Remote data in EJ2 JavaScript Grid control

13 Apr 202324 minutes to read

To bind remote data to grid component, assign service data as an instance of DataManager to the dataSource property. To interact with remote data source, provide the endpoint url.

index.js
index.html
var data = new ej.data.DataManager({
    url: 'https://services.syncfusion.com/js/production/api/Orders',
    adaptor: new ej.data.ODataAdaptor()
});

var grid = new ej.grids.Grid({
    dataSource: data,
    columns: [
                { field: 'OrderID', headerText: 'Order ID', textAlign: 'Right', width: 120, type: 'number' },
                { field: 'CustomerID', width: 140, headerText: 'Customer ID', type: 'string' },
                { field: 'Freight', headerText: 'Freight', textAlign: 'Right', width: 120, format: 'C' },
                { field: 'OrderDate', headerText: 'Order Date', width: 140, format: 'yMd' }
    ]
});

grid.appendTo('#Grid');
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/25.1.35/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>

By default, DataManager uses ODataAdaptor for remote data-binding.

OData adaptor - Binding OData service

OData is a standardized protocol for creating and consuming data. You can retrieve data from OData service using the DataManager. Refer to the following code example for remote Data binding using OData service.

index.js
index.html
var data = new ej.data.DataManager({
    url: 'https://services.odata.org/V3/Northwind/Northwind.svc/Orders/',
    adaptor: new ej.data.ODataAdaptor(),
    crossDomain: true
});

var grid = new ej.grids.Grid({
    dataSource: data,
    columns: [
                { field: 'OrderID', headerText: 'Order ID', textAlign: 'Right', width: 120, type: 'number' },
                { field: 'CustomerID', width: 140, headerText: 'Customer ID', type: 'string' },
                { field: 'Freight', headerText: 'Freight', textAlign: 'Right', width: 120, format: 'C' },
                { field: 'OrderDate', headerText: 'Order Date', width: 140, format: 'yMd' }
    ]
});

grid.appendTo('#Grid');
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/25.1.35/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>

OData v4 adaptor - Binding OData v4 service

The ODataV4 is an improved version of OData protocols, and the DataManager can also retrieve and consume OData v4 services. For more details on OData v4 services, refer to the odata documentation. To bind OData v4 service, use the ODataV4Adaptor.

index.js
index.html
var data = new ej.data.DataManager({
    url: 'https://services.odata.org/V4/Northwind/Northwind.svc/Orders/?$top=7',
    adaptor: new ej.data.ODataV4Adaptor()
});

var grid = new ej.grids.Grid({
    dataSource: data,
    columns: [
                { field: 'OrderID', headerText: 'Order ID', textAlign: 'Right', width: 120, type: 'number' },
                { field: 'CustomerID', width: 140, headerText: 'Customer ID', type: 'string' },
                { field: 'Freight', headerText: 'Freight', textAlign: 'Right', width: 120, format: 'C' },
                { field: 'OrderDate', headerText: 'Order Date', width: 140, format: 'yMd' }
    ]
});

grid.appendTo('#Grid');
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/25.1.35/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>

Web API adaptor

You can use WebApiAdaptor to bind grid with Web API created using OData endpoint.

import { Grid } from '@syncfusion/ej2-grids';
import { DataManager, WebApiAdaptor } from '@syncfusion/ej2-data';

let data: DataManager = new DataManager({
    url: '/api/OrderAPI',
    adaptor: new WebApiAdaptor
});

let grid: Grid = new Grid({
    dataSource: data,
    columns: [
                { field: 'OrderID', headerText: 'Order ID', textAlign: 'Right', width: 120, type: 'number' },
                { field: 'CustomerID', width: 140, headerText: 'Customer ID', type: 'string' },
                { field: 'Freight', headerText: 'Freight', textAlign: 'Right', width: 120, format: 'C' },
                { field: 'OrderDate', headerText: 'Order Date', width: 140, format: 'yMd' }
    ]
});

grid.appendTo('#Grid');

The response object should contain properties, Items and Count, whose values are a collection of entities and total count of the entities, respectively.

The sample response object should look like this:

{
    Items: [{..}, {..}, {..}, ...],
    Count: 830
}

Remote save adaptor

You may need to perform all Grid Actions in client-side except the CRUD operations, that should be interacted with server-side to persist data. It can be achieved in Grid by using RemoteSaveAdaptor.

Datasource must be set to json property and set RemoteSaveAdaptor to the adaptor property. CRUD operations can be mapped to server-side using updateUrl, insertUrl, removeUrl, batchUrl, crudUrl properties.

You can use the following code example to use RemoteSaveAdaptor in Grid.

import { Grid, Edit, Toolbar } from '@syncfusion/ej2-grids';
import { DataManager, RemoteSaveAdaptor } from '@syncfusion/ej2-data';
import { data } from './datasource.ts';

Grid.Inject(Edit, Toolbar);

let dataSource: DataManager = new DataManager({
    json: data,
    adaptor: new RemoteSaveAdaptor,
    insertUrl: '/Home/Insert',
    updateUrl: '/Home/Update',
    removeUrl: '/Home/Delete'
});

let grid: Grid = new Grid({
    dataSource: dataSource,
    toolbar: ['Add', 'Edit', 'Delete', 'Update', 'Cancel'],
    editSettings: { allowEditing: true, allowAdding: true, allowDeleting: true },
    columns: [
                { field: 'OrderID', headerText: 'Order ID', isPrimaryKey: true, textAlign: 'Right', width: 120, type: 'number' },
                { field: 'CustomerID', width: 140, headerText: 'Customer ID', type: 'string' },
                { field: 'Freight', headerText: 'Freight', textAlign: 'Right', width: 120, format: 'C' },
                { field: 'OrderDate', headerText: 'Order Date', width: 140, format: 'yMd' }
    ]
});

grid.appendTo('#Grid');

The following code example describes the CRUD operations handled at server-side.

    public ActionResult Update(OrdersDetails value)
    {
        ...
        return Json(value);
    }
    public ActionResult Insert(OrdersDetails value)
    {
        ...
       return Json(value);
    }
    public ActionResult Delete(int key)
    {
        ...
        return Json(data);
    }

Custom adaptor

You can create your own adaptor by extending the built-in adaptors. The following demonstrates custom adaptor approach and how to add a serial number for the records by overriding the built-in response processing using the processResponse method of the ODataAdaptor.

index.js
index.html
class SerialNoAdaptor extends ej.data.ODataV4Adaptor {
    processResponse() {
        var i= 0;
        // calling base class processResponse function
        var original = super.processResponse.apply(this, arguments);
        // adding serial number
        original.result.forEach(function(item){item['Sno'] = ++i});
        return { result: original.result, count: original.count };
    }
}

var data = new ej.data.DataManager({
    url: 'https://services.syncfusion.com/js/production/api/Orders',
    adaptor: new SerialNoAdaptor()
});

var grid = new ej.grids.Grid({
    dataSource: data,
    columns: [
        { field: 'Sno', width: 120, headerText: 'SNO', textAlign: 'Right' },
        { field: 'CustomerID', width: 140, headerText: 'Customer Name', type: 'string' },
        { field: 'Freight', headerText: 'Freight', textAlign: 'Right', width: 120, format: 'C2' },
        { field: 'OrderDate', headerText: 'Order Date', width: 140, format: 'yMd' }
    ]
});

grid.appendTo('#Grid');
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/25.1.35/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>

Offline mode

On remote data binding, all grid actions such as paging, sorting, editing, grouping, filtering, etc, will be processed on server-side. To avoid postback for every action, set the grid to load all data on initialization and make the actions process in client-side. To enable this behavior, use the offline property of DataManager.

index.js
index.html
var data = new ej.data.DataManager({
    url: 'https://services.syncfusion.com/js/production/api/Orders',
    adaptor: new ej.data.ODataAdaptor(),
    offline: true
});
ej.grids.Grid.Inject(ej.grids.Page, ej.grids.Sort, ej.grids.Group);
var grid = new ej.grids.Grid({
    dataSource: data,
    columns: [
                { field: 'OrderID', headerText: 'Order ID', textAlign: 'Right', width: 120, type: 'number' },
                { field: 'CustomerID', width: 140, headerText: 'Customer ID', type: 'string' },
                { field: 'Freight', headerText: 'Freight', textAlign: 'Right', width: 120, format: 'C' },
                { field: 'OrderDate', headerText: 'Order Date', width: 140, format: 'yMd' }
    ],
    allowPaging: true,
    pageSettings: { pageSize: 7 },
    allowSorting: true,
    allowGrouping: true
});

grid.appendTo('#Grid');
<!DOCTYPE html><html lang="en"><head>
    <title>EJ2 Grid</title>
    <meta charset="utf-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <meta name="description" content="Typescript Grid Control">
    <meta name="author" content="Syncfusion">
    <link href="index.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-base/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-grids/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-buttons/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-popups/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-richtexteditor/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-navigations/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-dropdowns/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-lists/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-inputs/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-calendars/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-notifications/styles/material.css" rel="stylesheet">
    <link href="https://cdn.syncfusion.com/ej2/25.1.35/ej2-splitbuttons/styles/material.css" rel="stylesheet">



    <style>
        .e-row[aria-selected="true"] .e-customizedExpandcell {
            background-color: #e0e0e0;
        }
        .e-grid.e-gridhover tr[role='row']:hover {
            background-color: #eee;
        }
        .e-expand::before {
        content: '\e5b8';
    }
    .empImage {
        margin: 6px 16px;
        float: left;
        width: 50px;
        height: 50px;
    }
    </style>
<script src="https://cdn.syncfusion.com/ej2/25.1.35/dist/ej2.min.js" type="text/javascript"></script>
<script src="es5-datasource.js" type="text/javascript"></script>
<script src="https://cdn.syncfusion.com/ej2/syncfusion-helper.js" type ="text/javascript"></script>
</head>
<body>

    <div id="container">
        <div id="Grid"></div>
    </div>

<script>
var ele = document.getElementById('container');
if(ele) {
  ele.style.visibility = "visible";
}
      </script>
<script src="index.js" type="text/javascript"></script>
</body></html>
