Exporting grid with templates in ASP.NET Core Grid control

26 Dec 202424 minutes to read

The grid offers the option to export the column, detail, and caption templates to an Excel document. The template contains images, hyperlinks, and customized text.

Exporting with column template

The Excel export functionality allows you to export Grid columns that include images, hyperlinks, and custom text to an Excel document.

In the following sample, the hyperlinks and images are exported to Excel using hyperlink and image properties in the excelQueryCellInfo event.

Excel Export supports base64 string to export the images.

CSHTML
column-template-export.cs
<ejs-grid id="grid" dataSource="@ViewBag.dataSource" allowExcelExport="true" toolbar="@(new List<string>() {"ExcelExport"})"
    toolbarClick="toolbarClick" excelQueryCellInfo="excelQueryCellInfo">
    <e-grid-columns>
        <e-grid-column headerText="Employee Image" textAlign="Center" template="#imageTemplate" width="150"></e-grid-column>
        <e-grid-column field="EmployeeID" headerText="Employee ID" width="125"></e-grid-column>
        <e-grid-column field="FirstName" headerText="First Name" width="120"></e-grid-column>
        <e-grid-column field="EmailID" headerText="Email ID" template="#mailTemplate" width="170"></e-grid-column>
    </e-grid-columns>
</ejs-grid>
<style type="text/css" class="cssStyles">
    .image img {
        border-radius: 50px;
        box-shadow: inset 0 0 1px #e0e0e0, inset 0 0 14px rgba(0,0,0,0.2);
        height: 55px;
        width: 55px;
    }
</style>
<script type="text/x-template" id="imageTemplate">
    <div class="image">
    </div>
</script>
<script type="text/x-template" id="mailTemplate">
    <div class="link">
        <a href="mailto:${EmailID}">${EmailID}</a>
    </div>
</script>
<script>
    function toolbarClick(args) {
        if (args['item'].id === 'grid_excelexport') {
            this.excelExport();
        }
    }
    function excelQueryCellInfo(args) {
        if (args.column.headerText === 'Employee Image') {
            args.image = {
                base64: args.data.EmployeeImage,
                height: 70,
                width: 70,
            };
        }
        if (args.column.headerText === 'Email ID') {
            args.hyperLink = {
                target: 'mailto:' + args.data.EmailID,
                displayText: args.data.EmailID,
            };
        }
    }
</script>
public IActionResult Index()
{
    ViewBag.dataSource = OrderDetails.GetAllRecords();
    return View();
}

ColumnTemplateExport

Exporting with detail template

By default, the grid will export the parent grid with expanded detail rows alone. Change the exporting option by using the excelExportProperties.hierarchyExportMode property. The available options are:

Mode	Behavior
Expanded	Exports the parent grid with expanded detail rows.
All	Exports the parent grid with all the detail rows.
None	Exports the parent grid alone.

The detail rows in the exported Excel can be customized or formatted using the exportDetailTemplate event. In this event, the detail rows of the Excel document are formatted in accordance with their parent row details.

In the following sample, the detail row content is formatted by specifying the columnHeader and rows properties using its parentRow details. This allows for the creation of detail rows in the Excel document. Additionally, custom styles can be applied to specific cells using the style property.

When using rowSpan, it is essential to provide the cell’s index for proper functionality.

CSHTML
detail-template-export.cs
<ejs-grid id="grid" dataSource="@ViewBag.dataSource" detailTemplate="#detailtemplate" allowExcelExport="true"
    toolbar="@(new List<string>() {"ExcelExport"})" toolbarClick="toolbarClick" exportDetailTemplate="exportDetailTemplate">
    <e-grid-columns>
        <e-grid-column field="Category" headerText="Category" width="140"></e-grid-column>
        <e-grid-column field="ProductID" headerText="Product ID" width="120"></e-grid-column>
        <e-grid-column field="Status" headerText="Status" width="200"></e-grid-column>
    </e-grid-columns>
</ejs-grid>
<style type="text/css" class="cssStyles">
    .detailtable td {
        font-size: 13px;
        padding: 4px;
        max-width: 0;
        overflow: hidden;
        text-overflow: ellipsis;
        white-space: nowrap;
    }

    .photo {
        width: 100px;
        height: 100px;
        border-radius: 50px;
        box-shadow: inset 0 0 1px #e0e0e0, inset 0 0 14px rgba(0, 0, 0, 0.2);
    }

    .Unavailable {
        color: #FF0000;
    }

    .Available {
        color: #00FF00;
    }
</style>
<script type="text/x-template" id="detailtemplate">
    <table class="detailtable" width="100%">
        <colgroup>
            <col width="40%" />
            <col width="60%" />
        </colgroup>
        <thead>
            <tr>
                <th colspan="2" style="font-weight: 500;text-align: center;background-color: #ADD8E6;">
                    Product Details
                </th>
            </tr>
        </thead>
        <tbody>
            <tr>
                <td rowspan="4" style="text-align: center;">
                </td>
                <td>
                    <span style="font-weight: 500;color: #0a76ff;">Offers: ${Offers} </span>
                </td>
            </tr>
            <tr>
                <td>
                    <span>Available: ${Available} </span>
                </td>
            </tr>
            <tr>
                <td>
                    <span class="link">
                        Contact: <a href="mailto:${Contact}">${Contact}</a>
                    </span>
                </td>
            </tr>
            <tr>
                <td>
                    <span style="font-weight: 500;color: #0a76ff;"> Ratings: ${Ratings}</span>
                </td>
            </tr>
            <tr>
                <td style="text-align: center;">
                    <span> ${productDesc}</span>
                </td>
                <td>
                    <span>${ReturnPolicy}</span>
                </td>
            </tr>
            <tr>
                <td style="text-align: center;">
                    <span style="font-weight: 500;" > ${Cost}</span>
                </td>
                <td>
                    <span>${Cancellation}</span>
                </td>
            </tr>
            <tr>
                <td style="text-align: center;">
                    <span class="${Status}" style="font-weight: 500;" > ${Status}</span>
                </td>
                <td>
                    <span style="font-weight: 500;color: #0a76ff;">${Delivery}</span>
                </td>
            </tr>
        </tbody>
    </table>
</script>

<script>
    function toolbarClick(args) {
        if (args['item'].id === 'grid_excelexport') {
            this.excelExport({
                hierarchyExportMode: "Expanded"
            });
        }
    }

    function exportDetailTemplate(args) {
        args.value = {
            columnHeader: [
                {
                    cells: [{
                        index: 0, colSpan: 2, value: 'Product Details',
                        style: { backColor: '#ADD8E6', excelHAlign: 'Center', bold: true }
                    }]
                }
            ],
            rows: [
                {
                    cells: [
                        {
                            index: 0, rowSpan: 4, image: {
                                base64: args.parentRow.data['ProductImg'],
                                height: 80, width: 100
                            }
                        },
                        {
                            index: 1, value: "Offers: " + args.parentRow.data['Offers'],
                            style: { bold: true, fontColor: '#0a76ff' }
                        },
                    ]
                },
                {
                    cells: [
                        {
                            index: 1, value: 'Available: ' + args.parentRow.data['Available']
                        }]
                },
                {
                    cells: [
                        {
                            index: 1, value: 'Contact: ',
                            hyperLink: {
                                target: 'mailto:' + args.parentRow.data['Contact'],
                                displayText: args.parentRow.data['Contact']
                            }
                        }]
                },
                {
                    cells: [
                        {
                            index: 1, value: 'Ratings: ' + args.parentRow.data['Ratings'],
                            style: { bold: true, fontColor: '#0a76ff' }
                        }
                    ]
                },
                {
                    cells: [
                        {
                            index: 0, value: args.parentRow.data['productDesc'],
                            style: { excelHAlign: 'Center' }
                        },
                        { index: 1, value: args.parentRow.data['ReturnPolicy'] }
                    ]
                },
                {
                    cells: [
                        {
                            index: 0, value: args.parentRow.data['Cost'],
                            style: { excelHAlign: 'Center', bold: true }
                        },
                        { index: 1, value: args.parentRow.data['Cancellation'] }
                    ]
                },
                {
                    cells: [
                        {
                            index: 0, value: args.parentRow.data['Status'],
                            style: {
                                bold: true, fontColor: args.parentRow.data['Status'] === 'Available' ? '#00FF00' : '#FF0000',
                                excelHAlign: 'Center'
                            }
                        },
                        {
                            index: 1, value: args.parentRow.data['Delivery'],
                            style: { bold: true, fontColor: '#0a76ff' }
                        }
                    ]
                }
            ],
        };
    }
</script>
public IActionResult Index()
{
    ViewBag.dataSource = OrderDetails.GetAllRecords();
    return View();
}

DetailTemplateExport

Exporting with caption template

The Excel export feature enables exporting of Grid with a caption template to an Excel document.

In the following sample, the customized caption text is exported to Excel using captionText property in the exportGroupCaption event.

CSHTML
caption-template-export.cs
<ejs-grid id="grid" dataSource="@ViewBag.dataSource" allowExcelExport="true" toolbar="@(new List<string>() {"ExcelExport"})"
    toolbarClick="toolbarClick" allowGrouping="true" exportGroupCaption="exportGroupCaption">
    <e-grid-groupsettings captionTemplate="#captiontemplate" columns="@(new string[] {"EmployeeID"})"></e-grid-groupsettings>
    <e-grid-columns>
        <e-grid-column field="EmployeeID" headerText="Employee ID" width="120"></e-grid-column>
        <e-grid-column field="FirstName" headerText="First Name" width="120"></e-grid-column>
        <e-grid-column field="City" headerText="City"></e-grid-column>
        <e-grid-column field="Title" headerText="Title" width="170"></e-grid-column>
    </e-grid-columns>
</ejs-grid>
<script type="text/x-template" id="captiontemplate">
    ${field} - ${key}
</script>
<script>
    function toolbarClick(args) {
        if (args['item'].id === 'grid_excelexport') {
            this.excelExport();
        }
    }
    function exportGroupCaption(args) {
        args.captionText = args.data.field + ' - ' + args.data.key;
    }
</script>
public IActionResult Index()
{
    ViewBag.dataSource = OrderDetails.GetAllRecords();
    return View();
}

CaptionTemplateExport
