Getting Started with React MultiColumn ComboBox component

17 Mar 202524 minutes to read

This section explains how to create a simple MultiColumn Combobox component and configure its available functionalities in React.

Dependencies

The following list of dependencies are required to use the MultiColumn ComboBox component in your application.

|-- @syncfusion/ej2-react-multicolumn-combobox
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-data
    |-- @syncfusion/ej2-react-base
    |-- @syncfusion/ej2-grids
    |-- @syncfusion/ej2-lists
    |-- @syncfusion/ej2-inputs
    |-- @syncfusion/ej2-popups
        |-- @syncfusion/ej2-buttons

Setup for Local Development

To set-up a React application, choose any of the following ways. The best and easiest way is to use the create-react-app. It sets up your development environment in JavaScript and improvise your application for production. Refer to the installation instructions of create-react-app.

npx create-react-app my-app
cd my-app
npm start

yarn create react-app my-app
cd my-app
yarn start

To set-up a React application in TypeScript environment, run the following command.

npx create-react-app my-app --template typescript
cd my-app
npm start

Besides using the npx package runner tool, also create an application from the npm init. To begin with the npm init, upgrade the npm version to npm 6+.

npm init react-app my-app
cd my-app
npm start

Adding syncfusion^® packages

All the available Essential^® JS 2 packages are published in npmjs.com public registry. You can choose the component that you want to install.

To install MultiColumn ComboBox component, use the following command

npm install @syncfusion/ej2-react-multicolumn-combobox --save

Adding MultiColumn ComboBox component

Now, you can start adding MultiColumn ComboBox component in the application. For getting started, add the MultiColumn ComboBox component by using <<MultiColumnComboBoxComponent> selector in src/App.tsx file using following code.Now place the below MultiColumn ComboBox code in the src/App.tsx.

[Class-component]

import { MultiColumnComboBoxComponent } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from "react-dom";

export default class App extends React.Component<{}, {}> {
  public render() {
    return (
        // specifies the tag for render the MultiColumn ComboBox component
        <MultiColumnComboBoxComponent id="multicolumn"></MultiColumnComboBoxComponent>
    );
  }
}

ReactDOM.render(<App />, document.getElementById('multicolumn'));

[Functional-component]

import { MultiColumnComboBoxComponent } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from "react-dom";

function App() {
    return (
        // specifies the tag for render the MultiColumn ComboBox component
        <MultiColumnComboBoxComponent id="multicolumn"></MultiColumnComboBoxComponent>
    );
}

ReactDOM.render(<App />, document.getElementById('multicolumn'));

Adding CSS reference

Import the ComboBox component required CSS references as follows in src/App.css.

/* import the MultiColumn ComboBox dependency styles */

@import "../node_modules/@syncfusion/ej2-base/styles/material.css";
@import "../node_modules/@syncfusion/ej2-inputs/styles/material.css";
@import "../node_modules/@syncfusion/ej2-grids/styles/material.css";
@import "../node_modules/@syncfusion/ej2-popups/styles/material.css";
@import "../node_modules/@syncfusion/ej2-react-multicolumn-combobox/styles/material.css";

Binding data source with fields and columns

After initializing, populate the MultiColumn ComboBox with data by using the dataSource property, to map the data for each specified columns use the <ColumnDirective> selector and the fields property to map the data fields from the dataSource.

[Class-component]

import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

export default class App extends React.Component<{}, {}> {
  // define the array of object data
  private employeeData: Object[] = [
    { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
    { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
    { "EmpID": 1003, "Name": "John", "Designation": "Tester", "Country": "Germany" },
    { "EmpID": 1004, "Name": "Robert King", "Designation": "Product Manager", "Country": "India" },
    { "EmpID": 1005, "Name": "Steven Buchanan", "Designation": "Developer", "Country": "Italy" },
    { "EmpID": 1006, "Name": "Jane Smith", "Designation": "Developer", "Country": "Europe" },
    { "EmpID": 1007, "Name": "James Brown", "Designation": "Developer", "Country": "Australia" },
    { "EmpID": 1008, "Name": "Laura Callahan", "Designation": "Developer", "Country": "Africa" },
    { "EmpID": 1009, "Name": "Mario Pontes", "Designation": "Developer", "Country": "Russia" }
  ];
  // maps the appropriate column to fields property
  private fields: Object = { text: 'Name', value: 'EmpID' };
  public render() {
    return (
        // specifies the tag for render the MultiColumn ComboBox component
        <MultiColumnComboBoxComponent id="multicolumn" dataSource={this.employeeData} fields={this.fields}>
            <ColumnsDirective>
                <ColumnDirective field='EmpID' header='Employee ID' width={120}></ColumnDirective>
                <ColumnDirective field='Name' header='Name' width={120}></ColumnDirective>
                <ColumnDirective field='Designation' header='Designation' width={120}></ColumnDirective>
                <ColumnDirective field='Country' header='Country' width={100}></ColumnDirective>
            </ColumnsDirective>
        </MultiColumnComboBoxComponent>
    );
  }
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));

[Functional-component]

import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

function App() {
  // define the array of object data
  const employeeData: Object[] = [
    { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
    { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
    { "EmpID": 1003, "Name": "John", "Designation": "Tester", "Country": "Germany" },
    { "EmpID": 1004, "Name": "Robert King", "Designation": "Product Manager", "Country": "India" },
    { "EmpID": 1005, "Name": "Steven Buchanan", "Designation": "Developer", "Country": "Italy" },
    { "EmpID": 1006, "Name": "Jane Smith", "Designation": "Developer", "Country": "Europe" },
    { "EmpID": 1007, "Name": "James Brown", "Designation": "Developer", "Country": "Australia" },
    { "EmpID": 1008, "Name": "Laura Callahan", "Designation": "Developer", "Country": "Africa" },
    { "EmpID": 1009, "Name": "Mario Pontes", "Designation": "Developer", "Country": "Russia" }
  ];
  // maps the appropriate column to fields property
  const fields: Object = { text: 'Name', value: 'EmpID' };
  return (
    // specifies the tag for render the MultiColumn ComboBox component
    <MultiColumnComboBoxComponent id="multicolumn" dataSource={employeeData} fields={fields}>
        <ColumnsDirective>
            <ColumnDirective field='EmpID' header='Employee ID' width={120}></ColumnDirective>
            <ColumnDirective field='Name' header='Name' width={120}></ColumnDirective>
            <ColumnDirective field='Designation' header='Designation' width={120}></ColumnDirective>
            <ColumnDirective field='Country' header='Country' width={100}></ColumnDirective>
        </ColumnsDirective>
    </MultiColumnComboBoxComponent>
  );
}
ReactDOM.render(<App />, document.getElementById('sample'));

Run the application

After completing the configuration required to render a basic MultiColumn ComboBox, run the following command to display the output in your default browser.

npm start

[Class-componnet]

index.jsx
index.tsx
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
export default class App extends React.Component {
    // defined the array of data
    empData = [
        { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
        { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
        { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
        { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
        { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
        { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
        { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
        { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
        { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
        { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
        { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
        { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
        { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
        { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
        { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
        { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
        { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
        { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
        { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
        { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
    ];

    // maps the appropriate column to fields property
    fields = { text: 'Name', value: 'EmpID' };
    // set placeholder to multicolumn ComboBox input element
    waterMark = 'Select a employee';

    render() {
        return (
            <MultiColumnComboBoxComponent id="multicolumn" dataSource={this.empData} fields={this.fields} placeholder={this.waterMark}>
                <ColumnsDirective>
                    <ColumnDirective field='EmpID' header='Employee ID' width={120}></ColumnDirective>
                    <ColumnDirective field='Name' header='Name' width={120}></ColumnDirective>
                    <ColumnDirective field='Designation' header='Designation' width={120}></ColumnDirective>
                    <ColumnDirective field='Country' header='Country' width={100}></ColumnDirective>
                </ColumnsDirective>
            </MultiColumnComboBoxComponent>
        );
    }
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

export default class App extends React.Component<{}, {}> {
    // defined the array of data
    private empData: { [key: string]: Object }[] = [
        { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
        { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
        { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
        { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
        { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
        { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
        { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
        { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
        { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
        { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
        { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
        { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
        { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
        { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
        { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
        { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
        { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
        { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
        { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
        { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
    ];

    // maps the appropriate column to fields property
    private fields: object = { text: 'Name', value: 'EmpID' };
    // set placeholder to multicolumn ComboBox input element
    private waterMark: string = 'Select a employee';

    public render() {
        return (
            <MultiColumnComboBoxComponent id="multicolumn" dataSource={this.empData} fields={this.fields} placeholder={this.waterMark}>
                <ColumnsDirective>
                    <ColumnDirective field='EmpID' header='Employee ID' width={120}></ColumnDirective>
                    <ColumnDirective field='Name' header='Name' width={120}></ColumnDirective>
                    <ColumnDirective field='Designation' header='Designation' width={120}></ColumnDirective>
                    <ColumnDirective field='Country' header='Country' width={100}></ColumnDirective>
                </ColumnsDirective>
            </MultiColumnComboBoxComponent>
        );
    }
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));

[Functional-componnet]

index.jsx
index.tsx
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

function App() {
  // defined the array of object data
  const empData = [
    { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
    { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
    { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
    { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
    { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
    { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
    { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
    { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
    { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
    { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
    { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
    { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
    { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
    { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
    { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
    { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
    { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
    { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
    { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
    { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
];
  // maps the appropriate column to fields property
  const fields = { text: 'Name', value: 'EmpID' };
  // set placeholder to multicolumn ComboBox input element
  const waterMark = 'Select a employee';

  return (
    // specifies the tag for render the MultiColumn ComboBox component
    <MultiColumnComboBoxComponent id="multicolumn" dataSource={empData} fields={fields} placeholder={waterMark}>
        <ColumnsDirective>
            <ColumnDirective field='EmpID' header='Employee ID' width={120}></ColumnDirective>
            <ColumnDirective field='Name' header='Name' width={120}></ColumnDirective>
            <ColumnDirective field='Designation' header='Designation' width={120}></ColumnDirective>
            <ColumnDirective field='Country' header='Country' width={100}></ColumnDirective>
        </ColumnsDirective>
    </MultiColumnComboBoxComponent>
  );
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

function App() {
  // defined the array of object data
  const empData: { [key: string]: Object }[] = [
    { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
    { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
    { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
    { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
    { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
    { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
    { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
    { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
    { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
    { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
    { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
    { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
    { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
    { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
    { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
    { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
    { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
    { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
    { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
    { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
];
  // maps the appropriate column to fields property
  const fields: Object = { text: 'Name', value: 'EmpID' };
  // set placeholder to multicolumn ComboBox input element
  const waterMark: string = 'Select a employee';

  return (
    // specifies the tag for render the MultiColumn ComboBox component
    <MultiColumnComboBoxComponent id="multicolumn" dataSource={empData} fields={fields} placeholder={waterMark}>
        <ColumnsDirective>
            <ColumnDirective field='EmpID' header='Employee ID' width={120}></ColumnDirective>
            <ColumnDirective field='Name' header='Name' width={120}></ColumnDirective>
            <ColumnDirective field='Designation' header='Designation' width={120}></ColumnDirective>
            <ColumnDirective field='Country' header='Country' width={100}></ColumnDirective>
        </ColumnsDirective>
    </MultiColumnComboBoxComponent>
  );
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));

By default, the width of the popup list automatically adjusts according to the MultiColumn ComboBox input element’s width, and the height of the popup list has ‘300px’.

The height and width of the popup list can also be customized using the popupHeight and popupWidth properties respectively.

In the following sample, popup list’s width and height are configured.

[Class-component]

index.jsx
index.tsx
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';
export default class App extends React.Component {

    // defined the array of data
    empData = [
        { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
        { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
        { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
        { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
        { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
        { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
        { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
        { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
        { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
        { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
        { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
        { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
        { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
        { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
        { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
        { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
        { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
        { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
        { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
        { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
    ];

    // maps the appropriate column to fields property
    fields = { text: 'Name', value: 'EmpID' };
    // set placeholder to multicolumn ComboBox input element
    waterMark = 'Select a employee';

    render() {
        return (
            <MultiColumnComboBoxComponent id="multicolumn" dataSource={this.empData} fields={this.fields} popupWidth={500} popupHeight={250} placeholder={this.waterMark}>
                <ColumnsDirective>
                    <ColumnDirective field='EmpID' header='Employee ID' width={90}></ColumnDirective>
                    <ColumnDirective field='Name' header='Name' width={90}></ColumnDirective>
                    <ColumnDirective field='Designation' header='Designation' width={90}></ColumnDirective>
                    <ColumnDirective field='Country' header='Country' width={70}></ColumnDirective>
                </ColumnsDirective>
            </MultiColumnComboBoxComponent>
        );
    }
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

export default class App extends React.Component<{}, {}> {
    // defined the array of data
    private empData: { [key: string]: Object }[] = [
        { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
        { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
        { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
        { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
        { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
        { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
        { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
        { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
        { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
        { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
        { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
        { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
        { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
        { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
        { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
        { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
        { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
        { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
        { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
        { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
    ];

    // maps the appropriate column to fields property
    private fields: object = { text: 'Name', value: 'EmpID' };
    // set placeholder to multicolumn ComboBox input element
    private waterMark: string = 'Select a employee';

    public render() {
        return (
            <MultiColumnComboBoxComponent id="multicolumn" dataSource={this.empData} fields={this.fields} popupWidth={500} popupHeight={250} placeholder={this.waterMark}>
                <ColumnsDirective>
                    <ColumnDirective field='EmpID' header='Employee ID' width={90}></ColumnDirective>
                    <ColumnDirective field='Name' header='Name' width={90}></ColumnDirective>
                    <ColumnDirective field='Designation' header='Designation' width={90}></ColumnDirective>
                    <ColumnDirective field='Country' header='Country' width={70}></ColumnDirective>
                </ColumnsDirective>
            </MultiColumnComboBoxComponent>
        );
    }
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));

[Functional-component]

index.jsx
index.tsx
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

function App() {
  // defined the array of object data
  const empData = [
    { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
    { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
    { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
    { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
    { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
    { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
    { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
    { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
    { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
    { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
    { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
    { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
    { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
    { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
    { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
    { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
    { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
    { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
    { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
    { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
];
  // maps the appropriate column to fields property
  const fields = { text: 'Name', value: 'EmpID' };
  // set placeholder to multicolumn ComboBox input element
  const waterMark = 'Select a employee';

  return (
    // specifies the tag for render the MultiColumn ComboBox component
    <MultiColumnComboBoxComponent id="multicolumn" dataSource={empData} fields={fields} popupWidth={500} popupHeight={250} placeholder={waterMark}>
        <ColumnsDirective>
            <ColumnDirective field='EmpID' header='Employee ID' width={90}></ColumnDirective>
            <ColumnDirective field='Name' header='Name' width={90}></ColumnDirective>
            <ColumnDirective field='Designation' header='Designation' width={90}></ColumnDirective>
            <ColumnDirective field='Country' header='Country' width={70}></ColumnDirective>
        </ColumnsDirective>
    </MultiColumnComboBoxComponent>
  );
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));
import { MultiColumnComboBoxComponent, ColumnsDirective, ColumnDirective } from '@syncfusion/ej2-react-multicolumn-combobox';
import * as React from 'react';
import * as ReactDOM from 'react-dom';

function App() {
  // defined the array of object data
  const empData: { [key: string]: Object }[] = [
    { "EmpID": 1001, "Name": "Andrew Fuller", "Designation": "Team Lead", "Country": "England" },
    { "EmpID": 1002, "Name": "Robert", "Designation": "Developer", "Country": "USA" },
    { "EmpID": 1003, "Name": "Michael", "Designation": "HR", "Country": "Russia" },
    { "EmpID": 1004, "Name": "Steven Buchanan", "Designation": "Product Manager", "Country": "Ukraine" },
    { "EmpID": 1005, "Name": "Margaret Peacock", "Designation": "Developer", "Country": "Egypt" },
    { "EmpID": 1006, "Name": "Janet Leverling", "Designation": "Team Lead", "Country": "Africa" },
    { "EmpID": 1007, "Name": "Alice", "Designation": "Product Manager", "Country": "Australia" },
    { "EmpID": 1008, "Name": "Bob", "Designation": "Developer", "Country": "India" },
    { "EmpID": 1009, "Name": "John", "Designation": "Product Manager", "Country": "Ireland"},
    { "EmpID": 1010, "Name": "Mario Pontes", "Designation": "Team Lead", "Country": "South Africa" },
    { "EmpID": 1011, "Name": "Yang Wang", "Designation": "Developer", "Country": "Russia" },
    { "EmpID": 1012, "Name": "David", "Designation": "Product Manager", "Country": "Egypt" },
    { "EmpID": 1013, "Name": "Antonio Bianchi", "Designation": "Team Lead", "Country": "USA" },
    { "EmpID": 1014, "Name": "Laura", "Designation": "Developer", "Country": "England" },
    { "EmpID": 1015, "Name": "Carlos Hernandez", "Designation": "Developer", "Country": "Canada" },
    { "EmpID": 1016, "Name": "Lily", "Designation": "Product Manager", "Country": "France" },
    { "EmpID": 1017, "Name": "Tom Williams", "Designation": "Developer", "Country": "Ukraine" },
    { "EmpID": 1018, "Name": "Grace", "Designation": "Developer", "Country": "Australia" },
    { "EmpID": 1019, "Name": "Olivia", "Designation": "Team Lead", "Country": "Ireland" },
    { "EmpID": 1020, "Name": "James", "Designation": "Developer", "Country": "China" },
];
  // maps the appropriate column to fields property
  const fields: Object = { text: 'Name', value: 'EmpID' };
  // set placeholder to multicolumn ComboBox input element
  const waterMark: string = 'Select a employee';

  return (
    // specifies the tag for render the MultiColumn ComboBox component
    <MultiColumnComboBoxComponent id="multicolumn" dataSource={empData} fields={fields} popupWidth={500} popupHeight={250} placeholder={waterMark}>
        <ColumnsDirective>
            <ColumnDirective field='EmpID' header='Employee ID' width={90}></ColumnDirective>
            <ColumnDirective field='Name' header='Name' width={90}></ColumnDirective>
            <ColumnDirective field='Designation' header='Designation' width={90}></ColumnDirective>
            <ColumnDirective field='Country' header='Country' width={70}></ColumnDirective>
        </ColumnsDirective>
    </MultiColumnComboBoxComponent>
  );
}
ReactDOM.render(<App />, document.getElementById('multicolumn'));

Getting Started with React MultiColumn ComboBox component

Dependencies

Setup for Local Development

Adding syncfusion® packages

Adding MultiColumn ComboBox component

Adding CSS reference

Binding data source with fields and columns

Run the application

Configure the popup list

Adding syncfusion^® packages
