-inputs
    |-- @syncfusion/ej2-splitbuttons
        |-- @syncfusion/ej2-buttons
    |-- @syncfusion/ej2-popups
    |-- @syncfusion/ej2-angular-base

Installation and configuration

To setup basic Angular sample use following commands.

git clone https://github.com/angular/quickstart.git quickstart
cd quickstart
npm install

For more information, refer to Angular sample setup.

Install Syncfusion packages using below command.

npm install @syncfusion/ej2-ng-navigations --save

The above package installs TreeView dependencies which are required to render the component in the Angular environment.

Syncfusion ej2-angular-navigations packages needs to be mapped in systemjs.config.js configuration file.

/**
 * System configuration for Angular samples
 * Adjust as necessary for your application needs.
 */
(function (global) {
System.config({
    paths: {
        'npm:': 'node_modules/',
         "syncfusion:": "node_modules/@syncfusion/", //** syncfusion alias **
    },
    map: {

        // our app is within the app folder
        app: 'app',

        // angular bundles
        '@angular/core': 'npm:@angular/core/bundles/core.umd.js',
        '@angular/common': 'npm:@angular/common/bundles/common.umd.js',
        '@angular/compiler': 'npm:@angular/compiler/bundles/compiler.umd.js',
        '@angular/platform-browser': 'npm:@angular/platform-browser/bundles/platform-browser.umd.js',
        '@angular/platform-browser-dynamic': 'npm:@angular/platform-browser-dynamic/bundles/platform-browser-dynamic.umd.js',
        '@angular/http': 'npm:@angular/http/bundles/http.umd.js',
        '@angular/router': 'npm:@angular/router/bundles/router.umd.js',
        '@angular/forms': 'npm:@angular/forms/bundles/forms.umd.js',

        // syncfusion bundles
        "@syncfusion/ej2-base": "syncfusion:ej2-base/dist/ej2-base.umd.min.js",
        "@syncfusion/ej2-data": "syncfusion:ej2-data/dist/ej2-data.umd.min.js",
        "@syncfusion/ej2-lists": "syncfusion:ej2-lists/dist/ej2-lists.umd.min.js",
        "@syncfusion/ej2-inputs": "syncfusion:ej2-inputs/dist/ej2-inputs.umd.min.js",
        "@syncfusion/ej2-buttons": "syncfusion:ej2-buttons/dist/ej2-buttons.umd.min.js",
        "@syncfusion/ej2-popups": "syncfusion:ej2-popups/dist/ej2-popups.umd.min.js",
        '@syncfusion/ej2-splitbuttons': 'syncfusion:ej2-splitbuttons/dist/ej2-splitbuttons.umd.min.js',
        "@syncfusion/ej2-navigations": "syncfusion:ej2-navigations/dist/ej2-navigations.umd.min.js",
        "@syncfusion/ej2-angular-base": "syncfusion:ej2-angular-base/dist/ej2-angular-base.umd.min.js",
        '@syncfusion/ej2-angular-splitbuttons': 'syncfusion:ej2-angular-splitbuttons/dist/ej2-angular-splitbuttons.umd.min.js',
        "@syncfusion/ej2-angular-navigations": "syncfusion:ej2-angular-navigations/dist/ej2-angular-navigations.umd.min.js",

        // other libraries
        'rxjs':                      'npm:rxjs',
        'angular-in-memory-web-api': 'npm:angular-in-memory-web-api/bundles/in-memory-web-api.umd.js'
    },

    // packages tells the System loader how to load when no filename and/or no extension
    packages: {
      app: {
        defaultExtension: 'js',
        meta: {
          './*.js': {
            loader: 'systemjs-angular-loader.js'
          }
        }
      },
      rxjs: {
        defaultExtension: 'js'
      }
    }
  });
})(this);

Add the TreeView and its dependency component’s styles as given below in style.css.

@import "../node_modules/@syncfusion/ej2-base/styles/material.css";
@import "../node_modules/@syncfusion/ej2-angular-navigations/styles/material.css";
@import "../node_modules/@syncfusion/ej2-inputs/styles/material.css";
@import "../node_modules/@syncfusion/ej2-buttons/styles/material.css";

Note: If you want to refer the combined component styles, please make use of our CRG (Custom Resource Generator) in your application.

Import TreeView module into Angular application(app.module.ts) from the package @syncfusion/ej2-angular-navigations.

import { NgModule }      from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
// import the TreeViewModule for the TreeView component
import { TreeViewModule } from '@syncfusion/ej2-angular-navigations';
import { AppComponent }  from './app.component';

@NgModule({
  //declaration of ej2-angular-navigations module into NgModule
  imports:      [ BrowserModule, TreeViewModule ],
  declarations: [ AppComponent ],
  bootstrap:    [ AppComponent ]
})
export class AppModule { }

Modify the template in app.component.ts file to render the ejs-treeview component.

import { Component, ViewEncapsulation } from '@angular/core';

@Component({
  selector: 'my-app',
  template: `<ejs-treeview id='treeelement'></ejs-treeview>`,
  encapsulation: ViewEncapsulation.None
})
export class AppComponent  { }

Binding data source

TreeView can load data either from local data sources or remote data services. This can be done using the dataSource property that is a member of the fields property. The dataSource property supports array of JavaScript objects and DataManager. Here, an array of JSON values is passed to the TreeView component.

import { Component, ViewEncapsulation } from '@angular/core';

@Component({
    selector: 'my-app',
    template: `<ejs-treeview id='treeelement' [fields]='field'></ejs-treeview>`,
    encapsulation: ViewEncapsulation.None
})
export class AppComponent {
    constructor() {
    }
    // defined the array of data
     public hierarchicalData: Object[] = [
        { id: '01', name: 'Music', expanded: true,
            subChild: [
                {id: '01-01', name: 'Gouttes.mp3'},
                      ]
        },
        {
            id: '02', name: 'Videos',
            subChild: [
                {id: '02-01', name: 'Naturals.mp4'},
                {id: '02-02', name: 'Wild.mpeg'}
        ]
        },
        {
            id: '03', name: 'Documents',
            subChild: [
                {id: '03-01', name: 'Environment Pollution.docx'},
                {id: '03-02', name: 'Global Water, Sanitation, & Hygiene.docx'},
                {id: '03-03', name: 'Global Warming.ppt'},
                {id: '03-02', name: 'Social Network.pdf'},
                {id: '03-03', name: 'Youth Empowerment.pdf'},
            ]
        }
    ];
    public field:Object ={ dataSource: this.hierarchicalData, id: 'id', text: 'name', child: 'subChild' };
}

Run the application

After completing the configuration required to render a basic TreeView, run the following command to display the output in your default browser.

npm start

The following example illustrates the output in your browser.

Source

Preview

app.component.ts

app.module.ts

main.ts

import { Component } from '@angular/core';

@Component({
    selector: 'app-container',
    template: `<div id='treeparent'><ejs-treeview id='treeelement' [fields]='field'></ejs-treeview></div>`
})
export class AppComponent {
    constructor() {
    }
    // defined the array of data
    public hierarchicalData: Object[] = [
       { id: '01', name: 'Music', expanded: true,
            subChild: [
                {id: '01-01', name: 'Gouttes.mp3'},
                      ]
        },
        {
            id: '02', name: 'Videos',
            subChild: [
                {id: '02-01', name: 'Naturals.mp4'},
                {id: '02-02', name: 'Wild.mpeg'}
        ]
        },
        {
            id: '03', name: 'Documents',
            subChild: [
                {id: '03-01', name: 'Environment Pollution.docx'},
                {id: '03-02', name: 'Global Water, Sanitation, & Hygiene.docx'},
                {id: '03-03', name: 'Global Warming.ppt'},
                {id: '03-02', name: 'Social Network.pdf'},
                {id: '03-03', name: 'Youth Empowerment.pdf'},
            ]
        }
    ];
    public field:Object ={ dataSource: this.hierarchicalData, id: 'id', text: 'name', child: 'subChild' };
}

import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { FormsModule } from '@angular/forms';
import { AppComponent } from './app.component';
import { TreeViewModule } from '@syncfusion/ej2-angular-navigations';
/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule,FormsModule,TreeViewModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent]
})
export class AppModule { }

import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);
