Getting started with Angular Linear Gauge component

This section explains you the steps required to create a simple linear gauge and demonstrate the basic usage of the linear gauge control.

Dependencies

Below is the list of minimum dependencies required to use the linear gauge component.

|-- @syncfusion/ej2-angular-lineargauge
    |-- @syncfusion/ej2-angular-base
    |-- @syncfusion/ej2-angular-buttons
    |-- @syncfusion/ej2-angular-popups
    |-- @syncfusion/ej2-lineargauge
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-buttons
    |-- @syncfusion/ej2-popups

Installation and Configuration

To setup basic Angular sample use following commands.

git clone https://github.com/angular/quickstart.git quickstart
cd quickstart
npm install

For more information, refer to Angular sample setup

Install linear gauge packages using below command.

npm install @syncfusion/ej2-angular-lineargauge --save

The above package installs lineargauge dependencies which are required to render the component in Angular environment

Syncfusion ej2-angular-lineargauge packages needs to be mapped in systemjs.config.js configuration file.

/**
 * System configuration for Angular samples
 * Adjust as necessary for your application needs.
 */
(function (global) {
  System.config({
    paths: {
      // paths serve as alias
      'npm:': 'node_modules/',
      "syncfusion:": "node_modules/@syncfusion/", // syncfusion alias

    },
    // map tells the System loader where to look for things
    map: {
      // our app is within the app folder
      'app': 'app',

      // angular bundles
      '@angular/core': 'npm:@angular/core/bundles/core.umd.js',
      '@angular/common': 'npm:@angular/common/bundles/common.umd.js',
      '@angular/compiler': 'npm:@angular/compiler/bundles/compiler.umd.js',
      '@angular/platform-browser': 'npm:@angular/platform-browser/bundles/platform-browser.umd.js',
      '@angular/platform-browser-dynamic': 'npm:@angular/platform-browser-dynamic/bundles/platform-browser-dynamic.umd.js',
      '@angular/http': 'npm:@angular/http/bundles/http.umd.js',
      '@angular/router': 'npm:@angular/router/bundles/router.umd.js',
      '@angular/forms': 'npm:@angular/forms/bundles/forms.umd.js',

      // syncfusion bundles
      "@syncfusion/ej2-base": "node_modules/@syncfusion/ej2-base/dist/ej2-base.umd.min.js",
      "@syncfusion/ej2-lineargauge": "node_modules/@syncfusion/ej2-lineargauge/dist/ej2-lineargauge.umd.min.js",
      "@syncfusion/ej2-angular-base": "node_modules/@syncfusion/ej2-angular-base/dist/ej2-angular-base.umd.min.js",
      "@syncfusion/ej2-angular-lineargauge": "node_modules/@syncfusion/ej2-angular-lineargauge/dist/ej2-angular-lineargauge.umd.min.js",
      "@syncfusion/ej2-buttons": "syncfusion:ej2-buttons/dist/ej2-buttons.umd.min.js",
      "@syncfusion/ej2-popups": "syncfusion:ej2-popups/dist/ej2-popups.umd.min.js",
      "@syncfusion/ej2-angular-buttons": "syncfusion:ej2-angular-buttons/dist/ej2-angular-buttons.umd.min.js",
      "@syncfusion/ej2-angular-popups": "syncfusion:ej2-angular-popups/dist/ej2-angular-popups.umd.min.js",

      // other libraries
      'rxjs':                      'npm:rxjs',
      'angular-in-memory-web-api': 'npm:angular-in-memory-web-api/bundles/in-memory-web-api.umd.js'
    },
    // packages tells the System loader how to load when no filename and/or no extension
    packages: {
      app: {
        defaultExtension: 'js',
        meta: {
          './*.js': {
            loader: 'systemjs-angular-loader.js'
          }
        }
      },
      rxjs: {
        defaultExtension: 'js'
      }
    }
  });
})(this);

Import LinearGauge module into Angular application(app.module.ts) from the package @syncfusion/ej2-angular-lineargauge [src/app/app.module.ts].

import { NgModule }      from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
// import the LinearGaugeModule for the LinearGauge component
import { LinearGaugeModule } from '@syncfusion/ej2-angular-lineargauge';
import { AppComponent }  from './app.component';

@NgModule({
  //declaration of ej2-angular-lineargauge module into NgModule
  imports:      [ BrowserModule, LinearGaugeModule ],
  declarations: [ AppComponent ],
  bootstrap:    [ AppComponent ]
})
export class AppModule { }

Modify the template in app.component.ts file to render the ej2-angular-lineargauge component [src/app/app.component.ts].

import { Component, ViewEncapsulation } from '@angular/core';

@Component({
  selector: 'my-app',
  // specifies the template string for the linear gauge component
  template: `<ejs-lineargauge id='container'></ejs-lineargauge>`,
  encapsulation: ViewEncapsulation.None
})
export class AppComponent  { }

Now run the application in the browser using the below command.

npm start

The below example shows a basic linear gauge.

Source

Preview

app.component.ts

app.module.ts

main.ts

import { Component } from '@angular/core';

@Component({
    selector: 'app-container',
    // specifies the template string for the linear gauge component
    template: `<ejs-lineargauge id="gauge-container"></ejs-lineargauge>`
})
export class AppComponent {

}

import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { AppComponent } from './app.component';
import { LinearGaugeModule } from '@syncfusion/ej2-angular-lineargauge';
import { GaugeTooltipService } from '@syncfusion/ej2-angular-lineargauge';

/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule, LinearGaugeModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent],
    providers: [ GaugeTooltipService ]
})
export class AppModule { }

import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

Module Injection

Lineargauge component are segregated into individual feature-wise modules. In order to use a particular feature, you need to inject its feature service in the AppModule. In the current application, we are going to modify the above basic chart to visualize sales data for a particular year. For this application we are going to use tooltip and annotation feature of the linear gauge. Please find relevant feature service name and description as follows.

AnnotationsService - Inject this provider to use Annotation feature.
GaugeTooltipService - Inject this provider to use Tooltip feature.

These modules should be injected to the provider section as follows,

   import { NgModule } from '@angular/core';
   import { BrowserModule } from '@angular/platform-browser';
   import { AppComponent } from './app.component';
   import { LinearGaugeComponent } from '@syncfusion/ej2-angular-lineargauge';
   import { AnnotationsService, GaugeTooltipService} from '@syncfusion/ej2-angular-lineargauge';

   @NgModule({
       imports: [
           BrowserModule,
       ],
       declarations: [AppComponent, LinearGaugeComponent],
       bootstrap: [AppComponent],
       providers: [ AnnotationsService, GaugeTooltipService ]
   })

Add Gauge Title

You can add a title using title property to the linear gauge to provide quick information to the user about the user.

Source

Preview

app.component.ts

app.module.ts

main.ts

import { Component, OnInit } from '@angular/core';

@Component({
    selector: 'app-container',
    template:
    `<ejs-lineargauge id="gauge-container" [title]='Title'>
    </ejs-lineargauge>`
})
export class AppComponent implements OnInit {
    public Title: string;
    ngOnInit(): void {
        // Title for linear gauge
        this.Title = 'linear gauge';
    }
}

import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { AppComponent } from './app.component';
import { LinearGaugeModule } from '@syncfusion/ej2-angular-lineargauge';
import { GaugeTooltipService } from '@syncfusion/ej2-angular-lineargauge';

/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule, LinearGaugeModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent],
    providers: [ GaugeTooltipService ]
})
export class AppModule { }

import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

Axis Range

You can set the range to the axis using minimum and maximum properties.

Source

Preview

app.component.ts

app.module.ts

main.ts

import { Component, OnInit } from '@angular/core';

@Component({
    selector: 'app-container',
    template:
    `<ejs-lineargauge id="gauge-container">
      <e-axes>
         <e-axis [minimum]='Minimum' [maximum]='Maximum'>
         </e-axis>
      </e-axes>
    </ejs-lineargauge>`
})
export class AppComponent implements OnInit {
    public Minimum: number;
    public Maximum: number;
    ngOnInit(): void {
       this.Minimum: 0,
       this.Maximum: 200
    }
}

import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { AppComponent } from './app.component';
import { LinearGaugeModule } from '@syncfusion/ej2-angular-lineargauge';
import { GaugeTooltipService } from '@syncfusion/ej2-angular-lineargauge';

/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule, LinearGaugeModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent],
    providers: [ GaugeTooltipService ]
})
export class AppModule { }

import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

To denote the axis values with temperature units, we can add °C as suffix to each label. This can be achieved by setting the {value}°C to the format property of labelStyle in the axis. Here, {value} acts as a placeholder for each axis label.

You can change the pointer value from the default value of the gauge by settings the value property in pointers option in axis.

Source

Preview

app.component.ts

app.module.ts

main.ts

import { Component, OnInit } from '@angular/core';

@Component({
    selector: 'app-container',
    template:
    `<ejs-lineargauge id="gauge-container">
      <e-axes>
         <e-axis minimum=0 maximum=200>
           <e-pointers>
             <e-pointer value=140></e-pointer>
           </e-pointers>
           <e-ranges>
             <e-range start=0 end=80 startWidth=15 endWidth=15></e-range>
             <e-range start=80 end=120 startWidth=15 endWidth=15></e-range>
             <e-range start=120 end=140 startWidth=15 endWidth=15></e-range>
             <e-range start=140 end=200 startWidth=15 endWidth=15></e-range>
           </e-ranges>
         </e-axis>
      </e-axes>
    </ejs-lineargauge>`
})
export class AppComponent implements OnInit {
    public Label: Object;
    ngOnInit(): void {
      this.Label = {
           format: '{value}°C'
      };
    }
}

import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { AppComponent } from './app.component';
import { LinearGaugeModule } from '@syncfusion/ej2-angular-lineargauge';
import { GaugeTooltipService } from '@syncfusion/ej2-angular-lineargauge';

/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule, LinearGaugeModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent],
    providers: [ GaugeTooltipService ]
})
export class AppModule { }

import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

Set Pointer Value

You can change the pointer value in the below sample using value property in pointers.

Source

Preview

app.component.ts

app.module.ts

main.ts

import { Component, OnInit } from '@angular/core';

@Component({
    selector: 'app-container',
    template:
    `<ejs-lineargauge id="gauge-container">
      <e-axes>
         <e-axis minimum=0 maximum=200>
           <e-pointers>
             <e-pointer value=40 color='green'></e-pointer>
           </e-pointers>
         </e-axis>
      </e-axes>
    </ejs-lineargauge>`
})
export class AppComponent implements OnInit {
    ngOnInit(): void {
    }
}

import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { AppComponent } from './app.component';
import { LinearGaugeModule } from '@syncfusion/ej2-angular-lineargauge';
import { GaugeTooltipService } from '@syncfusion/ej2-angular-lineargauge';

/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule, LinearGaugeModule
    ],
    declarations: [AppComponent],
    bootstrap: [AppComponent],
    providers: [ GaugeTooltipService ]
})
export class AppModule { }

import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

Contents

Dependencies
Installation and Configuration
Module Injection
Add Gauge Title
Axis Range
Set Pointer Value

Contents

Dependencies
Installation and Configuration
Module Injection
Add Gauge Title
Axis Range
Set Pointer Value

Please provide additional information

Thank you for your feedback and comments.We will rectify this as soon as possible!
