Getting started with React FloatingActionButton component

30 Jan 2023 / 3 minutes to read

This section explains how to create a simple Floating Action Button and demonstrate the basic usage of the Floating Action Button component in an React environment.

Dependencies

The list of dependencies required to use the Floating Action Button component in your application is given below:

Copied to clipboard
|-- @syncfusion/ej2-react-buttons
    |-- @syncfusion/ej2-react-base
    |-- @syncfusion/ej2-base
    |-- @syncfusion/ej2-buttons

Installation and Configuration

You can use Create-react-app to setup the applications. To install create-react-app run the following command.

Copied to clipboard
npm install -g create-react-app

Start a new project using create-react-app command as follows

Copied to clipboard
create-react-app quickstart --scripts-version=react-scripts-ts

cd quickstart
Copied to clipboard
create-react-app quickstart

cd quickstart

‘react-scripts-ts’ is used for creating React app with typescript.

Adding Syncfusion packages

All the available Essential JS 2 packages are published in npmjs.com public registry.

To install Floating Action Button component, use the following command

Copied to clipboard
npm install @syncfusion/ej2-react-buttons --save

Adding Floating Action Button Component to the Application

To include the Floating Action Button component in your application import the FabComponent from ej2-react-buttons package in App.tsx.

Add the Floating Action Button component in application as shown in below code example.

Copied to clipboard
{/* Import the Floating Action Button */}.
import { FabComponent } from '@syncfusion/ej2-react-buttons';
import * as React from 'react';
import './App.css';

{/* To render Floating Action Button. */}
function App() {
    return (
        <FabComponent id='fab'></FabComponent>
    );
}
export default App;
Copied to clipboard
{ /* Import the Floating Action Button */ }
import { FabComponent } from '@syncfusion/ej2-react-buttons';
import * as React from 'react';
import './App.css';
{ /* To render Floating Action Button. */ }
function App() {
    return (<FabComponent id='fab'></FabComponent>);
}
export default App;

Adding CSS reference

Import the Floating Action Button component’s required CSS references as follows in src/App.css.

Copied to clipboard
@import "../node_modules/@syncfusion/ej2-base/styles/material.css";
@import "../node_modules/@syncfusion/ej2-buttons/styles/material.css";

Running the application

Run the application in the browser using the following command:

Copied to clipboard
npm start

The following example shows a basic Floating Action Button component.

Source
Preview
app.jsx
index.html
app.tsx
Copied to clipboard
import { enableRipple } from '@syncfusion/ej2-base';
import { FabComponent } from '@syncfusion/ej2-react-buttons';
import * as React from 'react';
import * as ReactDom from 'react-dom';
enableRipple(true);
function App() {
    return (<div>
            <div id="targetElement" style={{ position: 'relative', minHeight: '350px', border: '1px solid' }}></div>

            <FabComponent id='fab' content='Add' target='#targetElement'></FabComponent>
        </div>);
}
export default App;
ReactDom.render(<App />, document.getElementById('button'));
Copied to clipboard
<!DOCTYPE html>
<html lang="en">

<head>

    <title>Syncfusion React Floating Action Button</title>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <meta name="description" content="Essential JS 2 for React Components" />
    <meta name="author" content="Syncfusion" />
    <link href="//cdn.syncfusion.com/ej2/20.4.38/ej2-base/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.4.38/ej2-buttons/styles/material.css" rel="stylesheet" />
	<link href="index.css" rel="stylesheet" />
    <script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
    <script src="systemjs.config.js"></script>
</head>

<body>
        <div id='button'>
            <div id='loader'>Loading....</div>
        </div>
</body>

</html>
Copied to clipboard
import { enableRipple } from '@syncfusion/ej2-base';
import { FabComponent } from '@syncfusion/ej2-react-buttons';
import * as React from 'react';
import * as ReactDom from 'react-dom';

enableRipple(true);

function App() {
    return (
        <div>
            <div id="targetElement" style={{ position: 'relative', minHeight: '350px', border: '1px solid' }}></div>
            {/* To render Floating Action Button with position. */ }
            <FabComponent id='fab' content='Add' target='#targetElement'></FabComponent>
        </div>
    );
}
export default App;
ReactDom.render(<App />, document.getElementById('button'));

Click event

The floating action button control triggers the onclick event when you click on the floating action button. You can use this event to perform the required action.

Source
Preview
app.jsx
index.html
app.tsx
Copied to clipboard
import { FabComponent } from '@syncfusion/ej2-react-buttons';
import * as React from 'react';
import * as ReactDom from 'react-dom';
function App() {
    function onClick() {
        alert("Edit is clicked!");
    }
    return (<div>
            <div id="targetElement" style={{ position: 'relative', minHeight: '350px', border: '1px solid' }}></div>

            <FabComponent id='fab' iconCss='e-icons e-edit' content='Edit' onClick={onClick} target='#targetElement'></FabComponent>
        </div>);
}
export default App;
ReactDom.render(<App />, document.getElementById('button'));
Copied to clipboard
<!DOCTYPE html>
<html lang="en">

<head>

    <title>Syncfusion React Floating Action Button</title>
    <meta charset="utf-8" />
    <meta name="viewport" content="width=device-width, initial-scale=1.0" />
    <meta name="description" content="Essential JS 2 for React Components" />
    <meta name="author" content="Syncfusion" />
    <link href="//cdn.syncfusion.com/ej2/20.4.38/ej2-base/styles/material.css" rel="stylesheet" />
    <link href="//cdn.syncfusion.com/ej2/20.4.38/ej2-buttons/styles/material.css" rel="stylesheet" />
	<link href="index.css" rel="stylesheet" />
    <script src="https://cdnjs.cloudflare.com/ajax/libs/systemjs/0.19.38/system.js"></script>
    <script src="systemjs.config.js"></script>
</head>

<body>
        <div id='button'>
            <div id='loader'>Loading....</div>
        </div>
</body>

</html>
Copied to clipboard
import { FabComponent } from '@syncfusion/ej2-react-buttons';
import * as React from 'react';
import * as ReactDom from 'react-dom';

function App() {

    function onClick(): void {
        alert("Edit is clicked!");
    }

    return (
        <div>
            <div id="targetElement" style={{ position: 'relative', minHeight: '350px', border: '1px solid' }}></div>
            {/* To render Floating Action Button */ }
            <FabComponent id='fab' iconCss='e-icons e-edit' content='Edit' onClick={onClick} target='#targetElement'></FabComponent>
        </div>
    );
}
export default App;
ReactDom.render(<App />, document.getElementById('button'));
