Getting started

This section explains how to create a simple AutoComplete component and configure its available functionalities in Angular.

Dependencies

The following list of dependencies are required to use the AutoComplete component in your application.

|-- @syncfusion/ej2-angular-dropdowns
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-data
    |-- @syncfusion/ej2-lists
    |-- @syncfusion/ej2-inputs
    |-- @syncfusion/ej2-popups
        |-- @syncfusion/ej2-buttons
    |-- @syncfusion/ej2-angular-base

Installation and configuration

  • To setup basic Angular sample use following commands.
git clone https://github.com/angular/quickstart.git quickstart
cd quickstart
npm install

For more information, refer to Angular sample setup.

npm install @syncfusion/ej2-angular-dropdowns --save

The above package installs AutoComplete dependencies which are required to render the component in the Angular environment.

/**
 * System configuration for Angular samples
 * Adjust as necessary for your application needs.
 */
(function (global) {
System.config({
    paths: {
        'npm:': 'node_modules/',
         "syncfusion:": "node_modules/@syncfusion/", //** syncfusion alias **
    },
    map: {

        // our app is within the app folder
        app: 'app',

        // angular bundles
        '@angular/core': 'npm:@angular/core/bundles/core.umd.js',
        '@angular/common': 'npm:@angular/common/bundles/common.umd.js',
        '@angular/compiler': 'npm:@angular/compiler/bundles/compiler.umd.js',
        '@angular/platform-browser': 'npm:@angular/platform-browser/bundles/platform-browser.umd.js',
        '@angular/platform-browser-dynamic': 'npm:@angular/platform-browser-dynamic/bundles/platform-browser-dynamic.umd.js',
        '@angular/http': 'npm:@angular/http/bundles/http.umd.js',
        '@angular/router': 'npm:@angular/router/bundles/router.umd.js',
        '@angular/forms': 'npm:@angular/forms/bundles/forms.umd.js',

        // syncfusion bundles
        '@syncfusion/ej2-base': 'syncfusion:ej2-base/dist/ej2-base.umd.min.js',
        '@syncfusion/ej2-data': 'syncfusion:ej2-data/dist/ej2-data.umd.min.js',
        '@syncfusion/ej2-inputs': 'syncfusion:ej2-inputs/dist/ej2-inputs.umd.min.js',
        '@syncfusion/ej2-popups': 'syncfusion:ej2-popups/dist/ej2-popups.umd.min.js',
        "@syncfusion/ej2-dropdowns": 'syncfusion:ej2-dropdowns/dist/ej2-dropdowns.umd.min.js',
        '@syncfusion/ej2-angular-base': 'syncfusion:ej2-angular-base/dist/ej2-angular-base.umd.min.js',
        '@syncfusion/ej2-angular-dropdowns': 'syncfusion:ej2-angular-dropdowns/dist/ej2-angular-dropdowns.umd.min.js'

        // other libraries
        'rxjs':                      'npm:rxjs',
        'angular-in-memory-web-api': 'npm:angular-in-memory-web-api/bundles/in-memory-web-api.umd.js'
    },

    // packages tells the System loader how to load when no filename and/or no extension
    packages: {
      app: {
        defaultExtension: 'js',
        meta: {
          './*.js': {
            loader: 'systemjs-angular-loader.js'
          }
        }
      },
      rxjs: {
        defaultExtension: 'js'
      }
    }
  });
})(this);
  • Import AutoComplete module into Angular application(app.module.ts) from the package @syncfusion/ej2-angular-dropdowns.
import { NgModule }      from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
// import the AutoCompleteModule for the AutoComplete component
import { AutoCompleteModule } from '@syncfusion/ej2-angular-dropdowns';
import { AppComponent }  from './app.component';

@NgModule({
  //declaration of ej2-angular-dropdowns module into NgModule
  imports:      [ BrowserModule, AutoCompleteModule ],
  declarations: [ AppComponent ],
  bootstrap:    [ AppComponent ]
})
export class AppModule { }
  • Modify the template in app.component.ts file to render the ejs-autocomplete component and also include the component theme from the corresponding base package @syncfusion/ej2-dropdowns component through styleUrls.
import { Component, ViewEncapsulation } from '@angular/core';

@Component({
  selector: 'my-app',
  // specifies the template string for the AutoComplete component
  template: `<ejs-autocomplete id='atcelement'></ejs-autocomplete>`,
  // include the material theme to AutoComplete
  styleUrls: ['../../node_modules/@syncfusion/ej2-base/styles/material.css','../../node_modules/@syncfusion/ej2-lists/styles/material.css','../../node_modules/@syncfusion/ej2-inputs/styles/material.css','../../node_modules/@syncfusion/ej2-popups/styles/material.css','../../node_modules/@syncfusion/ej2-dropdowns/styles/material.css'],
  encapsulation: ViewEncapsulation.None
})
export class AppComponent  { }

Binding data source

After initializing, populate the data in AutoComplete using dataSource property. Here, an array of string values is passed to the AutoComplete component.

import { Component } from '@angular/core';

@Component({
    selector: 'app-container',
    // specifies the template string for the AutoComplete component
    template: `<ejs-autocomplete id='atcelement' [dataSource]='sportsData'></ejs-autocomplete>`
})
export class AppComponent {
    constructor() {
    }
    // defined the array of data
    public sportsData: string[] = ['Badminton', 'Basketball', 'Cricket', 'Football', 'Golf', 'Gymnastics', 'Hockey', 'Rugby', 'Snooker', 'Tennis'];
}

Run the application

After completing the configuration required to render a basic AutoComplete, run the following command to display the output in your default browser.

npm start

The following example illustrates the output in your browser.

Source
Preview
app.component.ts
app.module.ts
main.ts
import { Component } from '@angular/core';

@Component({
    selector: 'app-container',
    // specifies the template string for the AutoComplete component with dataSource
    template: `<ejs-autocomplete id='atcelement' [dataSource]='sportsData'></ejs-autocomplete>`
})
export class AppComponent {
    constructor() {
    }
    // defined the array of data
    public sportsData: string[] = ['Badminton', 'Basketball', 'Cricket', 'Football', 'Golf', 'Gymnastics'];
}
import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { FormsModule, ReactiveFormsModule } from '@angular/forms';
import { AppComponent } from './app.component';
import { AutoCompleteComponent } from '@syncfusion/ej2-angular-dropdowns';
import { ButtonComponent } from '@syncfusion/ej2-angular-buttons';
/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule,FormsModule, ReactiveFormsModule
    ],
    declarations: [AppComponent, AutoCompleteComponent, ButtonComponent],
    bootstrap: [AppComponent]
})
export class AppModule { }
import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

Configure the popup list

By default, the width of the popup list automatically adjusts according to the DropDownList input element’s width, and the height of the popup list has ‘300px’.

The height and width of the popup list can also be customized using the popupHeight  and popupWidth properties respectively.

In the following sample, popup list’s width and height are configured.

Source
Preview
app.component.ts
app.module.ts
main.ts
import { Component } from '@angular/core';

@Component({
    selector: 'app-container',
    // specifies the template string for the AutoComplete component with dataSource
    template: `<ejs-autocomplete id='atcelement' [dataSource]='sportsData' [popupHeight]='height' [popupWidth]='width' [placeholder]='text'></ejs-autocomplete>`
})
export class AppComponent {
    constructor() {
    }
    // defined the array of data
    public sportsData: string[] = ['Badminton', 'Cricket', 'Football', 'Golf', 'Hockey', 'Rugby', 'Snooker', 'Tennis'];
    // set width of the popup list
    public width: string = '250px';
    // set height of the popup list
    public height: string = '200px';
    // set placeholder to autocomplete element
    public text: string = "Find a game"
}
import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { FormsModule, ReactiveFormsModule } from '@angular/forms';
import { AppComponent } from './app.component';
import { AutoCompleteComponent } from '@syncfusion/ej2-angular-dropdowns';
import { ButtonComponent } from '@syncfusion/ej2-angular-buttons';
/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule,FormsModule, ReactiveFormsModule
    ],
    declarations: [AppComponent, AutoCompleteComponent, ButtonComponent],
    bootstrap: [AppComponent]
})
export class AppModule { }
import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);

Two-way binding

In AutoComplete, the value property supports two-way binding functionality. The following example demonstrates how to work with the two-way binding functionality in AutoComplete.

Source
Preview
app.component.ts
app.module.ts
main.ts
import { Component } from '@angular/core';

@Component({
    selector: 'app-container',
    // specifies the template string for the AutoComplete component and
    // input element for checking the two-way binding support using value property
    template: `<ejs-autocomplete id='atcelement' [dataSource]='sportsData' [(value)]='value'></ejs-autocomplete>
    <div style='margin-top: 50px'>
        <input type="text" [(ngModel)]="value" style="width:245px;height:25px" />
     </div>`
})
export class AppComponent {
    constructor() {
    }
    // defined the array of complex data
    public sportsData: string[] = ['Badminton', 'Basketball', 'Cricket', 'Football', 'Golf', 'Gymnastics'];
    // set a value to pre-select
    public value: string = 'Badminton';
}
import { NgModule } from '@angular/core';
import { BrowserModule } from '@angular/platform-browser';
import { FormsModule, ReactiveFormsModule } from '@angular/forms';
import { AppComponent } from './app.component';
import { AutoCompleteComponent } from '@syncfusion/ej2-angular-dropdowns';
import { ButtonComponent } from '@syncfusion/ej2-angular-buttons';
/**
 * Module
 */
@NgModule({
    imports: [
        BrowserModule,FormsModule, ReactiveFormsModule
    ],
    declarations: [AppComponent, AutoCompleteComponent, ButtonComponent],
    bootstrap: [AppComponent]
})
export class AppModule { }
import { platformBrowserDynamic } from '@angular/platform-browser-dynamic';
import { enableProdMode } from '@angular/core';
import { AppModule } from './app.module';

enableProdMode();
platformBrowserDynamic().bootstrapModule(AppModule);
