Getting Started with ASP.NET MVC

Starting with v16.2.0.x, if you reference Syncfusion assemblies from trial setup or from the NuGet feed, you also have to include a license key in your projects. Please refer to this link to know about registering Syncfusion license key in your ASP.NET Core application to use our components.

Prerequisites

To get start with ASP.NET MVC application, need to ensure the following software to be installed on the machine.

  1. .Net Framework 4.5 and above.
  2. ASP.NET MVC 4 or ASP.NET MVC 5
  3. Visual Studio

Preparing ASP.NET MVC application

The following steps to create ASP.NET MVC Application.

Step 1: Create ASP.NET MVC Application with default template project in Visual Studio.

Default Template

Step 2: Once your project created. We need to add Syncfusion EJ2 package into your application by using NuGet Package Manager.

Open the NuGet package manager.

Solution Explorer

Install the Syncfusion.EJ2.MVC4 package to the application.

Nuget Demo

After installation complete, this will be included in the project. You can refer it from the Project Assembly Reference.

We need to install NewtonSoft.JSON as a dependency, since Syncfusion.EJ2 dependent to NewtonSoft.JSON package.

Step 3: Add Syncfusion.EJ2 namespace reference in Web.config

<namespaces>
    <add namespace="Syncfusion.EJ2"/>
</namespaces>
<system.web>
    <compilation>
      <assemblies>
        <add assembly="Syncfusion.EJ2" Version=15.3400.0.27, Culture=neutral, PublicKeyToken=31BF3856AD364E35"/>
      </assemblies>
    </compilation>
  </system.web>

Step 4: Add client side resource through CDN or local package in the layout page _Layout.cshtml.

<head>
@* Syncfusion Essential JS 2 Styles *@
<link rel="stylesheet" href="https://cdn.syncfusion.com/ej2/material.css" />

@* Syncfusion Essential JS 2 Scripts *@
<script src="https://cdn.syncfusion.com/ej2/dist/ej2.min.js"></script>
</head>

Step 5: Adding Script Manager in layout page _Layout.cshtml.

@Html.EJS().ScriptManager()

Step 6: Add the below code to your Index.cshtml view page which is present under Views/Home folder, to initialize the chart.

{% aspCodeBlock razorTemplate=“chart/getting-started/datalabel/razor” %}

<ejs-chart id="container"></ejs-chart>

{% endaspCodeBlock %}

Enable Legend

You can use legend for the chart by setting the visible property to true in legendSettings object.

razor
legend.cs
@Html.EJS().Chart("container").ChartArea(area => area.Border(ViewBag.ChartBorder)).Series(series =>
       {
           series.Type(Syncfusion.EJ2.Charts.ChartSeriesType.Line).Width(2).XName("xValue").Marker(ViewBag.marker).YName("yValue").DataSource(ViewBag.dataSource).Name("Germany").Add();
           series.Type(Syncfusion.EJ2.Charts.ChartSeriesType.Line).Width(2).XName("xValue").YName("yValue1").Marker(ViewBag.marker).DataSource(ViewBag.dataSource).Name("England").Add();


       }).PrimaryXAxis(px => px.ValueType(Syncfusion.EJ2.Charts.ValueType.DateTime).MajorGridLines(ViewBag.majorGridLines).MajorGridLines(ViewBag.majorGridLines).IntervalType(Syncfusion.EJ2.Charts.IntervalType.Years).EdgeLabelPlacement(Syncfusion.EJ2.Charts.EdgeLabelPlacement.Shift).LabelFormat("y")
       ).PrimaryYAxis(py => py.LabelFormat("{value}%").RangePadding(Syncfusion.EJ2.Charts.ChartRangePadding.None).MajorTickLines(ViewBag.majorTickLines).MinorTickLines(ViewBag.minorTickLines).LineStyle(ViewBag.lineStyle).Interval(20).Minimum(0).Maximum(100)
       ).Title("Inflation - Consumer Price").Tooltip(tt => tt.Enable(true)).Load("load").Render();
public IActionResult Index()
        {
            List<LineChartData> chartData = new List<LineChartData>
            {
                new LineChartData { xValue = new DateTime(2005, 01, 01), yValue = 21, yValue1 = 28 },
                new LineChartData { xValue = new DateTime(2006, 01, 01), yValue = 24, yValue1 = 44 },
                new LineChartData { xValue = new DateTime(2007, 01, 01), yValue = 36, yValue1 = 48 },
                new LineChartData { xValue = new DateTime(2008, 01, 01), yValue = 38, yValue1 = 50 },
                new LineChartData { xValue = new DateTime(2009, 01, 01), yValue = 54, yValue1 = 66 },
                new LineChartData { xValue = new DateTime(2010, 01, 01), yValue = 57, yValue1 = 78 },
                new LineChartData { xValue = new DateTime(2011, 01, 01), yValue = 70, yValue1 = 84 },
            };
            ViewBag.dataSource = chartData;
            return View();
        }
        public class LineChartData
        {
            public DateTime xValue;
            public double yValue;
            public double yValue1;
        }

Add Data Label

You can add data labels to improve the readability of the chart. This can be achieved by setting the visible property to true in the dataLabel object. Now, the data labels are arranged smartly based on series.

razor
datalabel.cs
@Html.EJS().Chart("container").ChartArea(area => area.Border(ViewBag.ChartBorder)).Series(series =>
       {
           series.Type(Syncfusion.EJ2.Charts.ChartSeriesType.Line).Width(2).XName("xValue").Marker(ViewBag.marker).YName("yValue").DataSource(ViewBag.dataSource).Name("Germany").Add();
           series.Type(Syncfusion.EJ2.Charts.ChartSeriesType.Line).Width(2).XName("xValue").YName("yValue1").Marker(ViewBag.marker).DataSource(ViewBag.dataSource).Name("England").Add();


       }).PrimaryXAxis(px => px.ValueType(Syncfusion.EJ2.Charts.ValueType.DateTime).MajorGridLines(ViewBag.majorGridLines).MajorGridLines(ViewBag.majorGridLines).IntervalType(Syncfusion.EJ2.Charts.IntervalType.Years).EdgeLabelPlacement(Syncfusion.EJ2.Charts.EdgeLabelPlacement.Shift).LabelFormat("y")
       ).PrimaryYAxis(py => py.LabelFormat("{value}%").RangePadding(Syncfusion.EJ2.Charts.ChartRangePadding.None).MajorTickLines(ViewBag.majorTickLines).MinorTickLines(ViewBag.minorTickLines).LineStyle(ViewBag.lineStyle).Interval(20).Minimum(0).Maximum(100)
       ).Title("Inflation - Consumer Price").Tooltip(tt => tt.Enable(true)).Load("load").Render()
public IActionResult Index()
        {
            List<LineChartData> chartData = new List<LineChartData>
            {
                new LineChartData { xValue = new DateTime(2005, 01, 01), yValue = 21, yValue1 = 28 },
                new LineChartData { xValue = new DateTime(2006, 01, 01), yValue = 24, yValue1 = 44 },
                new LineChartData { xValue = new DateTime(2007, 01, 01), yValue = 36, yValue1 = 48 },
                new LineChartData { xValue = new DateTime(2008, 01, 01), yValue = 38, yValue1 = 50 },
                new LineChartData { xValue = new DateTime(2009, 01, 01), yValue = 54, yValue1 = 66 },
                new LineChartData { xValue = new DateTime(2010, 01, 01), yValue = 57, yValue1 = 78 },
                new LineChartData { xValue = new DateTime(2011, 01, 01), yValue = 70, yValue1 = 84 },
            };
            ViewBag.dataSource = chartData;
            return View();
        }
        public class LineChartData
        {
            public DateTime xValue;
            public double yValue;
            public double yValue1;
        }

Enable Tooltip

The tooltip is useful when you cannot display information by using the data labels due to space constraints. You can enable tooltip by setting the enable property as true in tooltip object.

razor
tooltip.cs
@Html.EJS().Chart("container").ChartArea(area => area.Border(ViewBag.ChartBorder)).Series(series =>
       {
           series.Type(Syncfusion.EJ2.Charts.ChartSeriesType.Line).Width(2).XName("xValue").Marker(ViewBag.marker).YName("yValue").DataSource(ViewBag.dataSource).Name("Germany").Add();
           series.Type(Syncfusion.EJ2.Charts.ChartSeriesType.Line).Width(2).XName("xValue").YName("yValue1").Marker(ViewBag.marker).DataSource(ViewBag.dataSource).Name("England").Add();


       }).PrimaryXAxis(px => px.ValueType(Syncfusion.EJ2.Charts.ValueType.DateTime).MajorGridLines(ViewBag.majorGridLines).MajorGridLines(ViewBag.majorGridLines).IntervalType(Syncfusion.EJ2.Charts.IntervalType.Years).EdgeLabelPlacement(Syncfusion.EJ2.Charts.EdgeLabelPlacement.Shift).LabelFormat("y")
       ).PrimaryYAxis(py => py.LabelFormat("{value}%").RangePadding(Syncfusion.EJ2.Charts.ChartRangePadding.None).MajorTickLines(ViewBag.majorTickLines).MinorTickLines(ViewBag.minorTickLines).LineStyle(ViewBag.lineStyle).Interval(20).Minimum(0).Maximum(100)
       ).Title("Inflation - Consumer Price").Tooltip(tt => tt.Enable(true)).Load("load").Render()
public IActionResult Index()
        {
            List<LineChartData> chartData = new List<LineChartData>
            {
                new LineChartData { xValue = new DateTime(2005, 01, 01), yValue = 21, yValue1 = 28 },
                new LineChartData { xValue = new DateTime(2006, 01, 01), yValue = 24, yValue1 = 44 },
                new LineChartData { xValue = new DateTime(2007, 01, 01), yValue = 36, yValue1 = 48 },
                new LineChartData { xValue = new DateTime(2008, 01, 01), yValue = 38, yValue1 = 50 },
                new LineChartData { xValue = new DateTime(2009, 01, 01), yValue = 54, yValue1 = 66 },
                new LineChartData { xValue = new DateTime(2010, 01, 01), yValue = 57, yValue1 = 78 },
                new LineChartData { xValue = new DateTime(2011, 01, 01), yValue = 70, yValue1 = 84 },
            };
            ViewBag.dataSource = chartData;
            return View();
        }
        public class LineChartData
        {
            public DateTime xValue;
            public double yValue;
            public double yValue1;
        }
