Getting started with React QueryBuilder component

06 Oct 2022 / 3 minutes to read

This section explains how to create and configure a simple React Query Builder component.

Dependencies

The list of dependencies required to use the Query Builder component in your application is given below:

|-- @syncfusion/ej2-react-querybuilder
    |-- @syncfusion/ej2-react-base
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-querybuilder
    |-- @syncfusion/ej2-datamanager
    |-- @syncfusion/ej2-dropdowns
    |-- @syncfusion/ej2-calenders
    |-- @syncfusion/ej2-inputs
    |-- @syncfusion/ej2-popups

Installation and Configuration

You can use Create-react-app to setup the applications. To install create-react-app run the following command.

npm install -g create-react-app

Start a new project using create-react-app command as follows,

create-react-app quickstart --scripts-version=react-scripts-ts

cd quickstart

create-react-app quickstart

cd quickstart

Adding Syncfusion packages

All the available Essential JS 2 packages are published in npmjs.com public registry.

To install Query Builder component, use the following command.

npm install @syncfusion/ej2-react-querybuilder --save

‘react-scripts-ts’ is used for creating React app with typescript.

Adding Query Builder component to the Application

To include the Query Builder component in your application import the QueryBuilderComponent from ej2-react-querybuilder package in App.tsx.

Add the Query Builder component in application as shown in below code example.

import { ColumnsModel, QueryBuilderComponent } from '@syncfusion/ej2-react-querybuilder';
import * as ReactDOM from 'react-dom';
import * as React from 'react';

class App extends React.Component<{}, {}> {

    public columnData: ColumnsModel[] = [
        { field: 'EmployeeID', label: 'EmployeeID', type: 'number'},
        { field: 'FirstName', label: 'FirstName', type: 'string' },
        { field: 'TitleOfCourtesy', label: 'Title Of Courtesy', type: 'boolean', values: ['Mr.', 'Mrs.'] },
        { field: 'Title', label: 'Title', type: 'string' },
        { field: 'HireDate', label: 'HireDate', type: 'date', format: 'dd/MM/yyyy' },
        { field: 'Country', label: 'Country', type: 'string' },
        { field: 'City', label: 'City', type: 'string' }
    ];

    public render() {
        return (
            <QueryBuilderComponent width='100%' columns={this.columnData}/>
        );
    }
}

import { QueryBuilderComponent } from '@syncfusion/ej2-react-querybuilder';
import * as React from 'react';
class App extends React.Component {
    constructor() {
        super(...arguments);
        this.columnData = [
            { field: 'EmployeeID', label: 'EmployeeID', type: 'number' },
            { field: 'FirstName', label: 'FirstName', type: 'string' },
            { field: 'TitleOfCourtesy', label: 'Title Of Courtesy', type: 'boolean', values: ['Mr.', 'Mrs.'] },
            { field: 'Title', label: 'Title', type: 'string' },
            { field: 'HireDate', label: 'HireDate', type: 'date', format: 'dd/MM/yyyy' },
            { field: 'Country', label: 'Country', type: 'string' },
            { field: 'City', label: 'City', type: 'string' }
        ];
    }
    render() {
        return (<QueryBuilderComponent width='100%' columns={this.columnData}/>);
    }
}

Adding CSS Reference

Import the Button component’s required CSS references as follows in src/App.css.

@import "../node_modules/@syncfusion/ej2-base/styles/material.css";
@import "../node_modules/@syncfusion/ej2-buttons/styles/material.css";
@import "../node_modules/@syncfusion/ej2-splitbuttons/styles/material.css";
@import "../node_modules/@syncfusion/ej2-dropdowns/styles/material.css";
@import "../node_modules/@syncfusion/ej2-inputs/styles/material.css";
@import "../node_modules/@syncfusion/ej2-lists/styles/material.css";
@import "../node_modules/@syncfusion/ej2-popups/styles/material.css";
@import "../node_modules/@syncfusion/ej2-calendars/styles/material.css";
@import "../node_modules/@syncfusion/ej2-querybuilder/styles/material.css";

The following example shows a basic Query Builder component.

Source

Preview

app.jsx

index.html

datasource.ts

app.tsx

import { QueryBuilderComponent } from '@syncfusion/ej2-react-querybuilder';
import * as React from 'react';
import * as ReactDom from 'react-dom';
class App extends React.Component {
    constructor() {
        super(...arguments);
        this.columnData = [
            { field: 'EmployeeID', label: 'EmployeeID', type: 'number' },
            { field: 'FirstName', label: 'FirstName', type: 'string' },
            { field: 'TitleOfCourtesy', label: 'Title Of Courtesy', type: 'boolean', values: ['Mr.', 'Mrs.'] },
            { field: 'Title', label: 'Title', type: 'string' },
            { field: 'HireDate', label: 'HireDate', type: 'date', format: 'dd/MM/yyyy' },
            { field: 'Country', label: 'Country', type: 'string' },
            { field: 'City', label: 'City', type: 'string' }
        ];
    }
    render() {
        return (<QueryBuilderComponent width='100%' columns={this.columnData}></QueryBuilderComponent>);
    }
}
ReactDom.render(<App />, document.getElementById('querybuilder'));

<!DOCTYPE html>
<html lang="en">

<head>
    <title>Syncfusion React Query Builder</title>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <meta name="description" content="Essential JS 2 for React Components" />
    <meta name="author" content="Syncfusion" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-base/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-buttons/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-splitbuttons/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-dropdowns/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-inputs/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-calendars/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-popups/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.3.47/ej2-querybuilder/styles/material.css" rel="stylesheet" />
	<link href="index.css" rel="stylesheet" />
    <script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
    <script src="systemjs.config.js"></script>
</head>

<body>
        <div id='querybuilder'>
            <div id='loader'>Loading....</div>
        </div>
</body>

</html>

/**
 * QueryBuilder datasource
 */
export let employeeData: Array<{[key: string]: any}> = [
	{
		'Address': '507 - 20th Ave. E.\r\nApt. 2A',
		'City': 'Seattle',
		'Country': 'USA',
		'EmployeeID': 1,
		'FirstName': 'Nancy',
		'HireDate': '22/07/2001',
		'LastName': 'Davolio',
		'PostalCode': '98122',
		'Region': 'WA',
		'Title': 'Sales Representative',
		'TitleOfCourtesy': 'Ms.'
	},
	{
		'Address': '908 W. Capital Way',
		'City': 'Tacoma',
		'Country': 'USA',
		'EmployeeID': 2,
		'FirstName': 'Andrew',
		'HireDate': '21/04/2003',
		'LastName': 'Fuller',
		'PostalCode': '98401',
		'Region': 'WA',
		'Title': 'Vice President',
		'TitleOfCourtesy': 'Dr.'
	},
	{
		'Address': '722 Moss Bay Blvd.',
		'City': 'Kirkland',
		'Country': 'USA',
		'EmployeeID': 3,
		'FirstName': 'Janet',
		'HireDate': '22/07/2001',
		'LastName': 'Leverling',
		'PostalCode': '98033',
		'Region': 'WA',
		'Title': 'Sales Representative',
		'TitleOfCourtesy': 'Ms.'
	},
	{
		'Address': '4110 Old Redmond Rd.',
		'City': 'Redmond',
		'Country': 'USA',
		'EmployeeID': 4,
		'FirstName': 'Margaret',
		'HireDate': '22/07/2004',
		'LastName': 'Peacock',
		'PostalCode': '98052',
		'Region': 'WA',
		'Title': 'Sales Representative',
		'TitleOfCourtesy': 'Mrs.'
	},
	{
		'Address': '14 Garrett Hill',
		'City': 'London',
		'Country': 'UK',
		'EmployeeID': 5,
		'FirstName': 'Steven',
		'HireDate': '02/04/2001',
		'LastName': 'Buchanan',
		'PostalCode': 'SW1 8JR',
		'Region': null,
		'Title': 'Sales Manager',
		'TitleOfCourtesy': 'Mr.'
	},
	{
		'Address': 'Coventry House\r\nMiner Rd.',
		'City': 'London',
		'Country': 'UK',
		'EmployeeID': 6,
		'FirstName': 'Michael',
		'HireDate': '22/01/2003',
		'LastName': 'Suyama',
		'PostalCode': 'EC2 7JR',
		'Region': null,
		'Title': 'Sales Representative',
		'TitleOfCourtesy': 'Mr.'
	},
	{
		'Address': 'Edgeham Hollow\r\nWinchester Way',
		'City': 'London',
		'Country': 'UK',
		'EmployeeID': 7,
		'FirstName': 'Robert',
		'HireDate': '22/07/2001',
		'LastName': 'King',
		'PostalCode': 'RG1 9SP',
		'Region': null,
		'Title': 'Sales Representative',
		'TitleOfCourtesy': 'Mr.'
	},
	{
		'Address': '4726 - 11th Ave. N.E.',
		'City': 'Seattle',
		'Country': 'USA',
		'EmployeeID': 8,
		'FirstName': 'Laura',
		'HireDate': '22/07/2001',
		'LastName': 'Callahan',
		'PostalCode': '98105',
		'Region': 'WA',
		'Title': 'Inside Sales Coordinator',
		'TitleOfCourtesy': 'Ms.'
	},
	{
		'Address': '7 Houndstooth Rd.',
		'City': 'London',
		'Country': 'UK',
		'EmployeeID': 9,
		'FirstName': 'Anne',
		'HireDate': '22/07/2001',
		'LastName': 'Dodsworth',
		'PostalCode': 'WG2 7LT',
		'Region': null,
		'Title': 'Sales Representative',
		'TitleOfCourtesy': 'Ms.'
	}
];
export let expenseData: Array<{[key: string]: any}>  = [
	{
		'Amount': '7',
		'Category': 'Food',
		'Description': 'Boiled peanuts',
		'FormattedDate': '06/01/2017 09:12 AM',
		'MonthFull': 'June, 2017',
		'MonthShort': 'Jun',
		'PaymentMode': 'Credit Card',
		'TransactionType': 'Expense',
		'UniqueId': 'T100001'
	},
	{
		'Amount': '8',
		'Category': 'Food',
		'Description': 'Peanuts in Coke',
		'FormattedDate': '06/04/2017 02:43 PM',
		'MonthFull': 'June, 2017',
		'MonthShort': 'Jun',
		'PaymentMode': 'Cash',
		'TransactionType': 'Expense',
		'UniqueId': 'T100024'
	},
	{
		'Amount': '11',
		'Category': 'Food',
		'Description': 'Palmetto Cheese, Mint julep',
		'FormattedDate': '06/04/2017 08:35 PM',
		'MonthFull': 'June, 2017',
		'MonthShort': 'Jun',
		'PaymentMode': 'Cash',
		'TransactionType': 'Expense',
		'UniqueId': 'T100025'
	},
	{
		'Amount': '9',
		'Category': 'Transportation',
		'Description': 'Cars and trucks, used',
		'FormattedDate': '06/04/2017 10:25 AM',
		'MonthFull': 'June, 2017',
		'MonthShort': 'Jun',
		'PaymentMode': 'Debit Card',
		'TransactionType': 'Expense',
		'UniqueId': 'T100026'
	},
	{
		'Amount': '8',
		'Category': 'Transportation',
		'Description': 'Public and other transportation',
		'FormattedDate': '06/04/2017 03:55 PM',
		'MonthFull': 'June, 2017',
		'MonthShort': 'Jun',
		'PaymentMode': 'Debit Card',
		'TransactionType': 'Expense',
		'UniqueId': 'T100027'
	},
	{
		'Amount': '160',
		'Category': 'Shopping',
		'Description': 'Household things & Utilities',
		'FormattedDate': '06/04/2017 10:22 AM',
		'MonthFull': 'June, 2017',
		'MonthShort': 'Jun',
		'PaymentMode': 'Cash',
		'TransactionType': 'Expense',
		'UniqueId': 'T100028'
	},
	{
		'Amount': '110',
		'Category': 'Extra income',
		'Description': 'Income from Sale',
		'FormattedDate': '11/30/2017 02:42 PM',
		'MonthFull': 'November, 2017',
		'MonthShort': 'Nov',
		'PaymentMode': 'Cash',
		'TransactionType': 'Income',
		'UniqueId': 'T101284'
	}
];
export let hardwareData: Array<{[key: string]: any}>  = [
	{
		'AssignedTo': 'John Doe',
		'Category': 'Laptop',
		'DOP': '04/10/2018',
		'InvoiceNo': 'INV-2878',
		'Name': 'Lenovo Yoga',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB27932009',
		'Status': 'Assigned',
		'TaskID': 1,
		'WEO': '05/01/2021'
	},
	{
		'AssignedTo': '',
		'Category': 'Others',
		'DOP': '02/12/2018',
		'InvoiceNo': 'INV-3456',
		'Name': 'Acer Aspire',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB35728290',
		'Status': 'In-repair',
		'TaskID': 2,
		'WEO': '03/01/2023'
	},
	{
		'AssignedTo': '',
		'Category': 'Laptop',
		'DOP': '04/10/2018',
		'InvoiceNo': 'INV-2763',
		'Name': 'Apple MacBook',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB35628728',
		'Status': 'In-repair',
		'TaskID': 3,
		'WEO': '04/03/2021'
	},
	{
		'AssignedTo': '',
		'Category': 'Laptop',
		'DOP': '03/09/2018',
		'InvoiceNo': 'INV-2980',
		'Name': 'Lenovo ThinkPad',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB56209872',
		'Status': 'Pending',
		'TaskID': 4,
		'WEO': '05/12/2021'
	},
	{
		'AssignedTo': 'David Anto',
		'Category': 'Laptop',
		'DOP': '01/10/2018',
		'InvoiceNo': 'INV-3782',
		'Name': 'Dell Inspiron',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB56289036',
		'Status': 'Assigned',
		'TaskID': 5,
		'WEO': '04/01/2021'
	},
	{
		'AssignedTo': 'Mary Saveley',
		'Category': 'Laptop',
		'DOP': '04/10/2018',
		'InvoiceNo': 'INV-2712',
		'Name': 'HP Pavilion',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB56289305',
		'Status': 'Assigned',
		'TaskID': 6,
		'WEO': '05/01/2021'
	},
	{
		'AssignedTo': '',
		'Category': 'Laptop',
		'DOP': '06/16/2018',
		'InvoiceNo': 'INV-0984',
		'Name': 'Asus ZenBook',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB25637891',
		'Status': 'Pending',
		'TaskID': 7,
		'WEO': '09/01/2021'
	},
	{
		'AssignedTo': '',
		'Category': 'Laptop',
		'DOP': '02/19/2018',
		'InvoiceNo': 'INV-2561',
		'Name': 'HP EliteBook',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB27819726',
		'Status': 'Ordered',
		'TaskID': 8,
		'WEO': '05/21/2021'
	},
	{
		'AssignedTo': '',
		'Category': 'Laptop',
		'DOP': '02/12/2018',
		'InvoiceNo': 'INV-8970',
		'Name': 'Apple MacBook Air',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB05262880',
		'Status': 'Pending',
		'TaskID': 9,
		'WEO': '03/01/2023'
	},
	{
		'AssignedTo': '',
		'Category': 'Tablet',
		'DOP': '04/10/2018',
		'InvoiceNo': 'INV-4555',
		'Name': 'Apple iPad Air',
		'Note': 'Remarks are noted',
		'SerialNo': 'CB45262777',
		'Status': 'Pending',
		'TaskID': 10,
		'WEO': '05/01/2021'
	}
];

import { ColumnsModel, QueryBuilderComponent } from '@syncfusion/ej2-react-querybuilder';
import * as React from 'react';
import * as ReactDom from 'react-dom';

class App extends React.Component<{}, {}> {

    public columnData: ColumnsModel[] = [
        { field: 'EmployeeID', label: 'EmployeeID', type: 'number'},
        { field: 'FirstName', label: 'FirstName', type: 'string' },
        { field: 'TitleOfCourtesy', label: 'Title Of Courtesy', type: 'boolean', values: ['Mr.', 'Mrs.'] },
        { field: 'Title', label: 'Title', type: 'string' },
        { field: 'HireDate', label: 'HireDate', type: 'date', format: 'dd/MM/yyyy' },
        { field: 'Country', label: 'Country', type: 'string' },
        { field: 'City', label: 'City', type: 'string' }
    ];

    public render() {
        return (
            <QueryBuilderComponent width='100%' columns={this.columnData} ></QueryBuilderComponent>
        );
    }
}
ReactDom.render(<App />,document.getElementById('querybuilder'));

You can also explore our React Query Builder example that shows how to render the Query Builder in React.

Contents

Dependencies
Installation and Configuration
Adding Syncfusion packages
Adding Query Builder component to the Application
Adding CSS Reference

Contents

Dependencies
Installation and Configuration
Adding Syncfusion packages
Adding Query Builder component to the Application
Adding CSS Reference

Please provide additional information

Thank you for your feedback and comments.We will rectify this as soon as possible!
